mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM > Class Template Reference

Detailed Description

template<int DIM>
class mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >

A class that generalizes the concept of an ellipsoid to arbitrary parameterizations of uncertainty shapes in either 2D or 3D.

See derived classes for examples.

Please read the documentation of CGeneralizedEllipsoidTemplate::setQuantiles() for learning the mathematical details about setting the desired confidence interval.

The main method to set the modeled uncertainty is setCovMatrixAndMean()

Template Parameters

DIM	The dimensionality of the parameter space, which must coincide with that of the rendering space (2 or 3)

Definition at line 73 of file CGeneralizedEllipsoidTemplate.h.

#include <mrpt/opengl/CGeneralizedEllipsoidTemplate.h>

Inheritance diagram for mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >:

Public Types
typedef mrpt::math::CMatrixFixedNumeric< double, DIM, DIM >	cov_matrix_t
	The type of fixed-size covariance matrices for this representation. More...
typedef mrpt::math::CMatrixFixedNumeric< double, DIM, 1 >	mean_vector_t
	The type of fixed-size vector for this representation. More...
typedef mrpt::math::CMatrixFixedNumeric< float, DIM, 1 >	array_parameter_t
typedef mrpt::math::CMatrixFixedNumeric< float, DIM, 1 >	array_point_t

Public Member Functions
template<typename MATRIX , typename VECTOR >
void	setCovMatrixAndMean (const MATRIX &new_cov, const VECTOR &new_mean)
	Set the NxN covariance matrix that will determine the aspect of the ellipsoid - Notice that the covariance determines the uncertainty in the parameter space, which would be transformed by derived function. More...
const cov_matrix_t &	getCovMatrix () const
	Gets the current uncertainty covariance of parameter space. More...
void	setQuantiles (float q)
	Changes the scale of the "sigmas" for drawing the ellipse/ellipsoid (default=3, ~97 or ~98% CI); the exact mathematical meaning is: This value of "quantiles" q should be set to the square root of the chi-squared inverse cdf corresponding to the desired confidence interval. More...
float	getQuantiles () const
	Refer to documentation of setQuantiles() More...
void	setLineWidth (float w)
	The line width for 2D ellipses or 3D wireframe ellipsoids (default=1) More...
float	getLineWidth () const
void	setNumberOfSegments (const uint32_t numSegments)
	Set the number of segments of the surface/curve (higher means with greater resolution) More...
uint32_t	getNumberOfSegments ()
void	render_dl () const override
	Render If one of the eigen value of the covariance matrix of the ellipsoid is null, ellipsoid will not be rendered to ensure stability in the rendering process. More...
virtual void	getBoundingBox (mrpt::math::TPoint3D &bb_min, mrpt::math::TPoint3D &bb_max) const override
	Evaluates the bounding box of this object (including possible children) in the coordinate frame of the object parent. More...
virtual bool	traceRay (const mrpt::poses::CPose3D &o, double &dist) const override
	Ray tracing. More...
void	render () const override
	Render the object, regenerating the display list if needed, otherwise just calling it. More...
virtual mxArray *	writeToMatlab () const
	Introduces a pure virtual method responsible for writing to a mxArray Matlab object, typically a MATLAB struct whose contents are documented in each derived class. More...
virtual CObject *	clone () const =0
	Returns a deep copy (clone) of the object, indepently of its class. More...
Changes the appearance of the object to render (methods from
CRenderizable that need to be redefined)
CRenderizable &	setColorR_u8 (const uint8_t r) override
	Color components in the range [0,255]. More...
CRenderizable &	setColorG_u8 (const uint8_t g) override
	Color components in the range [0,255]. More...
CRenderizable &	setColorB_u8 (const uint8_t b) override
	Color components in the range [0,255]. More...
CRenderizable &	setColorA_u8 (const uint8_t a) override
	Color components in the range [0,255]. More...
CRenderizable &	setColor_u8 (const mrpt::utils::TColor &c) override
	Changes the default object color. More...
CRenderizable &	setColor_u8 (uint8_t R, uint8_t G, uint8_t B, uint8_t A=255)
	Color components in the range [0,255]. More...
Changes the appearance of the object to render
void	setName (const std::string &n)
	Changes the name of the object. More...
const std::string &	getName () const
	Returns the name of the object. More...
bool	isVisible () const
	Is the object visible? More...
void	setVisibility (bool visible=true)
	Set object visibility (default=true) More...
void	enableShowName (bool showName=true)
	Enables or disables showing the name of the object as a label when rendering. More...
bool	isShowNameEnabled () const
CRenderizable &	setPose (const mrpt::poses::CPose3D &o)
	Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this) More...
CRenderizable &	setPose (const mrpt::poses::CPose2D &o)
	Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this) More...
CRenderizable &	setPose (const mrpt::math::TPose3D &o)
	Set the 3D pose from a mrpt::math::TPose3D object (return a ref to this) More...
CRenderizable &	setPose (const mrpt::math::TPose2D &o)
	Set the 3D pose from a mrpt::math::TPose3D object (return a ref to this) More...
CRenderizable &	setPose (const mrpt::poses::CPoint3D &o)
	Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this) More...
CRenderizable &	setPose (const mrpt::poses::CPoint2D &o)
	Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this) More...
mrpt::math::TPose3D	getPose () const
	Returns the 3D pose of the object as TPose3D. More...
const mrpt::poses::CPose3D &	getPoseRef () const
	Returns a const ref to the 3D pose of the object as mrpt::poses::CPose3D (which explicitly contains the 3x3 rotation matrix) More...
CRenderizable &	setLocation (double x, double y, double z)
	Changes the location of the object, keeping untouched the orientation. More...
CRenderizable &	setLocation (const mrpt::math::TPoint3D &p)
	Changes the location of the object, keeping untouched the orientation. More...
double	getPoseX () const
	Translation relative to parent coordinate origin. More...
double	getPoseY () const
	Translation relative to parent coordinate origin. More...
double	getPoseZ () const
	Translation relative to parent coordinate origin. More...
double	getPoseYaw () const
	Rotation relative to parent coordinate origin, in DEGREES. More...
double	getPosePitch () const
	Rotation relative to parent coordinate origin, in DEGREES. More...
double	getPoseRoll () const
	Rotation relative to parent coordinate origin, in DEGREES. More...
double	getPoseYawRad () const
	Rotation relative to parent coordinate origin, in radians. More...
double	getPosePitchRad () const
	Rotation relative to parent coordinate origin, in radians. More...
double	getPoseRollRad () const
	Rotation relative to parent coordinate origin, in radians. More...
double	getColorR () const
	Color components in the range [0,1]. More...
double	getColorG () const
	Color components in the range [0,1]. More...
double	getColorB () const
	Color components in the range [0,1]. More...
double	getColorA () const
	Color components in the range [0,1]. More...
uint8_t	getColorR_u8 () const
	Color components in the range [0,255]. More...
uint8_t	getColorG_u8 () const
	Color components in the range [0,255]. More...
uint8_t	getColorB_u8 () const
	Color components in the range [0,255]. More...
uint8_t	getColorA_u8 () const
	Color components in the range [0,255]. More...
CRenderizable &	setColorR (const double r)
	Color components in the range [0,1]. More...
CRenderizable &	setColorG (const double g)
	Color components in the range [0,1]. More...
CRenderizable &	setColorB (const double b)
	Color components in the range [0,1]. More...
CRenderizable &	setColorA (const double a)
	Color components in the range [0,1]. More...
CRenderizable &	setScale (float s)
	Scale to apply to the object, in all three axes (default=1) More...
CRenderizable &	setScale (float sx, float sy, float sz)
	Scale to apply to the object in each axis (default=1) More...
float	getScaleX () const
	Get the current scaling factor in one axis. More...
float	getScaleY () const
	Get the current scaling factor in one axis. More...
float	getScaleZ () const
	Get the current scaling factor in one axis. More...
mrpt::utils::TColorf	getColor () const
	Returns the object color property as a TColorf. More...
CRenderizable &	setColor (const mrpt::utils::TColorf &c)
	Changes the default object color. More...
CRenderizable &	setColor (double R, double G, double B, double A=1)
	Set the color components of this object (R,G,B,Alpha, in the range 0-1) More...
const mrpt::utils::TColor &	getColor_u8 () const
	Returns the object color property as a TColor. More...
RTTI classes and functions
mrpt::utils::CObject::Ptr	duplicateGetSmartPtr () const
	Returns a copy of the object, indepently of its class, as a smart pointer (the newly created object will exist as long as any copy of this smart pointer). More...

Static Public Member Functions
static void	renderTextBitmap (const char *str, void *fontStyle)
	This method is safe for calling from within ::render() methods. More...
static void	renderTextBitmap (int screen_x, int screen_y, const std::string &str, float color_r=1, float color_g=1, float color_b=1, mrpt::opengl::TOpenGLFont font=mrpt::opengl::MRPT_GLUT_BITMAP_TIMES_ROMAN_24)
	Render a text message in the current rendering context, creating a glViewport in the way (do not call within ::render() methods) More...
static int	textBitmapWidth (const std::string &str, mrpt::opengl::TOpenGLFont font=mrpt::opengl::MRPT_GLUT_BITMAP_TIMES_ROMAN_24)
	Return the exact width in pixels for a given string, as will be rendered by renderTextBitmap(). More...

Protected Member Functions
virtual void	transformFromParameterSpace (const std::vector< array_point_t > &params_pts, std::vector< array_point_t > &out_pts) const =0
	To be implemented by derived classes: maps, using some arbitrary space transformation, a list of points defining an ellipsoid in parameter space into their corresponding points in 2D/3D space. More...
void	thisclass_writeToStream (mrpt::utils::CStream &out) const
void	thisclass_readFromStream (mrpt::utils::CStream &in)
	CGeneralizedEllipsoidTemplate ()
virtual	~CGeneralizedEllipsoidTemplate ()
void	writeToStreamRender (utils::CStream &out) const
virtual void	writeToStream (mrpt::utils::CStream &out, int *getVersion) const =0
	Introduces a pure virtual method responsible for writing to a CStream. More...
virtual void	readFromStream (mrpt::utils::CStream &in, int version)=0
	Introduces a pure virtual method responsible for loading from a CStream This can not be used directly be users, instead use "stream >> object;" for reading it from a stream or "stream >> object_ptr;" if the class is unknown apriori. More...
Methods accesible or implemented by derived classes
EIGEN_STRONG_INLINE void	notifyChange () const
	Must be called to notify that the object has changed (so, the display list must be updated) More...
virtual bool	should_skip_display_list_cache () const
	Optional: If the object has some state in which creating a display list is NOT preferred over direct rendering, implement this method and return "true" in those cases. More...
void	readFromStreamRender (mrpt::utils::CStream &in)

Static Protected Member Functions
static void	checkOpenGLError ()
	Checks glGetError and throws an exception if an error situation is found. More...
static unsigned int	getNewTextureNumber ()
	Returns the lowest next free texture name (avoid using OpenGL's own function since we may call them from different threads and seem it's not cool). More...
static void	releaseTextureName (unsigned int i)

Protected Attributes
cov_matrix_t	m_cov
mean_vector_t	m_mean
bool	m_needToRecomputeEigenVals
float	m_quantiles
	The number of "sigmas" for drawing the ellipse/ellipsoid (default=3) More...
float	m_lineWidth
	The line width for 2D ellipses or 3D wireframe ellipsoids (default=1) More...
uint32_t	m_numSegments
	Number of segments in 2D/3D ellipsoids (default=10) More...
mrpt::math::TPoint3D	m_bb_min
mrpt::math::TPoint3D	m_bb_max
cov_matrix_t	m_U
	Cholesky U triangular matrix cache. More...
std::string	m_name
bool	m_show_name
mrpt::utils::TColor	m_color
	Color components in the range [0,255]. More...
mrpt::poses::CPose3D	m_pose
	6D pose wrt the parent coordinate reference. More...
float	m_scale_x
	Scale components to apply to the object (default=1) More...
float	m_scale_y
float	m_scale_z
bool	m_visible
	Is the object visible? (default=true) More...

RTTI stuff
using	Ptr = std::shared_ptr< CRenderizableDisplayList >
using	ConstPtr = std::shared_ptr< const CRenderizableDisplayList >
virtual const mrpt::utils::TRuntimeClassId *	GetRuntimeClass () const override
	Returns information about the class of an object in runtime. More...
static const mrpt::utils::TRuntimeClassId	runtimeClassId
static const mrpt::utils::TRuntimeClassId *	_GetBaseClass ()
static const mrpt::utils::TRuntimeClassId &	GetRuntimeClassIdStatic ()

Member Typedef Documentation

array_parameter_t

template<int DIM>

typedef mrpt::math::CMatrixFixedNumeric<float, DIM, 1> mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::array_parameter_t

Definition at line 81 of file CGeneralizedEllipsoidTemplate.h.

array_point_t

template<int DIM>

typedef mrpt::math::CMatrixFixedNumeric<float, DIM, 1> mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::array_point_t

Definition at line 82 of file CGeneralizedEllipsoidTemplate.h.

ConstPtr

using mrpt::opengl::CRenderizableDisplayList::ConstPtr = std::shared_ptr<const CRenderizableDisplayList >

inherited

Definition at line 41 of file CRenderizableDisplayList.h.

cov_matrix_t

template<int DIM>

typedef mrpt::math::CMatrixFixedNumeric<double, DIM, DIM> mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::cov_matrix_t

The type of fixed-size covariance matrices for this representation.

Definition at line 77 of file CGeneralizedEllipsoidTemplate.h.

mean_vector_t

template<int DIM>

typedef mrpt::math::CMatrixFixedNumeric<double, DIM, 1> mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::mean_vector_t

The type of fixed-size vector for this representation.

Definition at line 79 of file CGeneralizedEllipsoidTemplate.h.

Ptr

using mrpt::opengl::CRenderizableDisplayList::Ptr = std::shared_ptr< CRenderizableDisplayList >

inherited

Definition at line 41 of file CRenderizableDisplayList.h.

Constructor & Destructor Documentation

CGeneralizedEllipsoidTemplate()

template<int DIM>

mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::CGeneralizedEllipsoidTemplate ( )

inlineprotected

Definition at line 294 of file CGeneralizedEllipsoidTemplate.h.

~CGeneralizedEllipsoidTemplate()

template<int DIM>

virtual mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::~CGeneralizedEllipsoidTemplate ( )

inlineprotectedvirtual

Definition at line 303 of file CGeneralizedEllipsoidTemplate.h.

Member Function Documentation

_GetBaseClass()

static const mrpt::utils::TRuntimeClassId* mrpt::opengl::CRenderizableDisplayList::_GetBaseClass ( )

staticprotectedinherited

checkOpenGLError()

void CRenderizable::checkOpenGLError ( )

staticprotectedinherited

Checks glGetError and throws an exception if an error situation is found.

Definition at line 302 of file CRenderizable.cpp.

References mrpt::opengl::gl_utils::checkOpenGLError().

Referenced by mrpt::opengl::CTexturedObject::loadTextureInOpenGL(), mrpt::opengl::COpenGLViewport::render(), mrpt::opengl::CBox::render_dl(), mrpt::opengl::CSimpleLine::render_dl(), mrpt::opengl::CGridPlaneXY::render_dl(), mrpt::opengl::CGridPlaneXZ::render_dl(), mrpt::opengl::CPlanarLaserScan::render_dl(), mrpt::opengl::CSetOfLines::render_dl(), mrpt::opengl::CVectorField2D::render_dl(), mrpt::opengl::CVectorField3D::render_dl(), mrpt::opengl::CPolyhedron::render_dl(), mrpt::opengl::CTexturedObject::render_post(), mrpt::opengl::CTexturedObject::render_pre(), and mrpt::opengl::CTexturedPlane::render_texturedobj().

Here is the call graph for this function:

Here is the caller graph for this function:

clone()

virtual CObject* mrpt::utils::CObject::clone ( ) const

pure virtualinherited

Returns a deep copy (clone) of the object, indepently of its class.

Implemented in mrpt::obs::CObservation3DRangeScan, mrpt::nav::CLogFileRecord_ND, mrpt::nav::CLogFileRecord_FullEval, mrpt::maps::CMultiMetricMap, mrpt::utils::CSimpleDatabase, mrpt::utils::CImage, mrpt::obs::CObservationIMU, mrpt::maps::TMapGenericParams, mrpt::poses::CPose3D, mrpt::obs::CObservationRGBD360, mrpt::maps::CRandomFieldGridMap3D, mrpt::detectors::CDetectable3D, mrpt::hmtslam::THypothesisIDSet, mrpt::maps::CMultiMetricMapPDF, mrpt::hmtslam::CLocalMetricHypothesis, mrpt::obs::CObservationVelodyneScan, mrpt::maps::CLandmarksMap, mrpt::hmtslam::CHMTSLAM, mrpt::opengl::COctoMapVoxels, mrpt::kinematics::CKinematicChain, mrpt::maps::COccupancyGridMap2D, mrpt::obs::CObservationGPS, mrpt::obs::CRawlog, mrpt::opengl::COpenGLViewport, mrpt::maps::CHeightGridMap2D, mrpt::opengl::COpenGLScene, mrpt::opengl::CPlanarLaserScan, mrpt::nav::CHolonomicFullEval, mrpt::vision::CFeature, mrpt::nav::CHolonomicND, mrpt::obs::CObservation2DRangeScan, mrpt::obs::CSensoryFrame, mrpt::opengl::CFrustum, mrpt::poses::CPose2DInterpolator, mrpt::poses::CPose3DInterpolator, mrpt::nav::CHolonomicVFF, mrpt::opengl::CEllipsoidInverseDepth3D, mrpt::opengl::CPointCloud, mrpt::opengl::CPointCloudColoured, mrpt::pbmap::PbMap, mrpt::poses::CPose3DQuat, mrpt::pbmap::Plane, mrpt::opengl::CEllipsoid, mrpt::opengl::CEllipsoidInverseDepth2D, mrpt::poses::CPose3DQuatPDFGaussianInf, mrpt::detectors::CDetectable2D, mrpt::hmtslam::CLSLAMParticleData, mrpt::maps::CBeaconMap, mrpt::poses::CPose3DRotVec, mrpt::opengl::CText3D, mrpt::opengl::CVectorField3D, mrpt::poses::CPointPDFParticles, mrpt::poses::CPose3DQuatPDFGaussian, mrpt::opengl::CAngularObservationMesh, mrpt::opengl::CEllipsoidRangeBearing2D, mrpt::opengl::CPolyhedron, mrpt::poses::CPose3DPDFGaussianInf, mrpt::maps::CReflectivityGridMap2D, mrpt::obs::CObservationStereoImages, mrpt::opengl::CAssimpModel, mrpt::maps::CBeacon, mrpt::nav::CPTG_DiffDrive_C, mrpt::opengl::CBox, mrpt::poses::CPose2D, mrpt::opengl::CMeshFast, mrpt::poses::CPose3DPDFGaussian, mrpt::hmtslam::CHMHMapNode, mrpt::hmtslam::CRobotPosesGraph, mrpt::obs::CObservationStereoImagesFeatures, mrpt::opengl::CMesh, mrpt::utils::CMHPropertiesValuesList, mrpt::opengl::CMesh3D, mrpt::opengl::CText, mrpt::poses::CPosePDFGaussianInf, mrpt::maps::CHeightGridMap2D_MRF, mrpt::nav::CPTG_DiffDrive_alpha, mrpt::maps::CRBPFParticleData, mrpt::poses::CPoint2D, mrpt::poses::CPointPDFSOG, mrpt::poses::CPose3DPDFParticles, mrpt::poses::CPosePDFParticles, mrpt::poses::CPosePDFSOG, mrpt::hmtslam::CHMHMapArc, mrpt::opengl::CColorBar, mrpt::opengl::CVectorField2D, mrpt::poses::CPose3DPDFSOG, mrpt::maps::CGasConcentrationGridMap2D, mrpt::maps::CWirelessPowerGridMap2D, mrpt::maps::CSimpleMap, mrpt::obs::CObservationImage, mrpt::opengl::CSetOfLines, mrpt::maps::CLandmark, mrpt::hmtslam::CHierarchicalMHMap, mrpt::maps::COctoMap, mrpt::obs::CActionRobotMovement2D, mrpt::obs::CObservationBatteryState, mrpt::opengl::CDisk, mrpt::poses::CPoint3D, mrpt::utils::CStringList, mrpt::utils::TCamera, mrpt::obs::CObservationOdometry, mrpt::obs::CObservationRawDAQ, mrpt::opengl::CCamera, mrpt::opengl::CCylinder, mrpt::opengl::CGridPlaneXY, mrpt::opengl::CGridPlaneXZ, mrpt::poses::CPosePDFGaussian, mrpt::maps::CColouredOctoMap, mrpt::maps::CSimplePointsMap, mrpt::nav::CLogFileRecord, mrpt::obs::CObservationBearingRange, mrpt::obs::CObservationWindSensor, mrpt::opengl::CArrow, mrpt::opengl::CAxis, mrpt::opengl::CGeneralizedCylinder, mrpt::opengl::CSphere, mrpt::slam::CIncrementalMapPartitioner, mrpt::maps::CColouredPointsMap, mrpt::maps::CWeightedPointsMap, mrpt::obs::CObservationRange, mrpt::opengl::CSetOfObjects, mrpt::obs::CActionCollection, mrpt::obs::CActionRobotMovement3D, mrpt::obs::CObservationWirelessPower, mrpt::opengl::CSetOfTexturedTriangles, mrpt::math::CSplineInterpolator1D, mrpt::nav::CLogFileRecord_VFF, mrpt::nav::CMultiObjMotionOpt_Scalarization, mrpt::nav::CPTG_Holo_Blend, mrpt::obs::CObservation6DFeatures, mrpt::obs::CObservationSkeleton, mrpt::obs::CObservationVisualLandmarks, mrpt::poses::CPosePDFGrid, mrpt::nav::CPTG_DiffDrive_CC, mrpt::nav::CPTG_DiffDrive_CCS, mrpt::nav::CPTG_DiffDrive_CS, mrpt::obs::CObservationBeaconRanges, mrpt::obs::CObservationComment, mrpt::obs::CObservationGasSensors, mrpt::obs::CObservationReflectivity, mrpt::obs::CObservationRFID, mrpt::math::CMatrixD, mrpt::poses::CPoses2DSequence, mrpt::poses::CPoses3DSequence, mrpt::opengl::C3DSScene, mrpt::opengl::COpenGLStandardObject, mrpt::math::CMatrix, mrpt::poses::CPointPDFGaussian, mrpt::utils::TStereoCamera, mrpt::opengl::CSetOfTriangles, mrpt::math::CMatrixB, mrpt::poses::TSimple3DPoint, mrpt::utils::CMemoryChunk, mrpt::utils::CPropertiesValuesList, mrpt::obs::CObservationCANBusJ1939, mrpt::obs::CObservationRobotPose, mrpt::math::CPolygon, mrpt::poses::CPoint2DPDFGaussian, mrpt::utils::CSimpleDatabaseTable, mrpt::utils::CTypeSelector, mrpt::opengl::CSimpleLine, mrpt::opengl::CTexturedPlane, mrpt::kinematics::CVehicleVelCmd_DiffDriven, and mrpt::kinematics::CVehicleVelCmd_Holo.

Referenced by mrpt::utils::CObject::duplicateGetSmartPtr(), mrpt::maps::CSimpleMap::insert(), mrpt::obs::CActionCollection::insert(), and mrpt::poses::CPoseRandomSampler::setPosePDF().

Here is the caller graph for this function:

enableShowName()

void mrpt::opengl::CRenderizable::enableShowName ( bool  showName = true )

inlineinherited

Enables or disables showing the name of the object as a label when rendering.

Definition at line 85 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_show_name.

getBoundingBox()

template<int DIM>

virtual void mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::getBoundingBox ( mrpt::math::TPoint3D &  bb_min, mrpt::math::TPoint3D &  bb_max  ) const

inlineoverridevirtual

Evaluates the bounding box of this object (including possible children) in the coordinate frame of the object parent.

Implements mrpt::opengl::CRenderizable.

Definition at line 225 of file CGeneralizedEllipsoidTemplate.h.

getColor()

mrpt::utils::TColorf mrpt::opengl::CRenderizable::getColor ( ) const

inlineinherited

Returns the object color property as a TColorf.

Definition at line 243 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_color.

Referenced by mrpt::maps::COctoMap::getAsOctoMapVoxels(), and mrpt::maps::CColouredOctoMap::getAsOctoMapVoxels().

Here is the caller graph for this function:

getColor_u8()

const mrpt::utils::TColor& mrpt::opengl::CRenderizable::getColor_u8 ( ) const

inlineinherited

Returns the object color property as a TColor.

Definition at line 263 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_color.

getColorA()

double mrpt::opengl::CRenderizable::getColorA ( ) const

inlineinherited

Color components in the range [0,1].

Definition at line 166 of file CRenderizable.h.

References mrpt::utils::TColor::A, and mrpt::opengl::CRenderizable::m_color.

Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().

Here is the caller graph for this function:

getColorA_u8()

uint8_t mrpt::opengl::CRenderizable::getColorA_u8 ( ) const

inlineinherited

Color components in the range [0,255].

Definition at line 174 of file CRenderizable.h.

References mrpt::utils::TColor::A, and mrpt::opengl::CRenderizable::m_color.

getColorB()

double mrpt::opengl::CRenderizable::getColorB ( ) const

inlineinherited

Color components in the range [0,1].

Definition at line 164 of file CRenderizable.h.

References mrpt::utils::TColor::B, and mrpt::opengl::CRenderizable::m_color.

Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().

Here is the caller graph for this function:

getColorB_u8()

uint8_t mrpt::opengl::CRenderizable::getColorB_u8 ( ) const

inlineinherited

Color components in the range [0,255].

Definition at line 172 of file CRenderizable.h.

References mrpt::utils::TColor::B, and mrpt::opengl::CRenderizable::m_color.

getColorG()

double mrpt::opengl::CRenderizable::getColorG ( ) const

inlineinherited

Color components in the range [0,1].

Definition at line 162 of file CRenderizable.h.

References mrpt::utils::TColor::G, and mrpt::opengl::CRenderizable::m_color.

Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().

Here is the caller graph for this function:

getColorG_u8()

uint8_t mrpt::opengl::CRenderizable::getColorG_u8 ( ) const

inlineinherited

Color components in the range [0,255].

Definition at line 170 of file CRenderizable.h.

References mrpt::utils::TColor::G, and mrpt::opengl::CRenderizable::m_color.

getColorR()

double mrpt::opengl::CRenderizable::getColorR ( ) const

inlineinherited

Color components in the range [0,1].

Definition at line 160 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_color, and mrpt::utils::TColor::R.

Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().

Here is the caller graph for this function:

getColorR_u8()

uint8_t mrpt::opengl::CRenderizable::getColorR_u8 ( ) const

inlineinherited

Color components in the range [0,255].

Definition at line 168 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_color, and mrpt::utils::TColor::R.

getCovMatrix()

template<int DIM>

const cov_matrix_t& mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::getCovMatrix ( ) const

inline

Gets the current uncertainty covariance of parameter space.

Definition at line 104 of file CGeneralizedEllipsoidTemplate.h.

getLineWidth()

template<int DIM>

float mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::getLineWidth ( ) const

inline

Definition at line 145 of file CGeneralizedEllipsoidTemplate.h.

getName()

const std::string& mrpt::opengl::CRenderizable::getName ( ) const

inlineinherited

Returns the name of the object.

Definition at line 70 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_name.

Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().

Here is the caller graph for this function:

getNewTextureNumber()

unsigned int CRenderizable::getNewTextureNumber ( )

staticprotectedinherited

Returns the lowest next free texture name (avoid using OpenGL's own function since we may call them from different threads and seem it's not cool).

Returns the lowest, free texture name.

Definition at line 73 of file CRenderizable.cpp.

References TOpenGLNameBooker::instance(), MAX_GL_TEXTURE_IDS, MAX_GL_TEXTURE_IDS_MASK, MRPT_END, MRPT_START, and THROW_EXCEPTION_FMT.

Referenced by mrpt::opengl::CTexturedObject::loadTextureInOpenGL().

Here is the call graph for this function:

Here is the caller graph for this function:

getNumberOfSegments()

template<int DIM>

uint32_t mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::getNumberOfSegments ( )

inline

Definition at line 153 of file CGeneralizedEllipsoidTemplate.h.

getPose()

mrpt::math::TPose3D CRenderizable::getPose ( ) const

inherited

Returns the 3D pose of the object as TPose3D.

Definition at line 347 of file CRenderizable.cpp.

References mrpt::opengl::CRenderizable::m_pose.

getPosePitch()

double mrpt::opengl::CRenderizable::getPosePitch ( ) const

inlineinherited

Rotation relative to parent coordinate origin, in DEGREES.

Definition at line 144 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_pose, mrpt::poses::CPose3D::pitch(), and mrpt::mrpt::utils::RAD2DEG().

Here is the call graph for this function:

getPosePitchRad()

double mrpt::opengl::CRenderizable::getPosePitchRad ( ) const

inlineinherited

Rotation relative to parent coordinate origin, in radians.

Definition at line 156 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_pose, and mrpt::poses::CPose3D::pitch().

Here is the call graph for this function:

getPoseRef()

const mrpt::poses::CPose3D& mrpt::opengl::CRenderizable::getPoseRef ( ) const

inlineinherited

Returns a const ref to the 3D pose of the object as mrpt::poses::CPose3D (which explicitly contains the 3x3 rotation matrix)

Definition at line 111 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_pose.

Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().

Here is the caller graph for this function:

getPoseRoll()

double mrpt::opengl::CRenderizable::getPoseRoll ( ) const

inlineinherited

Rotation relative to parent coordinate origin, in DEGREES.

Definition at line 149 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_pose, mrpt::mrpt::utils::RAD2DEG(), and mrpt::poses::CPose3D::roll().

Here is the call graph for this function:

getPoseRollRad()

double mrpt::opengl::CRenderizable::getPoseRollRad ( ) const

inlineinherited

Rotation relative to parent coordinate origin, in radians.

Definition at line 158 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_pose, and mrpt::poses::CPose3D::roll().

Here is the call graph for this function:

getPoseX()

double mrpt::opengl::CRenderizable::getPoseX ( ) const

inlineinherited

Translation relative to parent coordinate origin.

Definition at line 133 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_pose, and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x().

Here is the call graph for this function:

getPoseY()

double mrpt::opengl::CRenderizable::getPoseY ( ) const

inlineinherited

Translation relative to parent coordinate origin.

Definition at line 135 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_pose, and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y().

Here is the call graph for this function:

getPoseYaw()

double mrpt::opengl::CRenderizable::getPoseYaw ( ) const

inlineinherited

Rotation relative to parent coordinate origin, in DEGREES.

Definition at line 139 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_pose, mrpt::mrpt::utils::RAD2DEG(), and mrpt::poses::CPose3D::yaw().

Here is the call graph for this function:

getPoseYawRad()

double mrpt::opengl::CRenderizable::getPoseYawRad ( ) const

inlineinherited

Rotation relative to parent coordinate origin, in radians.

Definition at line 154 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_pose, and mrpt::poses::CPose3D::yaw().

Here is the call graph for this function:

getPoseZ()

double mrpt::opengl::CRenderizable::getPoseZ ( ) const

inlineinherited

Translation relative to parent coordinate origin.

Definition at line 137 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_pose.

getQuantiles()

template<int DIM>

float mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::getQuantiles ( ) const

inline

Refer to documentation of setQuantiles()

Definition at line 138 of file CGeneralizedEllipsoidTemplate.h.

GetRuntimeClass()

virtual const mrpt::utils::TRuntimeClassId* mrpt::opengl::CRenderizableDisplayList::GetRuntimeClass ( ) const

overridevirtualinherited

Returns information about the class of an object in runtime.

Reimplemented from mrpt::opengl::CRenderizable.

Reimplemented in mrpt::opengl::COctoMapVoxels, mrpt::opengl::CPlanarLaserScan, mrpt::opengl::CFrustum, mrpt::opengl::CEllipsoidInverseDepth3D, mrpt::opengl::CEllipsoid, mrpt::opengl::CEllipsoidInverseDepth2D, mrpt::opengl::CText3D, mrpt::opengl::CVectorField3D, mrpt::opengl::CAngularObservationMesh, mrpt::opengl::CEllipsoidRangeBearing2D, mrpt::opengl::CPolyhedron, mrpt::opengl::CAssimpModel, mrpt::opengl::CBox, mrpt::opengl::CMeshFast, mrpt::opengl::CMesh, mrpt::opengl::CMesh3D, mrpt::opengl::CColorBar, mrpt::opengl::CVectorField2D, mrpt::opengl::CSetOfLines, mrpt::opengl::CDisk, mrpt::opengl::CCylinder, mrpt::opengl::CGridPlaneXY, mrpt::opengl::CGridPlaneXZ, mrpt::opengl::CArrow, mrpt::opengl::CAxis, mrpt::opengl::CGeneralizedCylinder, mrpt::opengl::CSphere, mrpt::opengl::CSetOfTexturedTriangles, mrpt::opengl::C3DSScene, mrpt::opengl::COpenGLStandardObject, mrpt::opengl::CSetOfTriangles, mrpt::opengl::CTexturedObject, mrpt::opengl::CSimpleLine, and mrpt::opengl::CTexturedPlane.

GetRuntimeClassIdStatic()

static const mrpt::utils::TRuntimeClassId& mrpt::opengl::CRenderizableDisplayList::GetRuntimeClassIdStatic ( )

staticinherited

getScaleX()

float mrpt::opengl::CRenderizable::getScaleX ( ) const

inlineinherited

Get the current scaling factor in one axis.

Definition at line 237 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_scale_x.

Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().

Here is the caller graph for this function:

getScaleY()

float mrpt::opengl::CRenderizable::getScaleY ( ) const

inlineinherited

Get the current scaling factor in one axis.

Definition at line 239 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_scale_y.

Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().

Here is the caller graph for this function:

getScaleZ()

float mrpt::opengl::CRenderizable::getScaleZ ( ) const

inlineinherited

Get the current scaling factor in one axis.

Definition at line 241 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_scale_z.

Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().

Here is the caller graph for this function:

isShowNameEnabled()

bool mrpt::opengl::CRenderizable::isShowNameEnabled ( ) const

inlineinherited

See also

enableShowName

Definition at line 87 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_show_name.

Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().

Here is the caller graph for this function:

isVisible()

bool mrpt::opengl::CRenderizable::isVisible ( ) const

inlineinherited

Is the object visible?

See also

setVisibility

Definition at line 71 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_visible.

Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().

Here is the caller graph for this function:

notifyChange()

EIGEN_STRONG_INLINE void mrpt::opengl::CRenderizableDisplayList::notifyChange ( ) const

inlineprotectedinherited

Must be called to notify that the object has changed (so, the display list must be updated)

Definition at line 57 of file CRenderizableDisplayList.h.

References mrpt::opengl::CRenderizableDisplayList::m_dl_recreate.

Referenced by mrpt::opengl::CGeneralizedCylinder::addVisibleSectionAtEnd(), mrpt::opengl::CGeneralizedCylinder::addVisibleSectionAtStart(), mrpt::opengl::CMeshFast::adjustGridToImageAR(), mrpt::opengl::CMesh::adjustGridToImageAR(), mrpt::opengl::CVectorField2D::adjustVectorFieldToGrid(), mrpt::opengl::CSetOfLines::appendLine(), mrpt::opengl::CSetOfLines::appendLines(), mrpt::opengl::CTexturedObject::assignImage(), mrpt::opengl::CMeshFast::assignImage(), mrpt::opengl::CMesh::assignImage(), mrpt::opengl::CTexturedObject::assignImage_fast(), mrpt::opengl::CMeshFast::assignImageAndZ(), mrpt::opengl::CMesh::assignImageAndZ(), mrpt::opengl::CSetOfLines::begin(), mrpt::opengl::CSetOfLines::clear(), mrpt::opengl::C3DSScene::clear(), mrpt::opengl::CVectorField2D::clear(), mrpt::opengl::CAssimpModel::clear(), mrpt::opengl::CPlanarLaserScan::clear(), mrpt::opengl::CVectorField3D::clear(), mrpt::opengl::COctoMapVoxels::clear(), mrpt::opengl::CSetOfTexturedTriangles::clearTriangles(), mrpt::opengl::CSetOfTriangles::clearTriangles(), mrpt::opengl::COpenGLStandardObject::disable(), mrpt::opengl::COpenGLStandardObject::enable(), mrpt::opengl::CSimpleLine::enableAntiAliasing(), mrpt::opengl::CGridPlaneXY::enableAntiAliasing(), mrpt::opengl::CGridPlaneXZ::enableAntiAliasing(), mrpt::opengl::CMesh3D::enableAntiAliasing(), mrpt::opengl::CVectorField2D::enableAntiAliasing(), mrpt::opengl::CSetOfLines::enableAntiAliasing(), mrpt::opengl::CVectorField3D::enableAntiAliasing(), mrpt::opengl::CBox::enableBoxBorder(), mrpt::opengl::CVectorField3D::enableColorFromModule(), mrpt::opengl::CMeshFast::enableColorFromZ(), mrpt::opengl::CMesh::enableColorFromZ(), mrpt::opengl::COctoMapVoxels::enableCubeTransparency(), mrpt::opengl::CColorBar::enableDepthTest(), mrpt::opengl::CEllipsoid::enableDrawSolid3D(), mrpt::opengl::C3DSScene::enableExtraAmbientLight(), mrpt::opengl::CMesh3D::enableFaceNormals(), mrpt::opengl::COctoMapVoxels::enableLights(), mrpt::opengl::CPlanarLaserScan::enableLine(), mrpt::opengl::CPlanarLaserScan::enablePoints(), mrpt::opengl::CSphere::enableRadiusIndependentOfEyeDistance(), mrpt::opengl::CMesh3D::enableShowEdges(), mrpt::opengl::CMesh3D::enableShowFaces(), mrpt::opengl::CVectorField3D::enableShowPoints(), mrpt::opengl::CMesh3D::enableShowVertices(), mrpt::opengl::CPlanarLaserScan::enableSurface(), mrpt::opengl::CAxis::enableTickMarks(), mrpt::opengl::CMesh3D::enableTransparency(), mrpt::opengl::CMeshFast::enableTransparency(), mrpt::opengl::CMesh::enableTransparency(), mrpt::opengl::CSetOfTriangles::enableTransparency(), mrpt::opengl::CAngularObservationMesh::enableTransparency(), mrpt::opengl::CMesh::enableWireFrame(), mrpt::opengl::CSetOfLines::end(), mrpt::opengl::C3DSScene::evaluateAnimation(), mrpt::opengl::COctoMapVoxels::getGridCubeRef(), mrpt::opengl::CSetOfTexturedTriangles::getTriangle(), mrpt::opengl::COctoMapVoxels::getVoxel(), mrpt::opengl::COctoMapVoxels::getVoxelRef(), mrpt::opengl::CSetOfTexturedTriangles::insertTriangle(), mrpt::opengl::CSetOfTriangles::insertTriangle(), mrpt::opengl::CSetOfTriangles::insertTriangles(), mrpt::opengl::C3DSScene::loadFrom3DSFile(), mrpt::opengl::CMesh3D::loadMesh(), mrpt::opengl::CAssimpModel::loadScene(), mrpt::opengl::COctoMapVoxels::push_back_GridCube(), mrpt::opengl::COctoMapVoxels::push_back_Voxel(), mrpt::opengl::CSimpleLine::readFromStream(), mrpt::opengl::CTexturedPlane::readFromStream(), mrpt::opengl::CSetOfTriangles::readFromStream(), mrpt::opengl::C3DSScene::readFromStream(), mrpt::opengl::COpenGLStandardObject::readFromStream(), mrpt::opengl::CArrow::readFromStream(), mrpt::opengl::CAxis::readFromStream(), mrpt::opengl::CSphere::readFromStream(), mrpt::opengl::CCylinder::readFromStream(), mrpt::opengl::CGridPlaneXY::readFromStream(), mrpt::opengl::CGridPlaneXZ::readFromStream(), mrpt::opengl::CDisk::readFromStream(), mrpt::opengl::CSetOfLines::readFromStream(), mrpt::opengl::CColorBar::readFromStream(), mrpt::opengl::CVectorField2D::readFromStream(), mrpt::opengl::CMesh::readFromStream(), mrpt::opengl::CMeshFast::readFromStream(), mrpt::opengl::CBox::readFromStream(), mrpt::opengl::CAssimpModel::readFromStream(), mrpt::opengl::CPolyhedron::readFromStream(), mrpt::opengl::CText3D::readFromStream(), mrpt::opengl::CVectorField3D::readFromStream(), mrpt::opengl::CEllipsoid::readFromStream(), mrpt::opengl::CFrustum::readFromStream(), mrpt::opengl::COctoMapVoxels::readFromStream(), mrpt::opengl::CRenderizableDisplayList::readFromStreamRender(), mrpt::opengl::CTexturedObject::readFromStreamTexturedObject(), mrpt::opengl::CSetOfTriangles::reserve(), mrpt::opengl::CSetOfLines::reserve(), mrpt::opengl::COctoMapVoxels::reserveVoxels(), mrpt::opengl::CSetOfLines::resize(), mrpt::opengl::CVectorField2D::resize(), mrpt::opengl::CVectorField3D::resize(), mrpt::opengl::COctoMapVoxels::resizeGridCubes(), mrpt::opengl::COctoMapVoxels::resizeVoxels(), mrpt::opengl::COctoMapVoxels::resizeVoxelSets(), mrpt::opengl::CEllipsoid::set2DsegmentsCount(), mrpt::opengl::CEllipsoid::set3DsegmentsCount(), mrpt::opengl::CGeneralizedCylinder::setAllSectionsInvisible(), mrpt::opengl::CGeneralizedCylinder::setAllSectionsVisible(), mrpt::opengl::CArrow::setArrowEnds(), mrpt::opengl::CArrow::setArrowYawPitchRoll(), mrpt::opengl::CGeneralizedCylinder::setAxis(), mrpt::opengl::CAxis::setAxisLimits(), mrpt::opengl::CBox::setBoxBorderColor(), mrpt::opengl::CBox::setBoxCorners(), mrpt::opengl::CGeneralizedCylinder::setClosed(), mrpt::opengl::CRenderizableDisplayList::setColor_u8(), mrpt::opengl::CSetOfTriangles::setColor_u8(), mrpt::opengl::CRenderizableDisplayList::setColorA_u8(), mrpt::opengl::CSetOfTriangles::setColorA_u8(), mrpt::opengl::CColorBar::setColorAndValueLimits(), mrpt::opengl::CRenderizableDisplayList::setColorB_u8(), mrpt::opengl::CSetOfTriangles::setColorB_u8(), mrpt::opengl::CRenderizableDisplayList::setColorG_u8(), mrpt::opengl::CSetOfTriangles::setColorG_u8(), mrpt::opengl::CColorBar::setColormap(), mrpt::opengl::CRenderizableDisplayList::setColorR_u8(), mrpt::opengl::CSetOfTriangles::setColorR_u8(), mrpt::opengl::CEllipsoid::setCovMatrix(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::setCovMatrixAndMean(), mrpt::opengl::CDisk::setDiskRadius(), mrpt::opengl::COpenGLStandardObject::setFlags(), mrpt::opengl::CText3D::setFont(), mrpt::opengl::CAxis::setFrequency(), mrpt::opengl::CGeneralizedCylinder::setGeneratrix(), mrpt::opengl::CVectorField2D::setGridCenterAndCellSize(), mrpt::opengl::CGridPlaneXZ::setGridFrequency(), mrpt::opengl::CGridPlaneXY::setGridFrequency(), mrpt::opengl::CMeshFast::setGridLimits(), mrpt::opengl::CMesh::setGridLimits(), mrpt::opengl::CVectorField2D::setGridLimits(), mrpt::opengl::COctoMapVoxels::setGridLinesColor(), mrpt::opengl::COctoMapVoxels::setGridLinesWidth(), mrpt::opengl::CCylinder::setHasBases(), mrpt::opengl::CArrow::setHeadRatio(), mrpt::opengl::CCylinder::setHeight(), mrpt::opengl::CFrustum::setHorzFOV(), mrpt::opengl::CFrustum::setHorzFOVAsymmetric(), mrpt::opengl::CArrow::setLargeRadius(), mrpt::opengl::CSetOfLines::setLineByIndex(), mrpt::opengl::CSimpleLine::setLineCoords(), mrpt::opengl::CSimpleLine::setLineWidth(), mrpt::opengl::CGridPlaneXY::setLineWidth(), mrpt::opengl::CGridPlaneXZ::setLineWidth(), mrpt::opengl::CAxis::setLineWidth(), mrpt::opengl::CSetOfLines::setLineWidth(), mrpt::opengl::CFrustum::setLineWidth(), mrpt::opengl::CBox::setLineWidth(), mrpt::opengl::CVectorField2D::setLineWidth(), mrpt::opengl::CEllipsoid::setLineWidth(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::setLineWidth(), mrpt::opengl::CVectorField3D::setLineWidth(), mrpt::opengl::CDisk::setLoopsCount(), mrpt::opengl::CMesh::setMask(), mrpt::opengl::CVectorField3D::setMaxSpeedForColor(), mrpt::opengl::CVectorField3D::setMotionFieldColormap(), mrpt::opengl::CFrustum::setNearFarPlanes(), mrpt::opengl::COpenGLStandardObject::setNormal(), mrpt::opengl::CSphere::setNumberDivsLatitude(), mrpt::opengl::CSphere::setNumberDivsLongitude(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::setNumberOfSegments(), mrpt::opengl::CFrustum::setPlaneColor(), mrpt::opengl::CTexturedPlane::setPlaneCorners(), mrpt::opengl::CGridPlaneXZ::setPlaneLimits(), mrpt::opengl::CGridPlaneXY::setPlaneLimits(), mrpt::opengl::CGridPlaneXZ::setPlaneYcoord(), mrpt::opengl::CGridPlaneXY::setPlaneZcoord(), mrpt::opengl::CVectorField2D::setPointColor(), mrpt::opengl::CVectorField3D::setPointColor(), mrpt::opengl::CVectorField3D::setPointCoordinates(), mrpt::opengl::CVectorField2D::setPointSize(), mrpt::opengl::CVectorField3D::setPointSize(), mrpt::opengl::CEllipsoid::setQuantiles(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::setQuantiles(), mrpt::opengl::CCylinder::setRadii(), mrpt::opengl::CSphere::setRadius(), mrpt::opengl::CCylinder::setRadius(), mrpt::opengl::CPlanarLaserScan::setScan(), mrpt::opengl::CDisk::setSlicesCount(), mrpt::opengl::CCylinder::setSlicesCount(), mrpt::opengl::CArrow::setSmallRadius(), mrpt::opengl::CCylinder::setStacksCount(), mrpt::opengl::CText3D::setString(), mrpt::opengl::CText3D::setTextKerning(), mrpt::opengl::CAxis::setTextScale(), mrpt::opengl::CText3D::setTextSpacing(), mrpt::opengl::CText3D::setTextStyle(), mrpt::opengl::CTexturedPlane::setTextureCornerCoords(), mrpt::opengl::CMesh::setUV(), mrpt::opengl::CVectorField2D::setVectorField(), mrpt::opengl::CVectorField3D::setVectorField(), mrpt::opengl::CVectorField2D::setVectorFieldColor(), mrpt::opengl::CVectorField3D::setVectorFieldColor(), mrpt::opengl::CFrustum::setVertFOV(), mrpt::opengl::CFrustum::setVertFOVAsymmetric(), mrpt::opengl::CSetOfLines::setVerticesPointSize(), mrpt::opengl::CGeneralizedCylinder::setVisibleSections(), mrpt::opengl::COctoMapVoxels::setVisualizationMode(), mrpt::opengl::COctoMapVoxels::setVoxelAsPointsSize(), mrpt::opengl::CBox::setWireframe(), mrpt::opengl::CAngularObservationMesh::setWireframe(), mrpt::opengl::CMeshFast::setXBounds(), mrpt::opengl::CMesh::setXBounds(), mrpt::opengl::CMeshFast::setXMax(), mrpt::opengl::CMesh::setXMax(), mrpt::opengl::CMeshFast::setXMin(), mrpt::opengl::CMesh::setXMin(), mrpt::opengl::CMeshFast::setYBounds(), mrpt::opengl::CMesh::setYBounds(), mrpt::opengl::CMeshFast::setYMax(), mrpt::opengl::CMesh::setYMax(), mrpt::opengl::CMeshFast::setYMin(), mrpt::opengl::CMesh::setYMin(), mrpt::opengl::CMeshFast::setZ(), mrpt::opengl::CMesh::setZ(), mrpt::opengl::COctoMapVoxels::showGridLines(), mrpt::opengl::COctoMapVoxels::showVoxels(), mrpt::opengl::COctoMapVoxels::showVoxelsAsPoints(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::thisclass_readFromStream(), mrpt::opengl::CMesh::updateColorsMatrix(), mrpt::opengl::CMeshFast::updateColorsMatrix(), mrpt::opengl::CMeshFast::updatePoints(), mrpt::opengl::CMesh::updatePolygons(), mrpt::opengl::CSetOfTriangles::updatePolygons(), and mrpt::opengl::CMesh::updateTriangles().

readFromStream()

virtual void mrpt::utils::CSerializable::readFromStream ( mrpt::utils::CStream &  in, int  version  )

protectedpure virtualinherited

Introduces a pure virtual method responsible for loading from a CStream This can not be used directly be users, instead use "stream >> object;" for reading it from a stream or "stream >> object_ptr;" if the class is unknown apriori.

Parameters

in	The input binary stream where the object data must read from.
version	The version of the object stored in the stream: use this version number in your code to know how to read the incoming data.

Exceptions

std::exception

On any error, see CStream::ReadBuffer

See also

CStream

Implemented in mrpt::obs::CObservation3DRangeScan, mrpt::nav::CLogFileRecord_ND, mrpt::nav::CLogFileRecord_FullEval, mrpt::maps::CMultiMetricMap, mrpt::utils::CSimpleDatabase, mrpt::utils::CImage, mrpt::obs::CObservationIMU, mrpt::maps::TMapGenericParams, mrpt::poses::CPose3D, mrpt::obs::CObservationRGBD360, mrpt::maps::CRandomFieldGridMap3D, mrpt::detectors::CDetectable3D, mrpt::hmtslam::THypothesisIDSet, mrpt::maps::CMultiMetricMapPDF, mrpt::hmtslam::CLocalMetricHypothesis, mrpt::obs::CObservationVelodyneScan, mrpt::maps::CLandmarksMap, mrpt::hmtslam::CHMTSLAM, mrpt::opengl::COctoMapVoxels, mrpt::kinematics::CKinematicChain, mrpt::maps::COccupancyGridMap2D, mrpt::obs::CObservationGPS, mrpt::obs::CRawlog, mrpt::opengl::COpenGLViewport, mrpt::maps::CHeightGridMap2D, mrpt::opengl::COpenGLScene, mrpt::opengl::CPlanarLaserScan, mrpt::nav::CHolonomicFullEval, mrpt::vision::CFeature, mrpt::nav::CHolonomicND, mrpt::obs::CObservation2DRangeScan, mrpt::obs::CSensoryFrame, mrpt::opengl::CFrustum, mrpt::poses::CPose2DInterpolator, mrpt::poses::CPose3DInterpolator, mrpt::nav::CHolonomicVFF, mrpt::opengl::CEllipsoidInverseDepth3D, mrpt::opengl::CPointCloud, mrpt::opengl::CPointCloudColoured, mrpt::pbmap::PbMap, mrpt::poses::CPose3DQuat, mrpt::pbmap::Plane, mrpt::opengl::CEllipsoid, mrpt::opengl::CEllipsoidInverseDepth2D, mrpt::poses::CPose3DQuatPDFGaussianInf, mrpt::detectors::CDetectable2D, mrpt::hmtslam::CLSLAMParticleData, mrpt::maps::CBeaconMap, mrpt::poses::CPose3DRotVec, mrpt::opengl::CText3D, mrpt::opengl::CVectorField3D, mrpt::poses::CPointPDFParticles, mrpt::poses::CPose3DQuatPDFGaussian, mrpt::opengl::CAngularObservationMesh, mrpt::opengl::CEllipsoidRangeBearing2D, mrpt::opengl::CPolyhedron, mrpt::poses::CPose3DPDFGaussianInf, mrpt::maps::CReflectivityGridMap2D, mrpt::obs::CObservationStereoImages, mrpt::opengl::CAssimpModel, mrpt::maps::CBeacon, mrpt::nav::CPTG_DiffDrive_C, mrpt::opengl::CBox, mrpt::poses::CPose2D, mrpt::opengl::CMeshFast, mrpt::poses::CPose3DPDFGaussian, mrpt::hmtslam::CHMHMapNode, mrpt::hmtslam::CRobotPosesGraph, mrpt::obs::CObservationStereoImagesFeatures, mrpt::opengl::CMesh, mrpt::utils::CMHPropertiesValuesList, mrpt::opengl::CMesh3D, mrpt::opengl::CText, mrpt::poses::CPosePDFGaussianInf, mrpt::maps::CHeightGridMap2D_MRF, mrpt::nav::CPTG_DiffDrive_alpha, mrpt::maps::CRBPFParticleData, mrpt::poses::CPoint2D, mrpt::poses::CPointPDFSOG, mrpt::poses::CPose3DPDFParticles, mrpt::poses::CPosePDFParticles, mrpt::poses::CPosePDFSOG, mrpt::hmtslam::CHMHMapArc, mrpt::opengl::CColorBar, mrpt::opengl::CVectorField2D, mrpt::poses::CPose3DPDFSOG, mrpt::maps::CGasConcentrationGridMap2D, mrpt::maps::CWirelessPowerGridMap2D, mrpt::maps::CSimpleMap, mrpt::obs::CObservationImage, mrpt::opengl::CSetOfLines, mrpt::maps::CLandmark, mrpt::hmtslam::CHierarchicalMHMap, mrpt::maps::COctoMap, mrpt::obs::CActionRobotMovement2D, mrpt::obs::CObservationBatteryState, mrpt::opengl::CDisk, mrpt::poses::CPoint3D, mrpt::utils::CStringList, mrpt::utils::TCamera, mrpt::obs::CObservationOdometry, mrpt::obs::CObservationRawDAQ, mrpt::opengl::CCamera, mrpt::opengl::CCylinder, mrpt::opengl::CGridPlaneXY, mrpt::opengl::CGridPlaneXZ, mrpt::poses::CPosePDFGaussian, mrpt::maps::CColouredOctoMap, mrpt::maps::CSimplePointsMap, mrpt::nav::CLogFileRecord, mrpt::obs::CObservationBearingRange, mrpt::obs::CObservationWindSensor, mrpt::opengl::CArrow, mrpt::opengl::CAxis, mrpt::opengl::CGeneralizedCylinder, mrpt::opengl::CSphere, mrpt::slam::CIncrementalMapPartitioner, mrpt::maps::CColouredPointsMap, mrpt::maps::CWeightedPointsMap, mrpt::obs::CObservationRange, mrpt::opengl::CSetOfObjects, mrpt::obs::CActionCollection, mrpt::obs::CActionRobotMovement3D, mrpt::obs::CObservationWirelessPower, mrpt::opengl::CSetOfTexturedTriangles, mrpt::math::CSplineInterpolator1D, mrpt::nav::CLogFileRecord_VFF, mrpt::nav::CPTG_Holo_Blend, mrpt::obs::CObservation6DFeatures, mrpt::obs::CObservationSkeleton, mrpt::obs::CObservationVisualLandmarks, mrpt::poses::CPosePDFGrid, mrpt::nav::CPTG_DiffDrive_CC, mrpt::nav::CPTG_DiffDrive_CCS, mrpt::nav::CPTG_DiffDrive_CS, mrpt::obs::CObservationBeaconRanges, mrpt::obs::CObservationComment, mrpt::obs::CObservationGasSensors, mrpt::obs::CObservationReflectivity, mrpt::obs::CObservationRFID, mrpt::math::CMatrixD, mrpt::poses::CPoses2DSequence, mrpt::poses::CPoses3DSequence, mrpt::opengl::C3DSScene, mrpt::opengl::COpenGLStandardObject, mrpt::math::CMatrix, mrpt::poses::CPointPDFGaussian, mrpt::utils::TStereoCamera, mrpt::opengl::CSetOfTriangles, mrpt::math::CMatrixB, mrpt::poses::TSimple3DPoint, mrpt::utils::CMemoryChunk, mrpt::utils::CPropertiesValuesList, mrpt::obs::CObservationCANBusJ1939, mrpt::obs::CObservationRobotPose, mrpt::math::CPolygon, mrpt::poses::CPoint2DPDFGaussian, mrpt::utils::CSimpleDatabaseTable, mrpt::utils::CTypeSelector, mrpt::opengl::CSimpleLine, mrpt::opengl::CTexturedPlane, mrpt::kinematics::CVehicleVelCmd_DiffDriven, and mrpt::kinematics::CVehicleVelCmd_Holo.

readFromStreamRender()

void mrpt::opengl::CRenderizableDisplayList::readFromStreamRender ( mrpt::utils::CStream &  in )

inlineprotectedinherited

Definition at line 65 of file CRenderizableDisplayList.h.

References mrpt::opengl::CRenderizableDisplayList::notifyChange(), and mrpt::opengl::CRenderizable::readFromStreamRender().

Referenced by mrpt::opengl::CSimpleLine::readFromStream(), mrpt::opengl::CTexturedPlane::readFromStream(), mrpt::opengl::CGridPlaneXY::readFromStream(), mrpt::opengl::CGridPlaneXZ::readFromStream(), mrpt::opengl::CSetOfLines::readFromStream(), mrpt::opengl::CVectorField2D::readFromStream(), mrpt::opengl::CBox::readFromStream(), mrpt::opengl::CPolyhedron::readFromStream(), mrpt::opengl::CText3D::readFromStream(), mrpt::opengl::CVectorField3D::readFromStream(), mrpt::opengl::CFrustum::readFromStream(), and mrpt::opengl::CPlanarLaserScan::readFromStream().

Here is the call graph for this function:

Here is the caller graph for this function:

releaseTextureName()

void CRenderizable::releaseTextureName ( unsigned int  i )

staticprotectedinherited

Definition at line 101 of file CRenderizable.cpp.

References TOpenGLNameBooker::cs, TOpenGLNameBooker::freeTextureNames, TOpenGLNameBooker::instance(), and TOpenGLNameBooker::next_free_texture.

Referenced by mrpt::opengl::CTexturedObject::unloadTexture().

Here is the call graph for this function:

Here is the caller graph for this function:

render()

void CRenderizableDisplayList::render ( ) const

overridevirtualinherited

Render the object, regenerating the display list if needed, otherwise just calling it.

Implements mrpt::opengl::CRenderizable.

Definition at line 81 of file CRenderizableDisplayList.cpp.

References TAuxDLData::getSingleton(), GL_COMPILE, GL_NO_ERROR, glCallList(), glDeleteLists(), glEndList(), glGenLists(), glGetError(), glNewList(), INVALID_DISPLAY_LIST_ID, mrpt::opengl::CRenderizableDisplayList::m_dl, mrpt::opengl::CRenderizableDisplayList::m_dl_recreate, mrpt::opengl::CRenderizableDisplayList::render_dl(), and mrpt::opengl::CRenderizableDisplayList::should_skip_display_list_cache().

Here is the call graph for this function:

render_dl()

template<int DIM>

void mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::render_dl ( ) const

inlineoverridevirtual

Render If one of the eigen value of the covariance matrix of the ellipsoid is null, ellipsoid will not be rendered to ensure stability in the rendering process.

Implements mrpt::opengl::CRenderizableDisplayList.

Definition at line 159 of file CGeneralizedEllipsoidTemplate.h.

renderTextBitmap() [1/2]

void CRenderizable::renderTextBitmap ( const char *  str, void *  fontStyle  )

staticinherited

This method is safe for calling from within ::render() methods.

See also

renderTextBitmap, mrpt::opengl::gl_utils

renderTextBitmap

Definition at line 380 of file CRenderizable.cpp.

References mrpt::opengl::gl_utils::renderTextBitmap().

Here is the call graph for this function:

renderTextBitmap() [2/2]

void CRenderizable::renderTextBitmap ( int  screen_x, int  screen_y, const std::string &  str, float  color_r = 1, float  color_g = 1, float  color_b = 1, mrpt::opengl::TOpenGLFont  font = mrpt::opengl::MRPT_GLUT_BITMAP_TIMES_ROMAN_24  )

staticinherited

Render a text message in the current rendering context, creating a glViewport in the way (do not call within ::render() methods)

• Coordinates (x,y) are 2D pixels, starting at bottom-left of the viewport. Negative numbers will wrap to the opposite side of the viewport (e.g. x=-10 means 10px fromt the right).
• The text color is defined by (color_r,color_g,color_b), each float numbers in the range [0,1].

  See also

  renderTextBitmap, textBitmapWidth, mrpt::opengl::gl_utils

Definition at line 315 of file gl_utils.cpp.

References aux_mrptfont2glutfont(), GL_DEPTH_TEST, GL_MODELVIEW, GL_PROJECTION, GL_TRANSFORM_BIT, GL_VIEWPORT, GL_VIEWPORT_BIT, glColor3f(), glDisable(), glEnable(), glGetIntegerv(), glLoadIdentity(), glMatrixMode(), glPopAttrib(), glPopMatrix(), glPushAttrib(), glPushMatrix(), glRasterPos3f(), glViewport(), and MRPT_UNUSED_PARAM.

Here is the call graph for this function:

setColor() [1/2]

CRenderizable& mrpt::opengl::CRenderizable::setColor ( const mrpt::utils::TColorf &  c )

inlineinherited

Changes the default object color.

Returns

a ref to this

Definition at line 248 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::setColor_u8().

Referenced by mrpt::hwdrivers::CSkeletonTracker::processPreview().

Here is the call graph for this function:

Here is the caller graph for this function:

setColor() [2/2]

CRenderizable& mrpt::opengl::CRenderizable::setColor ( double  R, double  G, double  B, double  A = 1  )

inlineinherited

Set the color components of this object (R,G,B,Alpha, in the range 0-1)

Returns

a ref to this

Definition at line 257 of file CRenderizable.h.

References R, and mrpt::opengl::CRenderizable::setColor_u8().

Here is the call graph for this function:

setColor_u8() [1/2]

CRenderizable& mrpt::opengl::CRenderizableDisplayList::setColor_u8 ( const mrpt::utils::TColor &  c )

inlineoverridevirtualinherited

Changes the default object color.

Returns

a ref to this

Reimplemented from mrpt::opengl::CRenderizable.

Reimplemented in mrpt::opengl::CSetOfTriangles.

Definition at line 113 of file CRenderizableDisplayList.h.

References mrpt::opengl::CRenderizableDisplayList::notifyChange(), and mrpt::opengl::CRenderizable::setColor_u8().

Here is the call graph for this function:

setColor_u8() [2/2]

CRenderizable& mrpt::opengl::CRenderizableDisplayList::setColor_u8 ( uint8_t  R, uint8_t  G, uint8_t  B, uint8_t  A = 255  )

inlineinherited

Color components in the range [0,255].

Returns

a ref to this

Definition at line 120 of file CRenderizableDisplayList.h.

References mrpt::opengl::CRenderizableDisplayList::notifyChange(), R, and mrpt::opengl::CRenderizable::setColor_u8().

Here is the call graph for this function:

setColorA()

CRenderizable& mrpt::opengl::CRenderizable::setColorA ( const double  a )

inlineinherited

Color components in the range [0,1].

Returns

a ref to this

Definition at line 191 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::setColorA_u8().

Here is the call graph for this function:

setColorA_u8()

CRenderizable& mrpt::opengl::CRenderizableDisplayList::setColorA_u8 ( const uint8_t  a )

inlineoverridevirtualinherited

Color components in the range [0,255].

Returns

a ref to this

Reimplemented from mrpt::opengl::CRenderizable.

Reimplemented in mrpt::opengl::CSetOfTriangles.

Definition at line 106 of file CRenderizableDisplayList.h.

References mrpt::utils::TColor::A, mrpt::opengl::CRenderizable::m_color, and mrpt::opengl::CRenderizableDisplayList::notifyChange().

Referenced by mrpt::nav::ClearanceDiagram::renderAs3DObject().

Here is the call graph for this function:

Here is the caller graph for this function:

setColorB()

CRenderizable& mrpt::opengl::CRenderizable::setColorB ( const double  b )

inlineinherited

Color components in the range [0,1].

Returns

a ref to this

Definition at line 186 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::setColorB_u8().

Here is the call graph for this function:

setColorB_u8()

CRenderizable& mrpt::opengl::CRenderizableDisplayList::setColorB_u8 ( const uint8_t  b )

inlineoverridevirtualinherited

Color components in the range [0,255].

Returns

a ref to this

Reimplemented from mrpt::opengl::CRenderizable.

Reimplemented in mrpt::opengl::CSetOfTriangles.

Definition at line 99 of file CRenderizableDisplayList.h.

References mrpt::utils::TColor::B, mrpt::opengl::CRenderizable::m_color, and mrpt::opengl::CRenderizableDisplayList::notifyChange().

Here is the call graph for this function:

setColorG()

CRenderizable& mrpt::opengl::CRenderizable::setColorG ( const double  g )

inlineinherited

Color components in the range [0,1].

Returns

a ref to this

Definition at line 181 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::setColorG_u8().

Here is the call graph for this function:

setColorG_u8()

CRenderizable& mrpt::opengl::CRenderizableDisplayList::setColorG_u8 ( const uint8_t  g )

inlineoverridevirtualinherited

Color components in the range [0,255].

Returns

a ref to this

Reimplemented from mrpt::opengl::CRenderizable.

Reimplemented in mrpt::opengl::CSetOfTriangles.

Definition at line 92 of file CRenderizableDisplayList.h.

References mrpt::utils::TColor::G, mrpt::opengl::CRenderizable::m_color, and mrpt::opengl::CRenderizableDisplayList::notifyChange().

Here is the call graph for this function:

setColorR()

CRenderizable& mrpt::opengl::CRenderizable::setColorR ( const double  r )

inlineinherited

Color components in the range [0,1].

Returns

a ref to this

Definition at line 176 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::setColorR_u8().

Here is the call graph for this function:

setColorR_u8()

CRenderizable& mrpt::opengl::CRenderizableDisplayList::setColorR_u8 ( const uint8_t  r )

inlineoverridevirtualinherited

Color components in the range [0,255].

Returns

a ref to this

Reimplemented from mrpt::opengl::CRenderizable.

Reimplemented in mrpt::opengl::CSetOfTriangles.

Definition at line 85 of file CRenderizableDisplayList.h.

References mrpt::opengl::CRenderizable::m_color, mrpt::opengl::CRenderizableDisplayList::notifyChange(), and mrpt::utils::TColor::R.

Here is the call graph for this function:

setCovMatrixAndMean()

template<int DIM>

template<typename MATRIX , typename VECTOR >

void mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::setCovMatrixAndMean ( const MATRIX &  new_cov, const VECTOR &  new_mean  )

inline

Set the NxN covariance matrix that will determine the aspect of the ellipsoid - Notice that the covariance determines the uncertainty in the parameter space, which would be transformed by derived function.

Definition at line 90 of file CGeneralizedEllipsoidTemplate.h.

setLineWidth()

template<int DIM>

void mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::setLineWidth ( float  w )

inline

The line width for 2D ellipses or 3D wireframe ellipsoids (default=1)

Definition at line 140 of file CGeneralizedEllipsoidTemplate.h.

setLocation() [1/2]

CRenderizable& mrpt::opengl::CRenderizable::setLocation ( double  x, double  y, double  z  )

inlineinherited

Changes the location of the object, keeping untouched the orientation.

Returns

a ref to this

Definition at line 114 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_pose, mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x(), and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y().

Referenced by mrpt::graphslam::deciders::CLoopCloserERD< GRAPH_T >::updateCurrCovarianceVisualization(), and mrpt::graphslam::deciders::CLoopCloserERD< GRAPH_T >::updateMapPartitionsVisualization().

Here is the call graph for this function:

Here is the caller graph for this function:

setLocation() [2/2]

CRenderizable& mrpt::opengl::CRenderizable::setLocation ( const mrpt::math::TPoint3D &  p )

inlineinherited

Changes the location of the object, keeping untouched the orientation.

Returns

a ref to this

Definition at line 124 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_pose, mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x(), and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y().

Here is the call graph for this function:

setName()

void mrpt::opengl::CRenderizable::setName ( const std::string &  n )

inlineinherited

Changes the name of the object.

Definition at line 68 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_name.

setNumberOfSegments()

template<int DIM>

void mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::setNumberOfSegments ( const uint32_t  numSegments )

inline

Set the number of segments of the surface/curve (higher means with greater resolution)

Definition at line 148 of file CGeneralizedEllipsoidTemplate.h.

setPose() [1/6]

CRenderizable & CRenderizable::setPose ( const mrpt::poses::CPose3D &  o )

inherited

Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this)

Definition at line 310 of file CRenderizable.cpp.

References mrpt::opengl::CRenderizable::m_pose.

Referenced by mrpt::hwdrivers::CSkeletonTracker::processPreview(), mrpt::kinematics::CKinematicChain::update3DObject(), mrpt::graphslam::CGraphSlamEngine< GRAPH_T >::updateEstimatedTrajectoryVisualization(), mrpt::graphslam::CGraphSlamEngine< GRAPH_T >::updateGTVisualization(), mrpt::graphslam::CGraphSlamEngine< GRAPH_T >::updateOdometryVisualization(), and mrpt::graphslam::deciders::CICPCriteriaERD< GRAPH_T >::updateVisuals().

Here is the caller graph for this function:

setPose() [2/6]

CRenderizable & CRenderizable::setPose ( const mrpt::poses::CPose2D &  o )

inherited

Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this)

Definition at line 315 of file CRenderizable.cpp.

References mrpt::opengl::CRenderizable::m_pose.

setPose() [3/6]

CRenderizable & CRenderizable::setPose ( const mrpt::math::TPose3D &  o )

inherited

Set the 3D pose from a mrpt::math::TPose3D object (return a ref to this)

Definition at line 320 of file CRenderizable.cpp.

References mrpt::opengl::CRenderizable::m_pose.

setPose() [4/6]

CRenderizable & CRenderizable::setPose ( const mrpt::math::TPose2D &  o )

inherited

Set the 3D pose from a mrpt::math::TPose3D object (return a ref to this)

Definition at line 325 of file CRenderizable.cpp.

References mrpt::opengl::CRenderizable::m_pose.

setPose() [5/6]

CRenderizable & CRenderizable::setPose ( const mrpt::poses::CPoint3D &  o )

inherited

Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this)

Set the 3D pose from a mrpt::poses::CPose3D object.

Definition at line 332 of file CRenderizable.cpp.

References mrpt::opengl::CRenderizable::m_pose, mrpt::poses::CPose3D::setFromValues(), mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x(), and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y().

Here is the call graph for this function:

setPose() [6/6]

CRenderizable & CRenderizable::setPose ( const mrpt::poses::CPoint2D &  o )

inherited

Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this)

Set the 3D pose from a mrpt::poses::CPose3D object.

Definition at line 338 of file CRenderizable.cpp.

References mrpt::opengl::CRenderizable::m_pose, mrpt::poses::CPose3D::setFromValues(), mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x(), and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y().

Here is the call graph for this function:

setQuantiles()

template<int DIM>

void mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::setQuantiles ( float  q )

inline

Changes the scale of the "sigmas" for drawing the ellipse/ellipsoid (default=3, ~97 or ~98% CI); the exact mathematical meaning is: This value of "quantiles" q should be set to the square root of the chi-squared inverse cdf corresponding to the desired confidence interval.

Note that this value depends on the dimensionality. Refer to the MATLAB functions chi2inv() and chi2cdf().

Some common values follow here for the convenience of users:

• Dimensionality=3 (3D ellipsoids):
  • 19.8748% CI -> q=1
  • 73.8536% CI -> q=2
  • 97.0709% CI -> q=3
  • 99.8866% CI -> q=4
• Dimensionality=2 (2D ellipses):
  • 39.347% CI -> q=1
  • 86.466% CI -> q=2
  • 98.8891% CI -> q=3
  • 99.9664% CI -> q=4
• Dimensionality=1 (Not aplicable to this class but provided for reference):
  • 68.27% CI -> q=1
  • 95.45% CI -> q=2
  • 99.73% CI -> q=3
  • 99.9937% CI -> q=4

Definition at line 132 of file CGeneralizedEllipsoidTemplate.h.

setScale() [1/2]

CRenderizable& mrpt::opengl::CRenderizable::setScale ( float  s )

inlineinherited

Scale to apply to the object, in all three axes (default=1)

Returns

a ref to this

Definition at line 222 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_scale_x, mrpt::opengl::CRenderizable::m_scale_y, and mrpt::opengl::CRenderizable::m_scale_z.

Referenced by mrpt::opengl::CText3D::CText3D().

Here is the caller graph for this function:

setScale() [2/2]

CRenderizable& mrpt::opengl::CRenderizable::setScale ( float  sx, float  sy, float  sz  )

inlineinherited

Scale to apply to the object in each axis (default=1)

Returns

a ref to this

Definition at line 229 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_scale_x, mrpt::opengl::CRenderizable::m_scale_y, and mrpt::opengl::CRenderizable::m_scale_z.

setVisibility()

void mrpt::opengl::CRenderizable::setVisibility ( bool  visible = true )

inlineinherited

Set object visibility (default=true)

See also

isVisible

Definition at line 76 of file CRenderizable.h.

References mrpt::opengl::CRenderizable::m_visible.

Referenced by mrpt::hwdrivers::CSkeletonTracker::processPreview(), mrpt::hwdrivers::CSkeletonTracker::processPreviewNone(), and mrpt::graphslam::deciders::CLoopCloserERD< GRAPH_T >::updateMapPartitionsVisualization().

Here is the caller graph for this function:

should_skip_display_list_cache()

virtual bool mrpt::opengl::CRenderizableDisplayList::should_skip_display_list_cache ( ) const

inlineprotectedvirtualinherited

Optional: If the object has some state in which creating a display list is NOT preferred over direct rendering, implement this method and return "true" in those cases.

Reimplemented in mrpt::opengl::CSphere.

Definition at line 64 of file CRenderizableDisplayList.h.

Referenced by mrpt::opengl::CRenderizableDisplayList::render().

Here is the caller graph for this function:

textBitmapWidth()

int CRenderizable::textBitmapWidth ( const std::string &  str, mrpt::opengl::TOpenGLFont  font = mrpt::opengl::MRPT_GLUT_BITMAP_TIMES_ROMAN_24  )

staticinherited

Return the exact width in pixels for a given string, as will be rendered by renderTextBitmap().

See also

renderTextBitmap, mrpt::opengl::gl_utils

renderTextBitmap

Definition at line 389 of file CRenderizable.cpp.

References mrpt::opengl::gl_utils::textBitmapWidth().

Here is the call graph for this function:

thisclass_readFromStream()

template<int DIM>

void mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::thisclass_readFromStream ( mrpt::utils::CStream &  in )

inlineprotected

Definition at line 275 of file CGeneralizedEllipsoidTemplate.h.

thisclass_writeToStream()

template<int DIM>

void mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::thisclass_writeToStream ( mrpt::utils::CStream &  out ) const

inlineprotected

Definition at line 267 of file CGeneralizedEllipsoidTemplate.h.

traceRay()

template<int DIM>

virtual bool mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::traceRay ( const mrpt::poses::CPose3D &  o, double &  dist  ) const

inlineoverridevirtual

Ray tracing.

Reimplemented from mrpt::opengl::CRenderizable.

Definition at line 235 of file CGeneralizedEllipsoidTemplate.h.

transformFromParameterSpace()

template<int DIM>

virtual void mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::transformFromParameterSpace ( const std::vector< array_point_t > &  params_pts, std::vector< array_point_t > &  out_pts  ) const

protectedpure virtual

To be implemented by derived classes: maps, using some arbitrary space transformation, a list of points defining an ellipsoid in parameter space into their corresponding points in 2D/3D space.

Implemented in mrpt::opengl::CEllipsoidInverseDepth3D, mrpt::opengl::CEllipsoidInverseDepth2D, and mrpt::opengl::CEllipsoidRangeBearing2D.

Referenced by mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::render_dl().

Here is the caller graph for this function:

writeToMatlab()

virtual mxArray* mrpt::utils::CSerializable::writeToMatlab ( ) const

inlinevirtualinherited

Introduces a pure virtual method responsible for writing to a mxArray Matlab object, typically a MATLAB struct whose contents are documented in each derived class.

Returns

A new mxArray (caller is responsible of memory freeing) or nullptr is class does not support conversion to MATLAB.

Definition at line 89 of file CSerializable.h.

writeToStream()

virtual void mrpt::utils::CSerializable::writeToStream ( mrpt::utils::CStream &  out, int *  getVersion  ) const

protectedpure virtualinherited

Introduces a pure virtual method responsible for writing to a CStream.

This can not be used directly be users, instead use "stream << object;" for writing it to a stream.

Parameters

out	The output binary stream where object must be dumped.
getVersion	If nullptr, the object must be dumped. If not, only the version of the object dump must be returned in this pointer. This enables the versioning of objects dumping and backward compatibility with previously stored data.

Exceptions

std::exception

On any error, see CStream::WriteBuffer

See also

CStream

Implemented in mrpt::obs::CObservation3DRangeScan, mrpt::nav::CLogFileRecord_ND, mrpt::nav::CLogFileRecord_FullEval, mrpt::maps::CMultiMetricMap, mrpt::utils::CSimpleDatabase, mrpt::utils::CImage, mrpt::obs::CObservationIMU, mrpt::maps::TMapGenericParams, mrpt::poses::CPose3D, mrpt::obs::CObservationRGBD360, mrpt::maps::CRandomFieldGridMap3D, mrpt::detectors::CDetectable3D, mrpt::hmtslam::THypothesisIDSet, mrpt::maps::CMultiMetricMapPDF, mrpt::hmtslam::CLocalMetricHypothesis, mrpt::obs::CObservationVelodyneScan, mrpt::maps::CLandmarksMap, mrpt::hmtslam::CHMTSLAM, mrpt::opengl::COctoMapVoxels, mrpt::kinematics::CKinematicChain, mrpt::maps::COccupancyGridMap2D, mrpt::obs::CObservationGPS, mrpt::obs::CRawlog, mrpt::opengl::COpenGLViewport, mrpt::maps::CHeightGridMap2D, mrpt::opengl::COpenGLScene, mrpt::opengl::CPlanarLaserScan, mrpt::nav::CHolonomicFullEval, mrpt::vision::CFeature, mrpt::nav::CHolonomicND, mrpt::obs::CObservation2DRangeScan, mrpt::obs::CSensoryFrame, mrpt::opengl::CFrustum, mrpt::poses::CPose2DInterpolator, mrpt::poses::CPose3DInterpolator, mrpt::nav::CHolonomicVFF, mrpt::opengl::CEllipsoidInverseDepth3D, mrpt::opengl::CPointCloud, mrpt::opengl::CPointCloudColoured, mrpt::pbmap::PbMap, mrpt::poses::CPose3DQuat, mrpt::pbmap::Plane, mrpt::opengl::CEllipsoid, mrpt::opengl::CEllipsoidInverseDepth2D, mrpt::poses::CPose3DQuatPDFGaussianInf, mrpt::detectors::CDetectable2D, mrpt::hmtslam::CLSLAMParticleData, mrpt::maps::CBeaconMap, mrpt::poses::CPose3DRotVec, mrpt::opengl::CText3D, mrpt::opengl::CVectorField3D, mrpt::poses::CPointPDFParticles, mrpt::poses::CPose3DQuatPDFGaussian, mrpt::opengl::CAngularObservationMesh, mrpt::opengl::CEllipsoidRangeBearing2D, mrpt::opengl::CPolyhedron, mrpt::poses::CPose3DPDFGaussianInf, mrpt::maps::CReflectivityGridMap2D, mrpt::obs::CObservationStereoImages, mrpt::opengl::CAssimpModel, mrpt::maps::CBeacon, mrpt::nav::CPTG_DiffDrive_C, mrpt::opengl::CBox, mrpt::poses::CPose2D, mrpt::opengl::CMeshFast, mrpt::poses::CPose3DPDFGaussian, mrpt::hmtslam::CHMHMapNode, mrpt::hmtslam::CRobotPosesGraph, mrpt::obs::CObservationStereoImagesFeatures, mrpt::opengl::CMesh, mrpt::utils::CMHPropertiesValuesList, mrpt::opengl::CMesh3D, mrpt::opengl::CText, mrpt::poses::CPosePDFGaussianInf, mrpt::maps::CHeightGridMap2D_MRF, mrpt::nav::CPTG_DiffDrive_alpha, mrpt::maps::CRBPFParticleData, mrpt::poses::CPoint2D, mrpt::poses::CPointPDFSOG, mrpt::poses::CPose3DPDFParticles, mrpt::poses::CPosePDFParticles, mrpt::poses::CPosePDFSOG, mrpt::hmtslam::CHMHMapArc, mrpt::opengl::CColorBar, mrpt::opengl::CVectorField2D, mrpt::poses::CPose3DPDFSOG, mrpt::maps::CGasConcentrationGridMap2D, mrpt::maps::CWirelessPowerGridMap2D, mrpt::maps::CSimpleMap, mrpt::obs::CObservationImage, mrpt::opengl::CSetOfLines, mrpt::maps::CLandmark, mrpt::hmtslam::CHierarchicalMHMap, mrpt::maps::COctoMap, mrpt::obs::CActionRobotMovement2D, mrpt::obs::CObservationBatteryState, mrpt::opengl::CDisk, mrpt::poses::CPoint3D, mrpt::utils::CStringList, mrpt::utils::TCamera, mrpt::obs::CObservationOdometry, mrpt::obs::CObservationRawDAQ, mrpt::opengl::CCamera, mrpt::opengl::CCylinder, mrpt::opengl::CGridPlaneXY, mrpt::opengl::CGridPlaneXZ, mrpt::poses::CPosePDFGaussian, mrpt::maps::CColouredOctoMap, mrpt::maps::CSimplePointsMap, mrpt::nav::CLogFileRecord, mrpt::obs::CObservationBearingRange, mrpt::obs::CObservationWindSensor, mrpt::opengl::CArrow, mrpt::opengl::CAxis, mrpt::opengl::CGeneralizedCylinder, mrpt::opengl::CSphere, mrpt::slam::CIncrementalMapPartitioner, mrpt::maps::CColouredPointsMap, mrpt::maps::CWeightedPointsMap, mrpt::obs::CObservationRange, mrpt::opengl::CSetOfObjects, mrpt::obs::CActionCollection, mrpt::obs::CActionRobotMovement3D, mrpt::obs::CObservationWirelessPower, mrpt::opengl::CSetOfTexturedTriangles, mrpt::math::CSplineInterpolator1D, mrpt::nav::CLogFileRecord_VFF, mrpt::nav::CPTG_Holo_Blend, mrpt::obs::CObservation6DFeatures, mrpt::obs::CObservationSkeleton, mrpt::obs::CObservationVisualLandmarks, mrpt::poses::CPosePDFGrid, mrpt::nav::CPTG_DiffDrive_CC, mrpt::nav::CPTG_DiffDrive_CCS, mrpt::nav::CPTG_DiffDrive_CS, mrpt::obs::CObservationBeaconRanges, mrpt::obs::CObservationComment, mrpt::obs::CObservationGasSensors, mrpt::obs::CObservationReflectivity, mrpt::obs::CObservationRFID, mrpt::math::CMatrixD, mrpt::poses::CPoses2DSequence, mrpt::poses::CPoses3DSequence, mrpt::opengl::C3DSScene, mrpt::opengl::COpenGLStandardObject, mrpt::math::CMatrix, mrpt::poses::CPointPDFGaussian, mrpt::utils::TStereoCamera, mrpt::opengl::CSetOfTriangles, mrpt::math::CMatrixB, mrpt::poses::TSimple3DPoint, mrpt::utils::CMemoryChunk, mrpt::utils::CPropertiesValuesList, mrpt::obs::CObservationCANBusJ1939, mrpt::obs::CObservationRobotPose, mrpt::math::CPolygon, mrpt::poses::CPoint2DPDFGaussian, mrpt::utils::CSimpleDatabaseTable, mrpt::utils::CTypeSelector, mrpt::opengl::CSimpleLine, mrpt::opengl::CTexturedPlane, mrpt::kinematics::CVehicleVelCmd_DiffDriven, and mrpt::kinematics::CVehicleVelCmd_Holo.

Referenced by mrpt::utils::CStream::WriteObject(), mrpt::maps::CColouredOctoMap::writeToStream(), and mrpt::maps::COctoMap::writeToStream().

Here is the caller graph for this function:

writeToStreamRender()

void CRenderizable::writeToStreamRender ( utils::CStream &  out ) const

protectedinherited

Definition at line 112 of file CRenderizable.cpp.

References mrpt::utils::TColor::A, mrpt::utils::TColor::B, mrpt::utils::TColor::G, mrpt::opengl::CRenderizable::m_color, mrpt::opengl::CRenderizable::m_name, mrpt::opengl::CRenderizable::m_pose, mrpt::opengl::CRenderizable::m_scale_x, mrpt::opengl::CRenderizable::m_scale_y, mrpt::opengl::CRenderizable::m_scale_z, mrpt::opengl::CRenderizable::m_show_name, mrpt::opengl::CRenderizable::m_visible, mrpt::poses::CPose3D::pitch(), mrpt::utils::TColor::R, mrpt::poses::CPose3D::roll(), mrpt::utils::CStream::WriteBuffer(), mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x(), mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y(), and mrpt::poses::CPose3D::yaw().

Referenced by mrpt::opengl::CSimpleLine::writeToStream(), mrpt::opengl::CTexturedPlane::writeToStream(), mrpt::opengl::CGridPlaneXZ::writeToStream(), mrpt::opengl::CGridPlaneXY::writeToStream(), mrpt::opengl::CSetOfLines::writeToStream(), mrpt::opengl::CVectorField2D::writeToStream(), mrpt::opengl::CBox::writeToStream(), mrpt::opengl::CPolyhedron::writeToStream(), mrpt::opengl::CVectorField3D::writeToStream(), mrpt::opengl::CText3D::writeToStream(), mrpt::opengl::CFrustum::writeToStream(), and mrpt::opengl::CPlanarLaserScan::writeToStream().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

m_bb_max

template<int DIM>

mrpt::math::TPoint3D mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::m_bb_max

mutableprotected

Definition at line 262 of file CGeneralizedEllipsoidTemplate.h.

Referenced by mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::getBoundingBox(), and mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::render_dl().

m_bb_min

template<int DIM>

mrpt::math::TPoint3D mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::m_bb_min

mutableprotected

Definition at line 262 of file CGeneralizedEllipsoidTemplate.h.

Referenced by mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::getBoundingBox(), and mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::render_dl().

m_color

mrpt::utils::TColor mrpt::opengl::CRenderizable::m_color

protectedinherited

Color components in the range [0,255].

Definition at line 54 of file CRenderizable.h.

Referenced by mrpt::opengl::CMeshFast::CMeshFast(), mrpt::opengl::CVectorField2D::CVectorField2D(), mrpt::opengl::CVectorField3D::CVectorField3D(), mrpt::opengl::CRenderizable::getColor(), mrpt::opengl::CRenderizable::getColor_u8(), mrpt::opengl::CRenderizable::getColorA(), mrpt::opengl::CRenderizable::getColorA_u8(), mrpt::opengl::CRenderizable::getColorB(), mrpt::opengl::CRenderizable::getColorB_u8(), mrpt::opengl::CRenderizable::getColorG(), mrpt::opengl::CRenderizable::getColorG_u8(), mrpt::opengl::CRenderizable::getColorR(), mrpt::opengl::CRenderizable::getColorR_u8(), mrpt::opengl::CRenderizable::readFromStreamRender(), mrpt::opengl::CBox::render_dl(), mrpt::opengl::CSimpleLine::render_dl(), mrpt::opengl::CText3D::render_dl(), mrpt::opengl::CSetOfLines::render_dl(), mrpt::opengl::CVectorField2D::render_dl(), mrpt::opengl::CVectorField3D::render_dl(), mrpt::opengl::CPolyhedron::render_dl(), mrpt::opengl::CTexturedObject::render_post(), mrpt::opengl::CTexturedObject::render_pre(), mrpt::opengl::CRenderizable::setColor_u8(), mrpt::opengl::CRenderizableDisplayList::setColorA_u8(), mrpt::opengl::CRenderizable::setColorA_u8(), mrpt::opengl::CRenderizableDisplayList::setColorB_u8(), mrpt::opengl::CRenderizable::setColorB_u8(), mrpt::opengl::CRenderizableDisplayList::setColorG_u8(), mrpt::opengl::CRenderizable::setColorG_u8(), mrpt::opengl::CRenderizableDisplayList::setColorR_u8(), mrpt::opengl::CRenderizable::setColorR_u8(), and mrpt::opengl::CRenderizable::writeToStreamRender().

m_cov

template<int DIM>

cov_matrix_t mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::m_cov

mutableprotected

Definition at line 253 of file CGeneralizedEllipsoidTemplate.h.

Referenced by mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::getCovMatrix(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::render_dl(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::setCovMatrixAndMean(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::thisclass_readFromStream(), and mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::thisclass_writeToStream().

m_lineWidth

template<int DIM>

float mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::m_lineWidth

protected

The line width for 2D ellipses or 3D wireframe ellipsoids (default=1)

Definition at line 259 of file CGeneralizedEllipsoidTemplate.h.

Referenced by mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::getLineWidth(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::render_dl(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::setLineWidth(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::thisclass_readFromStream(), and mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::thisclass_writeToStream().

m_mean

template<int DIM>

mean_vector_t mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::m_mean

protected

Definition at line 254 of file CGeneralizedEllipsoidTemplate.h.

Referenced by mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::render_dl(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::setCovMatrixAndMean(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::thisclass_readFromStream(), and mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::thisclass_writeToStream().

m_name

std::string mrpt::opengl::CRenderizable::m_name

protectedinherited

Definition at line 51 of file CRenderizable.h.

Referenced by mrpt::opengl::CRenderizable::getName(), mrpt::opengl::CRenderizable::readFromStreamRender(), mrpt::opengl::CRenderizable::setName(), and mrpt::opengl::CRenderizable::writeToStreamRender().

m_needToRecomputeEigenVals

template<int DIM>

bool mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::m_needToRecomputeEigenVals

mutableprotected

Definition at line 255 of file CGeneralizedEllipsoidTemplate.h.

Referenced by mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::render_dl(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::setCovMatrixAndMean(), and mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::thisclass_readFromStream().

m_numSegments

template<int DIM>

uint32_t mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::m_numSegments

protected

Number of segments in 2D/3D ellipsoids (default=10)

Definition at line 261 of file CGeneralizedEllipsoidTemplate.h.

Referenced by mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::getNumberOfSegments(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::render_dl(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::setNumberOfSegments(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::thisclass_readFromStream(), and mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::thisclass_writeToStream().

m_pose

mrpt::poses::CPose3D mrpt::opengl::CRenderizable::m_pose

protectedinherited

6D pose wrt the parent coordinate reference.

This class automatically holds the cached 3x3 rotation matrix for quick load into opengl stack.

Definition at line 57 of file CRenderizable.h.

Referenced by mrpt::opengl::C3DSScene::getBoundingBox(), mrpt::opengl::CAssimpModel::getBoundingBox(), mrpt::opengl::CBox::getBoundingBox(), mrpt::opengl::CSimpleLine::getBoundingBox(), mrpt::opengl::CTexturedPlane::getBoundingBox(), mrpt::opengl::CGridPlaneXY::getBoundingBox(), mrpt::opengl::CText3D::getBoundingBox(), mrpt::opengl::CGridPlaneXZ::getBoundingBox(), mrpt::opengl::CFrustum::getBoundingBox(), mrpt::opengl::CPlanarLaserScan::getBoundingBox(), mrpt::opengl::CPolyhedron::getBoundingBox(), mrpt::opengl::CVectorField2D::getBoundingBox(), mrpt::opengl::CSetOfLines::getBoundingBox(), mrpt::opengl::CVectorField3D::getBoundingBox(), mrpt::opengl::CRenderizable::getPose(), mrpt::opengl::CRenderizable::getPosePitch(), mrpt::opengl::CRenderizable::getPosePitchRad(), mrpt::opengl::CRenderizable::getPoseRef(), mrpt::opengl::CRenderizable::getPoseRoll(), mrpt::opengl::CRenderizable::getPoseRollRad(), mrpt::opengl::CRenderizable::getPoseX(), mrpt::opengl::CRenderizable::getPoseY(), mrpt::opengl::CRenderizable::getPoseYaw(), mrpt::opengl::CRenderizable::getPoseYawRad(), mrpt::opengl::CRenderizable::getPoseZ(), mrpt::opengl::CPolyhedron::getSetOfPolygonsAbsolute(), mrpt::opengl::CRenderizable::readFromStreamRender(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::render_dl(), mrpt::opengl::CRenderizable::setLocation(), mrpt::opengl::CRenderizable::setPose(), mrpt::opengl::CTexturedPlane::traceRay(), mrpt::opengl::CPolyhedron::traceRay(), and mrpt::opengl::CRenderizable::writeToStreamRender().

m_quantiles

template<int DIM>

float mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::m_quantiles

protected

The number of "sigmas" for drawing the ellipse/ellipsoid (default=3)

Definition at line 257 of file CGeneralizedEllipsoidTemplate.h.

Referenced by mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::getQuantiles(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::render_dl(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::setQuantiles(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::thisclass_readFromStream(), and mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::thisclass_writeToStream().

m_scale_x

float mrpt::opengl::CRenderizable::m_scale_x

protectedinherited

Scale components to apply to the object (default=1)

Definition at line 59 of file CRenderizable.h.

Referenced by mrpt::opengl::CText3D::getBoundingBox(), mrpt::opengl::CRenderizable::getScaleX(), mrpt::opengl::CRenderizable::readFromStreamRender(), mrpt::opengl::CRenderizable::setScale(), and mrpt::opengl::CRenderizable::writeToStreamRender().

m_scale_y

float mrpt::opengl::CRenderizable::m_scale_y

protectedinherited

Definition at line 59 of file CRenderizable.h.

Referenced by mrpt::opengl::CRenderizable::getScaleY(), mrpt::opengl::CRenderizable::readFromStreamRender(), mrpt::opengl::CRenderizable::setScale(), and mrpt::opengl::CRenderizable::writeToStreamRender().

m_scale_z

float mrpt::opengl::CRenderizable::m_scale_z

protectedinherited

Definition at line 59 of file CRenderizable.h.

Referenced by mrpt::opengl::CRenderizable::getScaleZ(), mrpt::opengl::CRenderizable::readFromStreamRender(), mrpt::opengl::CRenderizable::setScale(), and mrpt::opengl::CRenderizable::writeToStreamRender().

m_show_name

bool mrpt::opengl::CRenderizable::m_show_name

protectedinherited

Definition at line 52 of file CRenderizable.h.

Referenced by mrpt::opengl::CRenderizable::enableShowName(), mrpt::opengl::CRenderizable::isShowNameEnabled(), mrpt::opengl::CRenderizable::readFromStreamRender(), and mrpt::opengl::CRenderizable::writeToStreamRender().

m_U

template<int DIM>

cov_matrix_t mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >::m_U

mutableprotected

Cholesky U triangular matrix cache.

Definition at line 265 of file CGeneralizedEllipsoidTemplate.h.

Referenced by mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::render_dl().

m_visible

bool mrpt::opengl::CRenderizable::m_visible

protectedinherited

Is the object visible? (default=true)

Definition at line 61 of file CRenderizable.h.

Referenced by mrpt::opengl::CRenderizable::isVisible(), mrpt::opengl::CRenderizable::readFromStreamRender(), mrpt::opengl::CRenderizable::setVisibility(), and mrpt::opengl::CRenderizable::writeToStreamRender().

runtimeClassId

const mrpt::utils::TRuntimeClassId mrpt::opengl::CRenderizableDisplayList::runtimeClassId

staticprotectedinherited

Definition at line 41 of file CRenderizableDisplayList.h.
