The base class of 3D objects that can be directly rendered through OpenGL.
In this class there are a set of common properties to all 3D objects, mainly:
Definition at line 43 of file CRenderizable.h.
#include <mrpt/opengl/CRenderizable.h>
Public Member Functions | |
CRenderizable () | |
Default constructor: More... | |
virtual | ~CRenderizable () |
virtual void | render () const =0 |
Implements the rendering of 3D objects in each class derived from CRenderizable. More... | |
virtual bool | traceRay (const mrpt::poses::CPose3D &o, double &dist) const |
Simulation of ray-trace, given a pose. More... | |
virtual void | getBoundingBox (mrpt::math::TPoint3D &bb_min, mrpt::math::TPoint3D &bb_max) const =0 |
Evaluates the bounding box of this object (including possible children) in the coordinate frame of the object parent. More... | |
virtual mxArray * | writeToMatlab () const |
Introduces a pure virtual method responsible for writing to a mxArray Matlab object, typically a MATLAB struct whose contents are documented in each derived class. More... | |
virtual CObject * | clone () const =0 |
Returns a deep copy (clone) of the object, indepently of its class. More... | |
Changes the appearance of the object to render | |
void | setName (const std::string &n) |
Changes the name of the object. More... | |
const std::string & | getName () const |
Returns the name of the object. More... | |
bool | isVisible () const |
Is the object visible? More... | |
void | setVisibility (bool visible=true) |
Set object visibility (default=true) More... | |
void | enableShowName (bool showName=true) |
Enables or disables showing the name of the object as a label when rendering. More... | |
bool | isShowNameEnabled () const |
CRenderizable & | setPose (const mrpt::poses::CPose3D &o) |
Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this) More... | |
CRenderizable & | setPose (const mrpt::poses::CPose2D &o) |
Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this) More... | |
CRenderizable & | setPose (const mrpt::math::TPose3D &o) |
Set the 3D pose from a mrpt::math::TPose3D object (return a ref to this) More... | |
CRenderizable & | setPose (const mrpt::math::TPose2D &o) |
Set the 3D pose from a mrpt::math::TPose3D object (return a ref to this) More... | |
CRenderizable & | setPose (const mrpt::poses::CPoint3D &o) |
Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this) More... | |
CRenderizable & | setPose (const mrpt::poses::CPoint2D &o) |
Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this) More... | |
mrpt::math::TPose3D | getPose () const |
Returns the 3D pose of the object as TPose3D. More... | |
const mrpt::poses::CPose3D & | getPoseRef () const |
Returns a const ref to the 3D pose of the object as mrpt::poses::CPose3D (which explicitly contains the 3x3 rotation matrix) More... | |
CRenderizable & | setLocation (double x, double y, double z) |
Changes the location of the object, keeping untouched the orientation. More... | |
CRenderizable & | setLocation (const mrpt::math::TPoint3D &p) |
Changes the location of the object, keeping untouched the orientation. More... | |
double | getPoseX () const |
Translation relative to parent coordinate origin. More... | |
double | getPoseY () const |
Translation relative to parent coordinate origin. More... | |
double | getPoseZ () const |
Translation relative to parent coordinate origin. More... | |
double | getPoseYaw () const |
Rotation relative to parent coordinate origin, in DEGREES. More... | |
double | getPosePitch () const |
Rotation relative to parent coordinate origin, in DEGREES. More... | |
double | getPoseRoll () const |
Rotation relative to parent coordinate origin, in DEGREES. More... | |
double | getPoseYawRad () const |
Rotation relative to parent coordinate origin, in radians. More... | |
double | getPosePitchRad () const |
Rotation relative to parent coordinate origin, in radians. More... | |
double | getPoseRollRad () const |
Rotation relative to parent coordinate origin, in radians. More... | |
double | getColorR () const |
Color components in the range [0,1]. More... | |
double | getColorG () const |
Color components in the range [0,1]. More... | |
double | getColorB () const |
Color components in the range [0,1]. More... | |
double | getColorA () const |
Color components in the range [0,1]. More... | |
uint8_t | getColorR_u8 () const |
Color components in the range [0,255]. More... | |
uint8_t | getColorG_u8 () const |
Color components in the range [0,255]. More... | |
uint8_t | getColorB_u8 () const |
Color components in the range [0,255]. More... | |
uint8_t | getColorA_u8 () const |
Color components in the range [0,255]. More... | |
CRenderizable & | setColorR (const double r) |
Color components in the range [0,1]. More... | |
CRenderizable & | setColorG (const double g) |
Color components in the range [0,1]. More... | |
CRenderizable & | setColorB (const double b) |
Color components in the range [0,1]. More... | |
CRenderizable & | setColorA (const double a) |
Color components in the range [0,1]. More... | |
virtual CRenderizable & | setColorR_u8 (const uint8_t r) |
Color components in the range [0,255]. More... | |
virtual CRenderizable & | setColorG_u8 (const uint8_t g) |
Color components in the range [0,255]. More... | |
virtual CRenderizable & | setColorB_u8 (const uint8_t b) |
Color components in the range [0,255]. More... | |
virtual CRenderizable & | setColorA_u8 (const uint8_t a) |
Color components in the range [0,255]. More... | |
CRenderizable & | setScale (float s) |
Scale to apply to the object, in all three axes (default=1) More... | |
CRenderizable & | setScale (float sx, float sy, float sz) |
Scale to apply to the object in each axis (default=1) More... | |
float | getScaleX () const |
Get the current scaling factor in one axis. More... | |
float | getScaleY () const |
Get the current scaling factor in one axis. More... | |
float | getScaleZ () const |
Get the current scaling factor in one axis. More... | |
mrpt::utils::TColorf | getColor () const |
Returns the object color property as a TColorf. More... | |
CRenderizable & | setColor (const mrpt::utils::TColorf &c) |
Changes the default object color. More... | |
CRenderizable & | setColor (double R, double G, double B, double A=1) |
Set the color components of this object (R,G,B,Alpha, in the range 0-1) More... | |
const mrpt::utils::TColor & | getColor_u8 () const |
Returns the object color property as a TColor. More... | |
virtual CRenderizable & | setColor_u8 (const mrpt::utils::TColor &c) |
CRenderizable & | setColor_u8 (uint8_t R, uint8_t G, uint8_t B, uint8_t A=255) |
Set the color components of this object (R,G,B,Alpha, in the range 0-255) More... | |
RTTI classes and functions | |
mrpt::utils::CObject::Ptr | duplicateGetSmartPtr () const |
Returns a copy of the object, indepently of its class, as a smart pointer (the newly created object will exist as long as any copy of this smart pointer). More... | |
Static Public Member Functions | |
static void | renderTextBitmap (const char *str, void *fontStyle) |
This method is safe for calling from within ::render() methods. More... | |
static int | textBitmapWidth (const std::string &str, mrpt::opengl::TOpenGLFont font=mrpt::opengl::MRPT_GLUT_BITMAP_TIMES_ROMAN_24) |
Return the exact width in pixels for a given string, as will be rendered by renderTextBitmap(). More... | |
static void | renderTextBitmap (int screen_x, int screen_y, const std::string &str, float color_r=1, float color_g=1, float color_b=1, mrpt::opengl::TOpenGLFont font=mrpt::opengl::MRPT_GLUT_BITMAP_TIMES_ROMAN_24) |
Render a text message in the current rendering context, creating a glViewport in the way (do not call within ::render() methods) More... | |
Protected Member Functions | |
void | writeToStreamRender (utils::CStream &out) const |
void | readFromStreamRender (utils::CStream &in) |
virtual void | writeToStream (mrpt::utils::CStream &out, int *getVersion) const =0 |
Introduces a pure virtual method responsible for writing to a CStream. More... | |
virtual void | readFromStream (mrpt::utils::CStream &in, int version)=0 |
Introduces a pure virtual method responsible for loading from a CStream This can not be used directly be users, instead use "stream >> object;" for reading it from a stream or "stream >> object_ptr;" if the class is unknown apriori. More... | |
Static Protected Member Functions | |
static void | checkOpenGLError () |
Checks glGetError and throws an exception if an error situation is found. More... | |
static unsigned int | getNewTextureNumber () |
Returns the lowest next free texture name (avoid using OpenGL's own function since we may call them from different threads and seem it's not cool). More... | |
static void | releaseTextureName (unsigned int i) |
Protected Attributes | |
std::string | m_name |
bool | m_show_name |
mrpt::utils::TColor | m_color |
Color components in the range [0,255]. More... | |
mrpt::poses::CPose3D | m_pose |
6D pose wrt the parent coordinate reference. More... | |
float | m_scale_x |
Scale components to apply to the object (default=1) More... | |
float | m_scale_y |
float | m_scale_z |
bool | m_visible |
Is the object visible? (default=true) More... | |
Friends | |
class | mrpt::opengl::COpenGLViewport |
class | mrpt::opengl::CSetOfObjects |
RTTI stuff | |
using | Ptr = std::shared_ptr< CRenderizable > |
using | ConstPtr = std::shared_ptr< const CRenderizable > |
static const mrpt::utils::TRuntimeClassId | runtimeClassId |
class | mrpt::utils::CStream |
static const mrpt::utils::TRuntimeClassId * | _GetBaseClass () |
virtual const mrpt::utils::TRuntimeClassId * | GetRuntimeClass () const override |
Returns information about the class of an object in runtime. More... | |
static const mrpt::utils::TRuntimeClassId & | GetRuntimeClassIdStatic () |
using mrpt::opengl::CRenderizable::ConstPtr = std::shared_ptr<const CRenderizable > |
Definition at line 45 of file CRenderizable.h.
using mrpt::opengl::CRenderizable::Ptr = std::shared_ptr< CRenderizable > |
Definition at line 45 of file CRenderizable.h.
CRenderizable::CRenderizable | ( | ) |
Default constructor:
Definition at line 57 of file CRenderizable.cpp.
|
virtual |
Definition at line 70 of file CRenderizable.cpp.
|
staticprotected |
|
staticprotected |
Checks glGetError and throws an exception if an error situation is found.
Definition at line 302 of file CRenderizable.cpp.
References mrpt::opengl::gl_utils::checkOpenGLError().
Referenced by mrpt::opengl::CTexturedObject::loadTextureInOpenGL(), mrpt::opengl::COpenGLViewport::render(), mrpt::opengl::CBox::render_dl(), mrpt::opengl::CSimpleLine::render_dl(), mrpt::opengl::CGridPlaneXY::render_dl(), mrpt::opengl::CGridPlaneXZ::render_dl(), mrpt::opengl::CPlanarLaserScan::render_dl(), mrpt::opengl::CSetOfLines::render_dl(), mrpt::opengl::CVectorField2D::render_dl(), mrpt::opengl::CVectorField3D::render_dl(), mrpt::opengl::CPolyhedron::render_dl(), mrpt::opengl::CTexturedObject::render_post(), mrpt::opengl::CTexturedObject::render_pre(), and mrpt::opengl::CTexturedPlane::render_texturedobj().
|
pure virtualinherited |
Returns a deep copy (clone) of the object, indepently of its class.
Implemented in mrpt::obs::CObservation3DRangeScan, mrpt::nav::CLogFileRecord_ND, mrpt::nav::CLogFileRecord_FullEval, mrpt::maps::CMultiMetricMap, mrpt::utils::CSimpleDatabase, mrpt::utils::CImage, mrpt::obs::CObservationIMU, mrpt::maps::TMapGenericParams, mrpt::poses::CPose3D, mrpt::obs::CObservationRGBD360, mrpt::maps::CRandomFieldGridMap3D, mrpt::detectors::CDetectable3D, mrpt::hmtslam::THypothesisIDSet, mrpt::maps::CMultiMetricMapPDF, mrpt::hmtslam::CLocalMetricHypothesis, mrpt::obs::CObservationVelodyneScan, mrpt::maps::CLandmarksMap, mrpt::hmtslam::CHMTSLAM, mrpt::opengl::COctoMapVoxels, mrpt::kinematics::CKinematicChain, mrpt::maps::COccupancyGridMap2D, mrpt::obs::CObservationGPS, mrpt::obs::CRawlog, mrpt::opengl::COpenGLViewport, mrpt::maps::CHeightGridMap2D, mrpt::opengl::COpenGLScene, mrpt::opengl::CPlanarLaserScan, mrpt::nav::CHolonomicFullEval, mrpt::vision::CFeature, mrpt::nav::CHolonomicND, mrpt::obs::CObservation2DRangeScan, mrpt::obs::CSensoryFrame, mrpt::opengl::CFrustum, mrpt::poses::CPose2DInterpolator, mrpt::poses::CPose3DInterpolator, mrpt::nav::CHolonomicVFF, mrpt::opengl::CEllipsoidInverseDepth3D, mrpt::opengl::CPointCloud, mrpt::opengl::CPointCloudColoured, mrpt::pbmap::PbMap, mrpt::poses::CPose3DQuat, mrpt::pbmap::Plane, mrpt::opengl::CEllipsoid, mrpt::opengl::CEllipsoidInverseDepth2D, mrpt::poses::CPose3DQuatPDFGaussianInf, mrpt::detectors::CDetectable2D, mrpt::hmtslam::CLSLAMParticleData, mrpt::maps::CBeaconMap, mrpt::poses::CPose3DRotVec, mrpt::opengl::CText3D, mrpt::opengl::CVectorField3D, mrpt::poses::CPointPDFParticles, mrpt::poses::CPose3DQuatPDFGaussian, mrpt::opengl::CAngularObservationMesh, mrpt::opengl::CEllipsoidRangeBearing2D, mrpt::opengl::CPolyhedron, mrpt::poses::CPose3DPDFGaussianInf, mrpt::maps::CReflectivityGridMap2D, mrpt::obs::CObservationStereoImages, mrpt::opengl::CAssimpModel, mrpt::maps::CBeacon, mrpt::nav::CPTG_DiffDrive_C, mrpt::opengl::CBox, mrpt::poses::CPose2D, mrpt::opengl::CMeshFast, mrpt::poses::CPose3DPDFGaussian, mrpt::hmtslam::CHMHMapNode, mrpt::hmtslam::CRobotPosesGraph, mrpt::obs::CObservationStereoImagesFeatures, mrpt::opengl::CMesh, mrpt::utils::CMHPropertiesValuesList, mrpt::opengl::CMesh3D, mrpt::opengl::CText, mrpt::poses::CPosePDFGaussianInf, mrpt::maps::CHeightGridMap2D_MRF, mrpt::nav::CPTG_DiffDrive_alpha, mrpt::maps::CRBPFParticleData, mrpt::poses::CPoint2D, mrpt::poses::CPointPDFSOG, mrpt::poses::CPose3DPDFParticles, mrpt::poses::CPosePDFParticles, mrpt::poses::CPosePDFSOG, mrpt::hmtslam::CHMHMapArc, mrpt::opengl::CColorBar, mrpt::opengl::CVectorField2D, mrpt::poses::CPose3DPDFSOG, mrpt::maps::CGasConcentrationGridMap2D, mrpt::maps::CWirelessPowerGridMap2D, mrpt::maps::CSimpleMap, mrpt::obs::CObservationImage, mrpt::opengl::CSetOfLines, mrpt::maps::CLandmark, mrpt::hmtslam::CHierarchicalMHMap, mrpt::maps::COctoMap, mrpt::obs::CActionRobotMovement2D, mrpt::obs::CObservationBatteryState, mrpt::opengl::CDisk, mrpt::poses::CPoint3D, mrpt::utils::CStringList, mrpt::utils::TCamera, mrpt::obs::CObservationOdometry, mrpt::obs::CObservationRawDAQ, mrpt::opengl::CCamera, mrpt::opengl::CCylinder, mrpt::opengl::CGridPlaneXY, mrpt::opengl::CGridPlaneXZ, mrpt::poses::CPosePDFGaussian, mrpt::maps::CColouredOctoMap, mrpt::maps::CSimplePointsMap, mrpt::nav::CLogFileRecord, mrpt::obs::CObservationBearingRange, mrpt::obs::CObservationWindSensor, mrpt::opengl::CArrow, mrpt::opengl::CAxis, mrpt::opengl::CGeneralizedCylinder, mrpt::opengl::CSphere, mrpt::slam::CIncrementalMapPartitioner, mrpt::maps::CColouredPointsMap, mrpt::maps::CWeightedPointsMap, mrpt::obs::CObservationRange, mrpt::opengl::CSetOfObjects, mrpt::obs::CActionCollection, mrpt::obs::CActionRobotMovement3D, mrpt::obs::CObservationWirelessPower, mrpt::opengl::CSetOfTexturedTriangles, mrpt::math::CSplineInterpolator1D, mrpt::nav::CLogFileRecord_VFF, mrpt::nav::CMultiObjMotionOpt_Scalarization, mrpt::nav::CPTG_Holo_Blend, mrpt::obs::CObservation6DFeatures, mrpt::obs::CObservationSkeleton, mrpt::obs::CObservationVisualLandmarks, mrpt::poses::CPosePDFGrid, mrpt::nav::CPTG_DiffDrive_CC, mrpt::nav::CPTG_DiffDrive_CCS, mrpt::nav::CPTG_DiffDrive_CS, mrpt::obs::CObservationBeaconRanges, mrpt::obs::CObservationComment, mrpt::obs::CObservationGasSensors, mrpt::obs::CObservationReflectivity, mrpt::obs::CObservationRFID, mrpt::math::CMatrixD, mrpt::poses::CPoses2DSequence, mrpt::poses::CPoses3DSequence, mrpt::opengl::C3DSScene, mrpt::opengl::COpenGLStandardObject, mrpt::math::CMatrix, mrpt::poses::CPointPDFGaussian, mrpt::utils::TStereoCamera, mrpt::opengl::CSetOfTriangles, mrpt::math::CMatrixB, mrpt::poses::TSimple3DPoint, mrpt::utils::CMemoryChunk, mrpt::utils::CPropertiesValuesList, mrpt::obs::CObservationCANBusJ1939, mrpt::obs::CObservationRobotPose, mrpt::math::CPolygon, mrpt::poses::CPoint2DPDFGaussian, mrpt::utils::CSimpleDatabaseTable, mrpt::utils::CTypeSelector, mrpt::opengl::CSimpleLine, mrpt::opengl::CTexturedPlane, mrpt::kinematics::CVehicleVelCmd_DiffDriven, and mrpt::kinematics::CVehicleVelCmd_Holo.
Referenced by mrpt::utils::CObject::duplicateGetSmartPtr(), mrpt::maps::CSimpleMap::insert(), mrpt::obs::CActionCollection::insert(), and mrpt::poses::CPoseRandomSampler::setPosePDF().
|
inline |
Enables or disables showing the name of the object as a label when rendering.
Definition at line 85 of file CRenderizable.h.
References m_show_name.
|
pure virtual |
Evaluates the bounding box of this object (including possible children) in the coordinate frame of the object parent.
Implemented in mrpt::opengl::CGeneralizedCylinder, mrpt::opengl::CVectorField3D, mrpt::opengl::COctoMapVoxels, mrpt::opengl::CAngularObservationMesh, mrpt::opengl::CSetOfLines, mrpt::opengl::CVectorField2D, mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >, mrpt::opengl::CGeneralizedEllipsoidTemplate< 2 >, mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >, mrpt::opengl::CMesh, mrpt::opengl::CSetOfTriangles, mrpt::opengl::CMeshFast, mrpt::opengl::CMesh3D, mrpt::opengl::CCylinder, mrpt::opengl::CEllipsoid, mrpt::opengl::CPolyhedron, mrpt::opengl::CPlanarLaserScan, mrpt::opengl::CFrustum, mrpt::opengl::CSetOfObjects, mrpt::opengl::CPointCloud, mrpt::opengl::CCamera, mrpt::opengl::CPointCloudColoured, mrpt::opengl::CGridPlaneXZ, mrpt::opengl::CText3D, mrpt::opengl::CGridPlaneXY, mrpt::opengl::CArrow, mrpt::opengl::CTexturedPlane, mrpt::opengl::CSimpleLine, mrpt::opengl::CSphere, mrpt::opengl::CColorBar, mrpt::opengl::CAxis, mrpt::opengl::CBox, mrpt::opengl::CDisk, mrpt::opengl::CSetOfTexturedTriangles, mrpt::opengl::CText, mrpt::opengl::COpenGLStandardObject, mrpt::opengl::CAssimpModel, and mrpt::opengl::C3DSScene.
|
inline |
Returns the object color property as a TColorf.
Definition at line 243 of file CRenderizable.h.
References m_color.
Referenced by mrpt::maps::COctoMap::getAsOctoMapVoxels(), and mrpt::maps::CColouredOctoMap::getAsOctoMapVoxels().
|
inline |
Returns the object color property as a TColor.
Definition at line 263 of file CRenderizable.h.
References m_color.
|
inline |
Color components in the range [0,1].
Definition at line 166 of file CRenderizable.h.
References mrpt::utils::TColor::A, and m_color.
Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().
|
inline |
Color components in the range [0,255].
Definition at line 174 of file CRenderizable.h.
References mrpt::utils::TColor::A, and m_color.
|
inline |
Color components in the range [0,1].
Definition at line 164 of file CRenderizable.h.
References mrpt::utils::TColor::B, and m_color.
Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().
|
inline |
Color components in the range [0,255].
Definition at line 172 of file CRenderizable.h.
References mrpt::utils::TColor::B, and m_color.
|
inline |
Color components in the range [0,1].
Definition at line 162 of file CRenderizable.h.
References mrpt::utils::TColor::G, and m_color.
Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().
|
inline |
Color components in the range [0,255].
Definition at line 170 of file CRenderizable.h.
References mrpt::utils::TColor::G, and m_color.
|
inline |
Color components in the range [0,1].
Definition at line 160 of file CRenderizable.h.
References m_color, and mrpt::utils::TColor::R.
Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().
|
inline |
Color components in the range [0,255].
Definition at line 168 of file CRenderizable.h.
References m_color, and mrpt::utils::TColor::R.
|
inline |
Returns the name of the object.
Definition at line 70 of file CRenderizable.h.
References m_name.
Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().
|
staticprotected |
Returns the lowest next free texture name (avoid using OpenGL's own function since we may call them from different threads and seem it's not cool).
Returns the lowest, free texture name.
Definition at line 73 of file CRenderizable.cpp.
References TOpenGLNameBooker::instance(), MAX_GL_TEXTURE_IDS, MAX_GL_TEXTURE_IDS_MASK, MRPT_END, MRPT_START, and THROW_EXCEPTION_FMT.
Referenced by mrpt::opengl::CTexturedObject::loadTextureInOpenGL().
mrpt::math::TPose3D CRenderizable::getPose | ( | ) | const |
Returns the 3D pose of the object as TPose3D.
Definition at line 347 of file CRenderizable.cpp.
References m_pose.
|
inline |
Rotation relative to parent coordinate origin, in DEGREES.
Definition at line 144 of file CRenderizable.h.
References m_pose, mrpt::poses::CPose3D::pitch(), and mrpt::mrpt::utils::RAD2DEG().
|
inline |
Rotation relative to parent coordinate origin, in radians.
Definition at line 156 of file CRenderizable.h.
References m_pose, and mrpt::poses::CPose3D::pitch().
|
inline |
Returns a const ref to the 3D pose of the object as mrpt::poses::CPose3D (which explicitly contains the 3x3 rotation matrix)
Definition at line 111 of file CRenderizable.h.
References m_pose.
Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().
|
inline |
Rotation relative to parent coordinate origin, in DEGREES.
Definition at line 149 of file CRenderizable.h.
References m_pose, mrpt::mrpt::utils::RAD2DEG(), and mrpt::poses::CPose3D::roll().
|
inline |
Rotation relative to parent coordinate origin, in radians.
Definition at line 158 of file CRenderizable.h.
References m_pose, and mrpt::poses::CPose3D::roll().
|
inline |
Translation relative to parent coordinate origin.
Definition at line 133 of file CRenderizable.h.
References m_pose, and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x().
|
inline |
Translation relative to parent coordinate origin.
Definition at line 135 of file CRenderizable.h.
References m_pose, and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y().
|
inline |
Rotation relative to parent coordinate origin, in DEGREES.
Definition at line 139 of file CRenderizable.h.
References m_pose, mrpt::mrpt::utils::RAD2DEG(), and mrpt::poses::CPose3D::yaw().
|
inline |
Rotation relative to parent coordinate origin, in radians.
Definition at line 154 of file CRenderizable.h.
References m_pose, and mrpt::poses::CPose3D::yaw().
|
inline |
Translation relative to parent coordinate origin.
Definition at line 137 of file CRenderizable.h.
References m_pose.
|
overridevirtual |
Returns information about the class of an object in runtime.
Reimplemented from mrpt::utils::CSerializable.
Reimplemented in mrpt::opengl::COctoMapVoxels, mrpt::opengl::CPlanarLaserScan, mrpt::opengl::CFrustum, mrpt::opengl::CEllipsoidInverseDepth3D, mrpt::opengl::CPointCloud, mrpt::opengl::CPointCloudColoured, mrpt::opengl::CEllipsoid, mrpt::opengl::CEllipsoidInverseDepth2D, mrpt::opengl::CText3D, mrpt::opengl::CVectorField3D, mrpt::opengl::CAngularObservationMesh, mrpt::opengl::CEllipsoidRangeBearing2D, mrpt::opengl::CPolyhedron, mrpt::opengl::CAssimpModel, mrpt::opengl::CBox, mrpt::opengl::CMeshFast, mrpt::opengl::CMesh, mrpt::opengl::CRenderizableDisplayList, mrpt::opengl::CMesh3D, mrpt::opengl::CText, mrpt::opengl::CColorBar, mrpt::opengl::CVectorField2D, mrpt::opengl::CSetOfLines, mrpt::opengl::CDisk, mrpt::opengl::CCamera, mrpt::opengl::CCylinder, mrpt::opengl::CGridPlaneXY, mrpt::opengl::CGridPlaneXZ, mrpt::opengl::CArrow, mrpt::opengl::CAxis, mrpt::opengl::CGeneralizedCylinder, mrpt::opengl::CSphere, mrpt::opengl::CSetOfObjects, mrpt::opengl::CSetOfTexturedTriangles, mrpt::opengl::C3DSScene, mrpt::opengl::COpenGLStandardObject, mrpt::opengl::CSetOfTriangles, mrpt::opengl::CTexturedObject, mrpt::opengl::CSimpleLine, and mrpt::opengl::CTexturedPlane.
Referenced by mrpt::opengl::COpenGLViewport::render().
|
static |
|
inline |
Get the current scaling factor in one axis.
Definition at line 237 of file CRenderizable.h.
References m_scale_x.
Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().
|
inline |
Get the current scaling factor in one axis.
Definition at line 239 of file CRenderizable.h.
References m_scale_y.
Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().
|
inline |
Get the current scaling factor in one axis.
Definition at line 241 of file CRenderizable.h.
References m_scale_z.
Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().
|
inline |
Definition at line 87 of file CRenderizable.h.
References m_show_name.
Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().
|
inline |
Is the object visible?
Definition at line 71 of file CRenderizable.h.
References m_visible.
Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().
|
protectedpure virtualinherited |
Introduces a pure virtual method responsible for loading from a CStream This can not be used directly be users, instead use "stream >> object;" for reading it from a stream or "stream >> object_ptr;" if the class is unknown apriori.
in | The input binary stream where the object data must read from. |
version | The version of the object stored in the stream: use this version number in your code to know how to read the incoming data. |
std::exception | On any error, see CStream::ReadBuffer |
Implemented in mrpt::obs::CObservation3DRangeScan, mrpt::nav::CLogFileRecord_ND, mrpt::nav::CLogFileRecord_FullEval, mrpt::maps::CMultiMetricMap, mrpt::utils::CSimpleDatabase, mrpt::utils::CImage, mrpt::obs::CObservationIMU, mrpt::maps::TMapGenericParams, mrpt::poses::CPose3D, mrpt::obs::CObservationRGBD360, mrpt::maps::CRandomFieldGridMap3D, mrpt::detectors::CDetectable3D, mrpt::hmtslam::THypothesisIDSet, mrpt::maps::CMultiMetricMapPDF, mrpt::hmtslam::CLocalMetricHypothesis, mrpt::obs::CObservationVelodyneScan, mrpt::maps::CLandmarksMap, mrpt::hmtslam::CHMTSLAM, mrpt::opengl::COctoMapVoxels, mrpt::kinematics::CKinematicChain, mrpt::maps::COccupancyGridMap2D, mrpt::obs::CObservationGPS, mrpt::obs::CRawlog, mrpt::opengl::COpenGLViewport, mrpt::maps::CHeightGridMap2D, mrpt::opengl::COpenGLScene, mrpt::opengl::CPlanarLaserScan, mrpt::nav::CHolonomicFullEval, mrpt::vision::CFeature, mrpt::nav::CHolonomicND, mrpt::obs::CObservation2DRangeScan, mrpt::obs::CSensoryFrame, mrpt::opengl::CFrustum, mrpt::poses::CPose2DInterpolator, mrpt::poses::CPose3DInterpolator, mrpt::nav::CHolonomicVFF, mrpt::opengl::CEllipsoidInverseDepth3D, mrpt::opengl::CPointCloud, mrpt::opengl::CPointCloudColoured, mrpt::pbmap::PbMap, mrpt::poses::CPose3DQuat, mrpt::pbmap::Plane, mrpt::opengl::CEllipsoid, mrpt::opengl::CEllipsoidInverseDepth2D, mrpt::poses::CPose3DQuatPDFGaussianInf, mrpt::detectors::CDetectable2D, mrpt::hmtslam::CLSLAMParticleData, mrpt::maps::CBeaconMap, mrpt::poses::CPose3DRotVec, mrpt::opengl::CText3D, mrpt::opengl::CVectorField3D, mrpt::poses::CPointPDFParticles, mrpt::poses::CPose3DQuatPDFGaussian, mrpt::opengl::CAngularObservationMesh, mrpt::opengl::CEllipsoidRangeBearing2D, mrpt::opengl::CPolyhedron, mrpt::poses::CPose3DPDFGaussianInf, mrpt::maps::CReflectivityGridMap2D, mrpt::obs::CObservationStereoImages, mrpt::opengl::CAssimpModel, mrpt::maps::CBeacon, mrpt::nav::CPTG_DiffDrive_C, mrpt::opengl::CBox, mrpt::poses::CPose2D, mrpt::opengl::CMeshFast, mrpt::poses::CPose3DPDFGaussian, mrpt::hmtslam::CHMHMapNode, mrpt::hmtslam::CRobotPosesGraph, mrpt::obs::CObservationStereoImagesFeatures, mrpt::opengl::CMesh, mrpt::utils::CMHPropertiesValuesList, mrpt::opengl::CMesh3D, mrpt::opengl::CText, mrpt::poses::CPosePDFGaussianInf, mrpt::maps::CHeightGridMap2D_MRF, mrpt::nav::CPTG_DiffDrive_alpha, mrpt::maps::CRBPFParticleData, mrpt::poses::CPoint2D, mrpt::poses::CPointPDFSOG, mrpt::poses::CPose3DPDFParticles, mrpt::poses::CPosePDFParticles, mrpt::poses::CPosePDFSOG, mrpt::hmtslam::CHMHMapArc, mrpt::opengl::CColorBar, mrpt::opengl::CVectorField2D, mrpt::poses::CPose3DPDFSOG, mrpt::maps::CGasConcentrationGridMap2D, mrpt::maps::CWirelessPowerGridMap2D, mrpt::maps::CSimpleMap, mrpt::obs::CObservationImage, mrpt::opengl::CSetOfLines, mrpt::maps::CLandmark, mrpt::hmtslam::CHierarchicalMHMap, mrpt::maps::COctoMap, mrpt::obs::CActionRobotMovement2D, mrpt::obs::CObservationBatteryState, mrpt::opengl::CDisk, mrpt::poses::CPoint3D, mrpt::utils::CStringList, mrpt::utils::TCamera, mrpt::obs::CObservationOdometry, mrpt::obs::CObservationRawDAQ, mrpt::opengl::CCamera, mrpt::opengl::CCylinder, mrpt::opengl::CGridPlaneXY, mrpt::opengl::CGridPlaneXZ, mrpt::poses::CPosePDFGaussian, mrpt::maps::CColouredOctoMap, mrpt::maps::CSimplePointsMap, mrpt::nav::CLogFileRecord, mrpt::obs::CObservationBearingRange, mrpt::obs::CObservationWindSensor, mrpt::opengl::CArrow, mrpt::opengl::CAxis, mrpt::opengl::CGeneralizedCylinder, mrpt::opengl::CSphere, mrpt::slam::CIncrementalMapPartitioner, mrpt::maps::CColouredPointsMap, mrpt::maps::CWeightedPointsMap, mrpt::obs::CObservationRange, mrpt::opengl::CSetOfObjects, mrpt::obs::CActionCollection, mrpt::obs::CActionRobotMovement3D, mrpt::obs::CObservationWirelessPower, mrpt::opengl::CSetOfTexturedTriangles, mrpt::math::CSplineInterpolator1D, mrpt::nav::CLogFileRecord_VFF, mrpt::nav::CPTG_Holo_Blend, mrpt::obs::CObservation6DFeatures, mrpt::obs::CObservationSkeleton, mrpt::obs::CObservationVisualLandmarks, mrpt::poses::CPosePDFGrid, mrpt::nav::CPTG_DiffDrive_CC, mrpt::nav::CPTG_DiffDrive_CCS, mrpt::nav::CPTG_DiffDrive_CS, mrpt::obs::CObservationBeaconRanges, mrpt::obs::CObservationComment, mrpt::obs::CObservationGasSensors, mrpt::obs::CObservationReflectivity, mrpt::obs::CObservationRFID, mrpt::math::CMatrixD, mrpt::poses::CPoses2DSequence, mrpt::poses::CPoses3DSequence, mrpt::opengl::C3DSScene, mrpt::opengl::COpenGLStandardObject, mrpt::math::CMatrix, mrpt::poses::CPointPDFGaussian, mrpt::utils::TStereoCamera, mrpt::opengl::CSetOfTriangles, mrpt::math::CMatrixB, mrpt::poses::TSimple3DPoint, mrpt::utils::CMemoryChunk, mrpt::utils::CPropertiesValuesList, mrpt::obs::CObservationCANBusJ1939, mrpt::obs::CObservationRobotPose, mrpt::math::CPolygon, mrpt::poses::CPoint2DPDFGaussian, mrpt::utils::CSimpleDatabaseTable, mrpt::utils::CTypeSelector, mrpt::opengl::CSimpleLine, mrpt::opengl::CTexturedPlane, mrpt::kinematics::CVehicleVelCmd_DiffDriven, and mrpt::kinematics::CVehicleVelCmd_Holo.
|
protected |
Definition at line 165 of file CRenderizable.cpp.
References mrpt::utils::TColor::A, mrpt::utils::TColorf::A, mrpt::utils::TColor::B, mrpt::utils::TColorf::B, DEG2RAD, mrpt::utils::TColor::G, mrpt::utils::TColorf::G, m_color, m_name, m_pose, m_scale_x, m_scale_y, m_scale_z, m_show_name, m_visible, mrpt::obs::gnss::pitch, mrpt::utils::TColor::R, mrpt::utils::TColorf::R, mrpt::obs::gnss::roll, mrpt::poses::CPose3D::setYawPitchRoll(), THROW_EXCEPTION_FMT, mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x(), and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y().
Referenced by mrpt::opengl::CRenderizableDisplayList::readFromStreamRender().
|
staticprotected |
Definition at line 101 of file CRenderizable.cpp.
References TOpenGLNameBooker::cs, TOpenGLNameBooker::freeTextureNames, TOpenGLNameBooker::instance(), and TOpenGLNameBooker::next_free_texture.
Referenced by mrpt::opengl::CTexturedObject::unloadTexture().
|
pure virtual |
Implements the rendering of 3D objects in each class derived from CRenderizable.
Implemented in mrpt::opengl::CPointCloud, mrpt::opengl::CPointCloudColoured, mrpt::opengl::CCamera, mrpt::opengl::CRenderizableDisplayList, mrpt::opengl::CSetOfObjects, and mrpt::opengl::CText.
Referenced by mrpt::opengl::gl_utils::renderSetOfObjects().
This method is safe for calling from within ::render() methods.
Definition at line 380 of file CRenderizable.cpp.
References mrpt::opengl::gl_utils::renderTextBitmap().
|
static |
Render a text message in the current rendering context, creating a glViewport in the way (do not call within ::render() methods)
Definition at line 315 of file gl_utils.cpp.
References aux_mrptfont2glutfont(), GL_DEPTH_TEST, GL_MODELVIEW, GL_PROJECTION, GL_TRANSFORM_BIT, GL_VIEWPORT, GL_VIEWPORT_BIT, glColor3f(), glDisable(), glEnable(), glGetIntegerv(), glLoadIdentity(), glMatrixMode(), glPopAttrib(), glPopMatrix(), glPushAttrib(), glPushMatrix(), glRasterPos3f(), glViewport(), and MRPT_UNUSED_PARAM.
|
inline |
Changes the default object color.
Definition at line 248 of file CRenderizable.h.
References setColor_u8().
Referenced by mrpt::hwdrivers::CSkeletonTracker::processPreview().
|
inline |
Set the color components of this object (R,G,B,Alpha, in the range 0-1)
Definition at line 257 of file CRenderizable.h.
References R, and setColor_u8().
|
virtual |
Reimplemented in mrpt::opengl::CSetOfTriangles, mrpt::opengl::CRenderizableDisplayList, and mrpt::opengl::CSetOfObjects.
Definition at line 369 of file CRenderizable.cpp.
References mrpt::utils::TColor::A, mrpt::utils::TColor::B, mrpt::utils::TColor::G, m_color, and mrpt::utils::TColor::R.
Referenced by setColor(), mrpt::opengl::CRenderizableDisplayList::setColor_u8(), setColor_u8(), and mrpt::graphslam::deciders::CLoopCloserERD< GRAPH_T >::updateMapPartitionsVisualization().
|
inline |
Set the color components of this object (R,G,B,Alpha, in the range 0-255)
Definition at line 269 of file CRenderizable.h.
References R, and setColor_u8().
|
inline |
Color components in the range [0,1].
Definition at line 191 of file CRenderizable.h.
References setColorA_u8().
|
inlinevirtual |
Color components in the range [0,255].
Reimplemented in mrpt::opengl::CSetOfTriangles, mrpt::opengl::CSetOfObjects, and mrpt::opengl::CRenderizableDisplayList.
Definition at line 214 of file CRenderizable.h.
References mrpt::utils::TColor::A, and m_color.
Referenced by setColorA(), and mrpt::opengl::CSetOfObjects::setColorA_u8().
|
inline |
Color components in the range [0,1].
Definition at line 186 of file CRenderizable.h.
References setColorB_u8().
|
inlinevirtual |
Color components in the range [0,255].
Reimplemented in mrpt::opengl::CSetOfTriangles, mrpt::opengl::CSetOfObjects, and mrpt::opengl::CRenderizableDisplayList.
Definition at line 208 of file CRenderizable.h.
References mrpt::utils::TColor::B, and m_color.
Referenced by setColorB(), and mrpt::opengl::CSetOfObjects::setColorB_u8().
|
inline |
Color components in the range [0,1].
Definition at line 181 of file CRenderizable.h.
References setColorG_u8().
|
inlinevirtual |
Color components in the range [0,255].
Reimplemented in mrpt::opengl::CSetOfTriangles, mrpt::opengl::CSetOfObjects, and mrpt::opengl::CRenderizableDisplayList.
Definition at line 202 of file CRenderizable.h.
References mrpt::utils::TColor::G, and m_color.
Referenced by setColorG(), and mrpt::opengl::CSetOfObjects::setColorG_u8().
|
inline |
Color components in the range [0,1].
Definition at line 176 of file CRenderizable.h.
References setColorR_u8().
|
inlinevirtual |
Color components in the range [0,255].
Reimplemented in mrpt::opengl::CSetOfTriangles, mrpt::opengl::CSetOfObjects, and mrpt::opengl::CRenderizableDisplayList.
Definition at line 196 of file CRenderizable.h.
References m_color, and mrpt::utils::TColor::R.
Referenced by setColorR(), and mrpt::opengl::CSetOfObjects::setColorR_u8().
|
inline |
Changes the location of the object, keeping untouched the orientation.
Definition at line 114 of file CRenderizable.h.
References m_pose, mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x(), and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y().
Referenced by mrpt::graphslam::deciders::CLoopCloserERD< GRAPH_T >::updateCurrCovarianceVisualization(), and mrpt::graphslam::deciders::CLoopCloserERD< GRAPH_T >::updateMapPartitionsVisualization().
|
inline |
Changes the location of the object, keeping untouched the orientation.
Definition at line 124 of file CRenderizable.h.
References m_pose, mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x(), and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y().
|
inline |
CRenderizable & CRenderizable::setPose | ( | const mrpt::poses::CPose3D & | o | ) |
Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this)
Definition at line 310 of file CRenderizable.cpp.
References m_pose.
Referenced by mrpt::hwdrivers::CSkeletonTracker::processPreview(), mrpt::kinematics::CKinematicChain::update3DObject(), mrpt::graphslam::CGraphSlamEngine< GRAPH_T >::updateEstimatedTrajectoryVisualization(), mrpt::graphslam::CGraphSlamEngine< GRAPH_T >::updateGTVisualization(), mrpt::graphslam::CGraphSlamEngine< GRAPH_T >::updateOdometryVisualization(), and mrpt::graphslam::deciders::CICPCriteriaERD< GRAPH_T >::updateVisuals().
CRenderizable & CRenderizable::setPose | ( | const mrpt::poses::CPose2D & | o | ) |
Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this)
Definition at line 315 of file CRenderizable.cpp.
References m_pose.
CRenderizable & CRenderizable::setPose | ( | const mrpt::math::TPose3D & | o | ) |
Set the 3D pose from a mrpt::math::TPose3D object (return a ref to this)
Definition at line 320 of file CRenderizable.cpp.
References m_pose.
CRenderizable & CRenderizable::setPose | ( | const mrpt::math::TPose2D & | o | ) |
Set the 3D pose from a mrpt::math::TPose3D object (return a ref to this)
Definition at line 325 of file CRenderizable.cpp.
References m_pose.
CRenderizable & CRenderizable::setPose | ( | const mrpt::poses::CPoint3D & | o | ) |
Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this)
Set the 3D pose from a mrpt::poses::CPose3D object.
Definition at line 332 of file CRenderizable.cpp.
References m_pose, mrpt::poses::CPose3D::setFromValues(), mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x(), and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y().
CRenderizable & CRenderizable::setPose | ( | const mrpt::poses::CPoint2D & | o | ) |
Set the 3D pose from a mrpt::poses::CPose3D object (return a ref to this)
Set the 3D pose from a mrpt::poses::CPose3D object.
Definition at line 338 of file CRenderizable.cpp.
References m_pose, mrpt::poses::CPose3D::setFromValues(), mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x(), and mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y().
|
inline |
Scale to apply to the object, in all three axes (default=1)
Definition at line 222 of file CRenderizable.h.
References m_scale_x, m_scale_y, and m_scale_z.
Referenced by mrpt::opengl::CText3D::CText3D().
|
inline |
Scale to apply to the object in each axis (default=1)
Definition at line 229 of file CRenderizable.h.
|
inline |
Set object visibility (default=true)
Definition at line 76 of file CRenderizable.h.
References m_visible.
Referenced by mrpt::hwdrivers::CSkeletonTracker::processPreview(), mrpt::hwdrivers::CSkeletonTracker::processPreviewNone(), and mrpt::graphslam::deciders::CLoopCloserERD< GRAPH_T >::updateMapPartitionsVisualization().
|
static |
Return the exact width in pixels for a given string, as will be rendered by renderTextBitmap().
Definition at line 389 of file CRenderizable.cpp.
References mrpt::opengl::gl_utils::textBitmapWidth().
|
virtual |
Simulation of ray-trace, given a pose.
Returns true if the ray effectively collisions with the object (returning the distance to the origin of the ray in "dist"), or false in other case. "dist" variable yields undefined behaviour when false is returned
Reimplemented in mrpt::opengl::CPolyhedron, mrpt::opengl::CAngularObservationMesh, mrpt::opengl::CMesh, mrpt::opengl::CGeneralizedEllipsoidTemplate< DIM >, mrpt::opengl::CGeneralizedEllipsoidTemplate< 2 >, mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >, mrpt::opengl::CSetOfTriangles, mrpt::opengl::CEllipsoid, mrpt::opengl::CGeneralizedCylinder, mrpt::opengl::CFrustum, mrpt::opengl::CSetOfObjects, mrpt::opengl::CSetOfTexturedTriangles, mrpt::opengl::CSphere, mrpt::opengl::CBox, mrpt::opengl::CTexturedPlane, mrpt::opengl::CDisk, mrpt::opengl::CAssimpModel, mrpt::opengl::C3DSScene, mrpt::opengl::CCylinder, and mrpt::opengl::COpenGLStandardObject.
Definition at line 355 of file CRenderizable.cpp.
References MRPT_UNUSED_PARAM.
|
inlinevirtualinherited |
Introduces a pure virtual method responsible for writing to a mxArray
Matlab object, typically a MATLAB struct
whose contents are documented in each derived class.
mxArray
(caller is responsible of memory freeing) or nullptr is class does not support conversion to MATLAB. Definition at line 89 of file CSerializable.h.
|
protectedpure virtualinherited |
Introduces a pure virtual method responsible for writing to a CStream.
This can not be used directly be users, instead use "stream << object;" for writing it to a stream.
out | The output binary stream where object must be dumped. |
getVersion | If nullptr, the object must be dumped. If not, only the version of the object dump must be returned in this pointer. This enables the versioning of objects dumping and backward compatibility with previously stored data. |
std::exception | On any error, see CStream::WriteBuffer |
Implemented in mrpt::obs::CObservation3DRangeScan, mrpt::nav::CLogFileRecord_ND, mrpt::nav::CLogFileRecord_FullEval, mrpt::maps::CMultiMetricMap, mrpt::utils::CSimpleDatabase, mrpt::utils::CImage, mrpt::obs::CObservationIMU, mrpt::maps::TMapGenericParams, mrpt::poses::CPose3D, mrpt::obs::CObservationRGBD360, mrpt::maps::CRandomFieldGridMap3D, mrpt::detectors::CDetectable3D, mrpt::hmtslam::THypothesisIDSet, mrpt::maps::CMultiMetricMapPDF, mrpt::hmtslam::CLocalMetricHypothesis, mrpt::obs::CObservationVelodyneScan, mrpt::maps::CLandmarksMap, mrpt::hmtslam::CHMTSLAM, mrpt::opengl::COctoMapVoxels, mrpt::kinematics::CKinematicChain, mrpt::maps::COccupancyGridMap2D, mrpt::obs::CObservationGPS, mrpt::obs::CRawlog, mrpt::opengl::COpenGLViewport, mrpt::maps::CHeightGridMap2D, mrpt::opengl::COpenGLScene, mrpt::opengl::CPlanarLaserScan, mrpt::nav::CHolonomicFullEval, mrpt::vision::CFeature, mrpt::nav::CHolonomicND, mrpt::obs::CObservation2DRangeScan, mrpt::obs::CSensoryFrame, mrpt::opengl::CFrustum, mrpt::poses::CPose2DInterpolator, mrpt::poses::CPose3DInterpolator, mrpt::nav::CHolonomicVFF, mrpt::opengl::CEllipsoidInverseDepth3D, mrpt::opengl::CPointCloud, mrpt::opengl::CPointCloudColoured, mrpt::pbmap::PbMap, mrpt::poses::CPose3DQuat, mrpt::pbmap::Plane, mrpt::opengl::CEllipsoid, mrpt::opengl::CEllipsoidInverseDepth2D, mrpt::poses::CPose3DQuatPDFGaussianInf, mrpt::detectors::CDetectable2D, mrpt::hmtslam::CLSLAMParticleData, mrpt::maps::CBeaconMap, mrpt::poses::CPose3DRotVec, mrpt::opengl::CText3D, mrpt::opengl::CVectorField3D, mrpt::poses::CPointPDFParticles, mrpt::poses::CPose3DQuatPDFGaussian, mrpt::opengl::CAngularObservationMesh, mrpt::opengl::CEllipsoidRangeBearing2D, mrpt::opengl::CPolyhedron, mrpt::poses::CPose3DPDFGaussianInf, mrpt::maps::CReflectivityGridMap2D, mrpt::obs::CObservationStereoImages, mrpt::opengl::CAssimpModel, mrpt::maps::CBeacon, mrpt::nav::CPTG_DiffDrive_C, mrpt::opengl::CBox, mrpt::poses::CPose2D, mrpt::opengl::CMeshFast, mrpt::poses::CPose3DPDFGaussian, mrpt::hmtslam::CHMHMapNode, mrpt::hmtslam::CRobotPosesGraph, mrpt::obs::CObservationStereoImagesFeatures, mrpt::opengl::CMesh, mrpt::utils::CMHPropertiesValuesList, mrpt::opengl::CMesh3D, mrpt::opengl::CText, mrpt::poses::CPosePDFGaussianInf, mrpt::maps::CHeightGridMap2D_MRF, mrpt::nav::CPTG_DiffDrive_alpha, mrpt::maps::CRBPFParticleData, mrpt::poses::CPoint2D, mrpt::poses::CPointPDFSOG, mrpt::poses::CPose3DPDFParticles, mrpt::poses::CPosePDFParticles, mrpt::poses::CPosePDFSOG, mrpt::hmtslam::CHMHMapArc, mrpt::opengl::CColorBar, mrpt::opengl::CVectorField2D, mrpt::poses::CPose3DPDFSOG, mrpt::maps::CGasConcentrationGridMap2D, mrpt::maps::CWirelessPowerGridMap2D, mrpt::maps::CSimpleMap, mrpt::obs::CObservationImage, mrpt::opengl::CSetOfLines, mrpt::maps::CLandmark, mrpt::hmtslam::CHierarchicalMHMap, mrpt::maps::COctoMap, mrpt::obs::CActionRobotMovement2D, mrpt::obs::CObservationBatteryState, mrpt::opengl::CDisk, mrpt::poses::CPoint3D, mrpt::utils::CStringList, mrpt::utils::TCamera, mrpt::obs::CObservationOdometry, mrpt::obs::CObservationRawDAQ, mrpt::opengl::CCamera, mrpt::opengl::CCylinder, mrpt::opengl::CGridPlaneXY, mrpt::opengl::CGridPlaneXZ, mrpt::poses::CPosePDFGaussian, mrpt::maps::CColouredOctoMap, mrpt::maps::CSimplePointsMap, mrpt::nav::CLogFileRecord, mrpt::obs::CObservationBearingRange, mrpt::obs::CObservationWindSensor, mrpt::opengl::CArrow, mrpt::opengl::CAxis, mrpt::opengl::CGeneralizedCylinder, mrpt::opengl::CSphere, mrpt::slam::CIncrementalMapPartitioner, mrpt::maps::CColouredPointsMap, mrpt::maps::CWeightedPointsMap, mrpt::obs::CObservationRange, mrpt::opengl::CSetOfObjects, mrpt::obs::CActionCollection, mrpt::obs::CActionRobotMovement3D, mrpt::obs::CObservationWirelessPower, mrpt::opengl::CSetOfTexturedTriangles, mrpt::math::CSplineInterpolator1D, mrpt::nav::CLogFileRecord_VFF, mrpt::nav::CPTG_Holo_Blend, mrpt::obs::CObservation6DFeatures, mrpt::obs::CObservationSkeleton, mrpt::obs::CObservationVisualLandmarks, mrpt::poses::CPosePDFGrid, mrpt::nav::CPTG_DiffDrive_CC, mrpt::nav::CPTG_DiffDrive_CCS, mrpt::nav::CPTG_DiffDrive_CS, mrpt::obs::CObservationBeaconRanges, mrpt::obs::CObservationComment, mrpt::obs::CObservationGasSensors, mrpt::obs::CObservationReflectivity, mrpt::obs::CObservationRFID, mrpt::math::CMatrixD, mrpt::poses::CPoses2DSequence, mrpt::poses::CPoses3DSequence, mrpt::opengl::C3DSScene, mrpt::opengl::COpenGLStandardObject, mrpt::math::CMatrix, mrpt::poses::CPointPDFGaussian, mrpt::utils::TStereoCamera, mrpt::opengl::CSetOfTriangles, mrpt::math::CMatrixB, mrpt::poses::TSimple3DPoint, mrpt::utils::CMemoryChunk, mrpt::utils::CPropertiesValuesList, mrpt::obs::CObservationCANBusJ1939, mrpt::obs::CObservationRobotPose, mrpt::math::CPolygon, mrpt::poses::CPoint2DPDFGaussian, mrpt::utils::CSimpleDatabaseTable, mrpt::utils::CTypeSelector, mrpt::opengl::CSimpleLine, mrpt::opengl::CTexturedPlane, mrpt::kinematics::CVehicleVelCmd_DiffDriven, and mrpt::kinematics::CVehicleVelCmd_Holo.
Referenced by mrpt::utils::CStream::WriteObject(), mrpt::maps::CColouredOctoMap::writeToStream(), and mrpt::maps::COctoMap::writeToStream().
|
protected |
Definition at line 112 of file CRenderizable.cpp.
References mrpt::utils::TColor::A, mrpt::utils::TColor::B, mrpt::utils::TColor::G, m_color, m_name, m_pose, m_scale_x, m_scale_y, m_scale_z, m_show_name, m_visible, mrpt::poses::CPose3D::pitch(), mrpt::utils::TColor::R, mrpt::poses::CPose3D::roll(), mrpt::utils::CStream::WriteBuffer(), mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::x(), mrpt::poses::CPoseOrPoint< DERIVEDCLASS >::y(), and mrpt::poses::CPose3D::yaw().
Referenced by mrpt::opengl::CSimpleLine::writeToStream(), mrpt::opengl::CTexturedPlane::writeToStream(), mrpt::opengl::CGridPlaneXZ::writeToStream(), mrpt::opengl::CGridPlaneXY::writeToStream(), mrpt::opengl::CSetOfLines::writeToStream(), mrpt::opengl::CVectorField2D::writeToStream(), mrpt::opengl::CBox::writeToStream(), mrpt::opengl::CPolyhedron::writeToStream(), mrpt::opengl::CVectorField3D::writeToStream(), mrpt::opengl::CText3D::writeToStream(), mrpt::opengl::CFrustum::writeToStream(), and mrpt::opengl::CPlanarLaserScan::writeToStream().
|
friend |
Definition at line 47 of file CRenderizable.h.
|
friend |
Definition at line 48 of file CRenderizable.h.
|
friend |
Definition at line 45 of file CRenderizable.h.
|
protected |
Color components in the range [0,255].
Definition at line 54 of file CRenderizable.h.
Referenced by mrpt::opengl::CMeshFast::CMeshFast(), mrpt::opengl::CVectorField2D::CVectorField2D(), mrpt::opengl::CVectorField3D::CVectorField3D(), getColor(), getColor_u8(), getColorA(), getColorA_u8(), getColorB(), getColorB_u8(), getColorG(), getColorG_u8(), getColorR(), getColorR_u8(), readFromStreamRender(), mrpt::opengl::CBox::render_dl(), mrpt::opengl::CSimpleLine::render_dl(), mrpt::opengl::CText3D::render_dl(), mrpt::opengl::CSetOfLines::render_dl(), mrpt::opengl::CVectorField2D::render_dl(), mrpt::opengl::CVectorField3D::render_dl(), mrpt::opengl::CPolyhedron::render_dl(), mrpt::opengl::CTexturedObject::render_post(), mrpt::opengl::CTexturedObject::render_pre(), setColor_u8(), mrpt::opengl::CRenderizableDisplayList::setColorA_u8(), setColorA_u8(), mrpt::opengl::CRenderizableDisplayList::setColorB_u8(), setColorB_u8(), mrpt::opengl::CRenderizableDisplayList::setColorG_u8(), setColorG_u8(), mrpt::opengl::CRenderizableDisplayList::setColorR_u8(), setColorR_u8(), and writeToStreamRender().
|
protected |
Definition at line 51 of file CRenderizable.h.
Referenced by getName(), readFromStreamRender(), setName(), and writeToStreamRender().
|
protected |
6D pose wrt the parent coordinate reference.
This class automatically holds the cached 3x3 rotation matrix for quick load into opengl stack.
Definition at line 57 of file CRenderizable.h.
Referenced by mrpt::opengl::C3DSScene::getBoundingBox(), mrpt::opengl::CAssimpModel::getBoundingBox(), mrpt::opengl::CBox::getBoundingBox(), mrpt::opengl::CSimpleLine::getBoundingBox(), mrpt::opengl::CTexturedPlane::getBoundingBox(), mrpt::opengl::CGridPlaneXY::getBoundingBox(), mrpt::opengl::CText3D::getBoundingBox(), mrpt::opengl::CGridPlaneXZ::getBoundingBox(), mrpt::opengl::CFrustum::getBoundingBox(), mrpt::opengl::CPlanarLaserScan::getBoundingBox(), mrpt::opengl::CPolyhedron::getBoundingBox(), mrpt::opengl::CVectorField2D::getBoundingBox(), mrpt::opengl::CSetOfLines::getBoundingBox(), mrpt::opengl::CVectorField3D::getBoundingBox(), getPose(), getPosePitch(), getPosePitchRad(), getPoseRef(), getPoseRoll(), getPoseRollRad(), getPoseX(), getPoseY(), getPoseYaw(), getPoseYawRad(), getPoseZ(), mrpt::opengl::CPolyhedron::getSetOfPolygonsAbsolute(), readFromStreamRender(), mrpt::opengl::CGeneralizedEllipsoidTemplate< 3 >::render_dl(), setLocation(), setPose(), mrpt::opengl::CTexturedPlane::traceRay(), mrpt::opengl::CPolyhedron::traceRay(), and writeToStreamRender().
|
protected |
Scale components to apply to the object (default=1)
Definition at line 59 of file CRenderizable.h.
Referenced by mrpt::opengl::CText3D::getBoundingBox(), getScaleX(), readFromStreamRender(), setScale(), and writeToStreamRender().
|
protected |
Definition at line 59 of file CRenderizable.h.
Referenced by getScaleY(), readFromStreamRender(), setScale(), and writeToStreamRender().
|
protected |
Definition at line 59 of file CRenderizable.h.
Referenced by getScaleZ(), readFromStreamRender(), setScale(), and writeToStreamRender().
|
protected |
Definition at line 52 of file CRenderizable.h.
Referenced by enableShowName(), isShowNameEnabled(), readFromStreamRender(), and writeToStreamRender().
|
protected |
Is the object visible? (default=true)
Definition at line 61 of file CRenderizable.h.
Referenced by isVisible(), readFromStreamRender(), setVisibility(), and writeToStreamRender().
|
staticprotected |
Definition at line 45 of file CRenderizable.h.
Page generated by Doxygen 1.8.14 for MRPT 1.9.9 Git: ae4571287 Thu Nov 23 00:06:53 2017 +0100 at dom oct 27 23:51:55 CET 2019 |
