Detailed Description

This class impements a very simple database system.

A database is a collection of tables, each one being a CSimpleDatabaseTable object. Tables are a rectangular arrrangement of cells, organized as records of fields. There are XML export/import methods in saveAsXML, loadFromXML.

Note: This class is NOT safe for read/write access from different threads. If needed, use critical sections.

See also: CSimpleDatabaseTable

Definition at line 123 of file CSimpleDatabase.h.

#include <mrpt/utils/CSimpleDatabase.h>

Inheritance diagram for mrpt::utils::CSimpleDatabase:

Public Member Functions
void *	operator new (size_t size)

void *	operator new[] (size_t size)

void	operator delete (void *ptr) noexcept

void	operator delete[] (void *ptr) noexcept

void	operator delete (void memory, void ptr) noexcept

void *	operator new (size_t size, const std::nothrow_t &) noexcept

void	operator delete (void *ptr, const std::nothrow_t &) noexcept

	CSimpleDatabase ()
	Default constructor. More...

virtual	~CSimpleDatabase ()
	Destructor. More...

void	clear ()
	Clears the DB. More...

CSimpleDatabaseTable::Ptr	createTable (const std::string &name)
	Creates a new table in the DB, initially empty. More...

CSimpleDatabaseTable::Ptr	getTable (const std::string &tableName)
	Returns the table with the indicated name. More...

void	dropTable (const std::string &tableName)
	Deletes the given table. More...

void	renameTable (const std::string &tableName, const std::string &newTableName)
	Changes the name of a given table. More...

CSimpleDatabaseTable::Ptr	getTable (size_t tableIndex)
	Returns the table by index. More...

size_t	tablesCount () const
	Returns the tables count in the DB. More...

std::string	tablesName (size_t tableIndex) const
	Returns the tables names in the DB. More...

bool	saveAsXML (const std::string &fileName) const
	Saves this database as a XML file. More...

bool	loadFromXML (const std::string &fileName)
	Loads the content of this database from a a XML file. More...

virtual mxArray *	writeToMatlab () const
	Introduces a pure virtual method responsible for writing to a `mxArray` Matlab object, typically a MATLAB `struct` whose contents are documented in each derived class. More...

RTTI classes and functions
mrpt::utils::CObject::Ptr	duplicateGetSmartPtr () const
	Returns a copy of the object, indepently of its class, as a smart pointer (the newly created object will exist as long as any copy of this smart pointer). More...

Static Public Member Functions
static void *	operator new (size_t size, void *ptr)

Protected Member Functions
CSerializable virtual methods
void	writeToStream (mrpt::utils::CStream &out, int *getVersion) const override
	Introduces a pure virtual method responsible for writing to a CStream. More...

void	readFromStream (mrpt::utils::CStream &in, int version) override
	Introduces a pure virtual method responsible for loading from a CStream This can not be used directly be users, instead use "stream >> object;" for reading it from a stream or "stream >> object_ptr;" if the class is unknown apriori. More...

Private Types
typedef std::map< std::string, CSimpleDatabaseTable::Ptr >	TTableList
	The tables of the DB indexed by their names: More...

typedef std::map< std::string, CSimpleDatabaseTable::Ptr >::iterator	iterator

typedef std::map< std::string, CSimpleDatabaseTable::Ptr >::const_iterator	const_iterator

Private Attributes
TTableList	m_tables

RTTI stuff
using	Ptr = std::shared_ptr< CSimpleDatabase >

using	ConstPtr = std::shared_ptr< const CSimpleDatabase >

static mrpt::utils::CLASSINIT	_init_CSimpleDatabase

static const mrpt::utils::TRuntimeClassId	runtimeClassId

static constexpr const char *	className = "CSimpleDatabase"

static const mrpt::utils::TRuntimeClassId *	_GetBaseClass ()

static const mrpt::utils::TRuntimeClassId &	GetRuntimeClassIdStatic ()

static mrpt::utils::CObject *	CreateObject ()

template<typename... Args>
static Ptr	Create (Args &&... args)

virtual const mrpt::utils::TRuntimeClassId *	GetRuntimeClass () const override
	Returns information about the class of an object in runtime. More...

virtual mrpt::utils::CObject *	clone () const override
	Returns a deep copy (clone) of the object, indepently of its class. More...

Member Typedef Documentation

◆ const_iterator

typedef std::map<std::string, CSimpleDatabaseTable::Ptr>::const_iterator mrpt::utils::CSimpleDatabase::const_iterator

private

Definition at line 192 of file CSimpleDatabase.h.

◆ ConstPtr

using mrpt::utils::CSimpleDatabase::ConstPtr = std::shared_ptr<const CSimpleDatabase >

Definition at line 125 of file CSimpleDatabase.h.

◆ iterator

typedef std::map<std::string, CSimpleDatabaseTable::Ptr>::iterator mrpt::utils::CSimpleDatabase::iterator

private

Definition at line 190 of file CSimpleDatabase.h.

◆ Ptr

using mrpt::utils::CSimpleDatabase::Ptr = std::shared_ptr< CSimpleDatabase >

A typedef for the associated smart pointer

Definition at line 125 of file CSimpleDatabase.h.

◆ TTableList

typedef std::map<std::string, CSimpleDatabaseTable::Ptr> mrpt::utils::CSimpleDatabase::TTableList

private

The tables of the DB indexed by their names:

Definition at line 189 of file CSimpleDatabase.h.

Constructor & Destructor Documentation

◆ CSimpleDatabase()

CSimpleDatabase::CSimpleDatabase ( )

Default constructor.

Definition at line 142 of file CSimpleDatabase.cpp.

◆ ~CSimpleDatabase()

CSimpleDatabase::~CSimpleDatabase ( )

virtual

Destructor.

Definition at line 146 of file CSimpleDatabase.cpp.

References mrpt::utils::clear().

Here is the call graph for this function:

Member Function Documentation

◆ _GetBaseClass()

static const mrpt::utils::TRuntimeClassId* mrpt::utils::CSimpleDatabase::_GetBaseClass ( )

staticprotected

◆ clear()

void CSimpleDatabase::clear ( )

Clears the DB.

Definition at line 150 of file CSimpleDatabase.cpp.

◆ clone()

virtual mrpt::utils::CObject* mrpt::utils::CSimpleDatabase::clone ( ) const

overridevirtual

Returns a deep copy (clone) of the object, indepently of its class.

Implements mrpt::utils::CObject.

◆ Create()

template<typename... Args>

static Ptr mrpt::utils::CSimpleDatabase::Create ( Args &&... args )

inlinestatic

Definition at line 125 of file CSimpleDatabase.h.

◆ CreateObject()

static mrpt::utils::CObject* mrpt::utils::CSimpleDatabase::CreateObject ( )

static

◆ createTable()

CSimpleDatabaseTable::Ptr CSimpleDatabase::createTable ( const std::string & name )

Creates a new table in the DB, initially empty.

Definition at line 205 of file CSimpleDatabase.cpp.

Referenced by mrpt::hmtslam::CHierarchicalMHMap::dumpAsXMLfile().

Here is the caller graph for this function:

◆ dropTable()

void CSimpleDatabase::dropTable ( const std::string & tableName )

Deletes the given table.

Exceptions

std::exception On table not found.

Definition at line 518 of file CSimpleDatabase.cpp.

References MRPT_END, MRPT_START, and THROW_EXCEPTION_FMT.

◆ GetRuntimeClass()

virtual const mrpt::utils::TRuntimeClassId* mrpt::utils::CSimpleDatabase::GetRuntimeClass ( ) const

overridevirtual

Returns information about the class of an object in runtime.

Reimplemented from mrpt::utils::CSerializable.

◆ GetRuntimeClassIdStatic()

static const mrpt::utils::TRuntimeClassId& mrpt::utils::CSimpleDatabase::GetRuntimeClassIdStatic ( )

static

◆ getTable() [1/2]

CSimpleDatabaseTable::Ptr CSimpleDatabase::getTable ( const std::string & tableName )

Returns the table with the indicated name.

Exceptions

std::exception On table not found.

Definition at line 154 of file CSimpleDatabase.cpp.

References MRPT_END, MRPT_START, and THROW_EXCEPTION_FMT.

Referenced by mrpt::hmtslam::CHierarchicalMHMap::loadFromXMLfile().

Here is the caller graph for this function:

◆ getTable() [2/2]

CSimpleDatabaseTable::Ptr CSimpleDatabase::getTable ( size_t tableIndex )

Returns the table by index.

Exceptions

std::exception On index out of bounds

Definition at line 170 of file CSimpleDatabase.cpp.

References ASSERT_, MRPT_END, and MRPT_START.

◆ loadFromXML()

bool CSimpleDatabase::loadFromXML ( const std::string & fileName )

Loads the content of this database from a a XML file.

Returns: false on any error, true if successful.

See also: saveAsXML

Definition at line 433 of file CSimpleDatabase.cpp.

References ASSERT_, mrpt::utils::clear(), XMLResults::error, eXMLErrorNone, XMLNode::getAttribute(), XMLNode::getChildNode(), XMLNode::getError(), XMLNode::isEmpty(), XMLNode::nChildNode(), XMLResults::nColumn, XMLResults::nLine, XMLNode::parseFile(), and XMLCSTR.

Referenced by mrpt::hmtslam::CHierarchicalMHMap::loadFromXMLfile().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator delete() [1/3]

void mrpt::utils::CSimpleDatabase::operator delete ( void * ptr )

inlinenoexcept

Definition at line 125 of file CSimpleDatabase.h.

◆ operator delete() [2/3]

void mrpt::utils::CSimpleDatabase::operator delete	(	void *	memory,
		void *	ptr
	)

inlinenoexcept

Definition at line 125 of file CSimpleDatabase.h.

◆ operator delete() [3/3]

void mrpt::utils::CSimpleDatabase::operator delete	(	void *	ptr,
		const std::nothrow_t &
	)

inlinenoexcept

Definition at line 125 of file CSimpleDatabase.h.

◆ operator delete[]()

void mrpt::utils::CSimpleDatabase::operator delete[] ( void * ptr )

inlinenoexcept

Definition at line 125 of file CSimpleDatabase.h.

◆ operator new() [1/3]

void* mrpt::utils::CSimpleDatabase::operator new ( size_t size )

inline

Definition at line 125 of file CSimpleDatabase.h.

◆ operator new() [2/3]

static void* mrpt::utils::CSimpleDatabase::operator new	(	size_t	size,
		void *	ptr
	)

inlinestatic

Definition at line 125 of file CSimpleDatabase.h.

◆ operator new() [3/3]

void* mrpt::utils::CSimpleDatabase::operator new	(	size_t	size,
		const std::nothrow_t &
	)

inlinenoexcept

Definition at line 125 of file CSimpleDatabase.h.

◆ operator new[]()

void* mrpt::utils::CSimpleDatabase::operator new[] ( size_t size )

inline

Definition at line 125 of file CSimpleDatabase.h.

◆ readFromStream()

void CSimpleDatabase::readFromStream	(	mrpt::utils::CStream &	in,
		int	version
	)

overrideprotectedvirtual

Introduces a pure virtual method responsible for loading from a CStream This can not be used directly be users, instead use "stream >> object;" for reading it from a stream or "stream >> object_ptr;" if the class is unknown apriori.

Parameters

in	The input binary stream where the object data must read from.
version	The version of the object stored in the stream: use this version number in your code to know how to read the incoming data.

Exceptions

std::exception On any error, see CStream::ReadBuffer

See also: CStream

Implements mrpt::utils::CSerializable.

Definition at line 54 of file CSimpleDatabase.cpp.

References mrpt::utils::clear(), and MRPT_THROW_UNKNOWN_SERIALIZATION_VERSION.

Here is the call graph for this function:

◆ renameTable()

void CSimpleDatabase::renameTable	(	const std::string &	tableName,
		const std::string &	newTableName
	)

Changes the name of a given table.

Exceptions

std::exception On table not found or new name already existed.

Definition at line 534 of file CSimpleDatabase.cpp.

References MRPT_END, MRPT_START, and THROW_EXCEPTION_FMT.

◆ saveAsXML()

bool CSimpleDatabase::saveAsXML ( const std::string & fileName ) const

Saves this database as a XML file.

Returns: false on any error, true if successful.

See also: loadFromXML

Definition at line 375 of file CSimpleDatabase.cpp.

References XMLNode::addAttribute(), XMLNode::addChild(), XMLNode::addText(), XMLNode::createXMLTopNode(), and XMLNode::writeToFile().

Referenced by mrpt::hmtslam::CHierarchicalMHMap::dumpAsXMLfile().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ tablesCount()

size_t CSimpleDatabase::tablesCount ( ) const

Returns the tables count in the DB.

Definition at line 186 of file CSimpleDatabase.cpp.

◆ tablesName()

string CSimpleDatabase::tablesName ( size_t tableIndex ) const

Returns the tables names in the DB.

Exceptions

std::exception On index out of bounds

Definition at line 190 of file CSimpleDatabase.cpp.

References ASSERT_, MRPT_END, and MRPT_START.

◆ writeToMatlab()

virtual mxArray* mrpt::utils::CSerializable::writeToMatlab ( ) const

inlinevirtualinherited

Introduces a pure virtual method responsible for writing to a mxArray Matlab object, typically a MATLAB struct whose contents are documented in each derived class.

Returns: A new mxArray (caller is responsible of memory freeing) or nullptr is class does not support conversion to MATLAB.

Definition at line 89 of file CSerializable.h.

◆ writeToStream()

void CSimpleDatabase::writeToStream	(	mrpt::utils::CStream &	out,
		int *	getVersion
	)		const

overrideprotectedvirtual

Introduces a pure virtual method responsible for writing to a CStream.

This can not be used directly be users, instead use "stream << object;" for writing it to a stream.

Parameters

out	The output binary stream where object must be dumped.
getVersion	If nullptr, the object must be dumped. If not, only the version of the object dump must be returned in this pointer. This enables the versioning of objects dumping and backward compatibility with previously stored data.

Exceptions

std::exception On any error, see CStream::WriteBuffer

See also: CStream

Implements mrpt::utils::CSerializable.

Definition at line 33 of file CSimpleDatabase.cpp.

Member Data Documentation

◆ _init_CSimpleDatabase

mrpt::utils::CLASSINIT mrpt::utils::CSimpleDatabase::_init_CSimpleDatabase

staticprotected

Definition at line 125 of file CSimpleDatabase.h.

◆ className

constexpr const char* mrpt::utils::CSimpleDatabase::className = "CSimpleDatabase"

static

Definition at line 125 of file CSimpleDatabase.h.

◆ m_tables

TTableList mrpt::utils::CSimpleDatabase::m_tables

private

Definition at line 194 of file CSimpleDatabase.h.

◆ runtimeClassId

const mrpt::utils::TRuntimeClassId mrpt::utils::CSimpleDatabase::runtimeClassId

staticprotected

Definition at line 125 of file CSimpleDatabase.h.

Detailed Description

Public Member Functions

Static Public Member Functions

Protected Member Functions

Private Types

Private Attributes

RTTI stuff

Member Typedef Documentation

◆ const_iterator

◆ ConstPtr

◆ iterator

◆ Ptr

◆ TTableList

Constructor & Destructor Documentation

◆ CSimpleDatabase()

◆ ~CSimpleDatabase()

Member Function Documentation

◆ _GetBaseClass()

◆ clear()

◆ clone()

◆ Create()

◆ CreateObject()

◆ createTable()

◆ dropTable()

◆ GetRuntimeClass()

◆ GetRuntimeClassIdStatic()

◆ getTable() [1/2]

◆ getTable() [2/2]

◆ loadFromXML()

◆ operator delete() [1/3]

◆ operator delete() [2/3]

◆ operator delete() [3/3]

◆ operator delete[]()

◆ operator new() [1/3]

◆ operator new() [2/3]

◆ operator new() [3/3]

◆ operator new[]()

◆ readFromStream()

◆ renameTable()

◆ saveAsXML()

◆ tablesCount()

◆ tablesName()

◆ writeToMatlab()

◆ writeToStream()

Member Data Documentation

◆ _init_CSimpleDatabase

◆ className

◆ m_tables

◆ runtimeClassId
