Detailed Description

An abstract class for accessing OpenNI2 compatible sensors.

This class permits to access several sensors simultaneously. The same options (resolution, fps, etc.) are used for every sensor.

More references to read:

http://http://www.openni.org/

Definition at line 26 of file COpenNI2Generic.h.

#include <mrpt/hwdrivers/COpenNI2Generic.h>

Inheritance diagram for mrpt::hwdrivers::COpenNI2Generic:

Classes
class	CDevice

Public Member Functions
	COpenNI2Generic ()
	Default ctor (width=640, height=480, fps=30) More...

	COpenNI2Generic (int width, int height, float fps=30.0f, bool open_streams_now=true)
	Ctor. More...

	~COpenNI2Generic ()
	Default ctor. More...

void	getNextFrameRGB (mrpt::utils::CImage &rgb_img, uint64_t &timestamp, bool &there_is_obs, bool &hardware_error, unsigned sensor_id=0)
	The main data retrieving function, to be called after calling loadConfig() and initialize(). More...

void	getNextFrameD (mrpt::math::CMatrix &depth_img, uint64_t &timestamp, bool &there_is_obs, bool &hardware_error, unsigned sensor_id=0)
	The main data retrieving function, to be called after calling loadConfig() and initialize(). More...

void	getNextFrameRGBD (mrpt::obs::CObservation3DRangeScan &out_obs, bool &there_is_obs, bool &hardware_error, unsigned sensor_id=0)
	The main data retrieving function, to be called after calling loadConfig() and initialize(). More...

void	setVerbose (bool verbose)

bool	isVerbose () const

bool	getColorSensorParam (mrpt::utils::TCamera &param, unsigned sensor_id=0) const

bool	getDepthSensorParam (mrpt::utils::TCamera &param, unsigned sensor_id=0) const

Open/Close device methods
void	open (unsigned sensor_id=0)
	Try to open the camera (all the parameters [resolution,fps,...] must be set before calling this) - users may also call initialize(), which in turn calls this method. More...

unsigned int	openDevicesBySerialNum (const std::set< unsigned > &vSerialRequired)
	Open a set of RGBD devices specified by their serial number. More...

unsigned int	openDeviceBySerial (const unsigned int SerialRequired)
	Open a RGBD device specified by its serial number. More...

bool	getDeviceIDFromSerialNum (const unsigned int SerialRequired, int &sensor_id) const
	Get the ID of the device corresponding to 'SerialRequired'. More...

bool	start ()
	Open all sensor streams (normally called automatically at constructor, no need to call it manually). More...

void	kill ()
	Kill the OpenNI2 driver. More...

bool	isOpen (const unsigned sensor_id) const
	Whether there is a working connection to the sensor. More...

void	close (unsigned sensor_id=0)
	Close the connection to the sensor (no need to call it manually unless desired for some reason, since it's called at destructor. More...

int	getNumDevices () const
	The number of available devices at initialization. More...

int	getConnectedDevices ()
	Get a list of the connected OpenNI2 sensors. More...

Protected Member Functions
void	showLog (const std::string &message) const

Protected Attributes
std::vector< int >	vSerialNums
	A vector with the serial numbers of the available devices. More...

int	m_width
	The same options (width, height and fps) are set for all the sensors. More...

int	m_height

float	m_fps

int	m_rgb_format

int	m_depth_format

bool	m_verbose

bool	m_grab_image
	The data that the RGBD sensors can return. More...

bool	m_grab_depth

bool	m_grab_3D_points

Static Protected Attributes
static std::vector< std::shared_ptr< CDevice > >	vDevices

static int	numInstances = 0

Constructor & Destructor Documentation

◆ COpenNI2Generic() [1/2]

COpenNI2Generic::COpenNI2Generic ( )

Default ctor (width=640, height=480, fps=30)

Definition at line 56 of file COpenNI2Generic.cpp.

References mrpt::mrpt::format(), m_verbose, start(), and THROW_EXCEPTION.

Here is the call graph for this function:

◆ COpenNI2Generic() [2/2]

COpenNI2Generic::COpenNI2Generic	(	int	width,
		int	height,
		float	fps = `30.0f`,
		bool	open_streams_now = `true`
	)

Ctor.

See also: start()

Definition at line 83 of file COpenNI2Generic.cpp.

References mrpt::mrpt::format(), m_verbose, start(), and THROW_EXCEPTION.

Here is the call graph for this function:

◆ ~COpenNI2Generic()

COpenNI2Generic::~COpenNI2Generic ( )

Default ctor.

Definition at line 139 of file COpenNI2Generic.cpp.

References kill(), and numInstances.

Here is the call graph for this function:

Member Function Documentation

◆ close()

void COpenNI2Generic::close ( unsigned sensor_id = 0 )

Close the connection to the sensor (no need to call it manually unless desired for some reason, since it's called at destructor.

Definition at line 389 of file COpenNI2Generic.cpp.

References getNumDevices(), MRPT_UNUSED_PARAM, THROW_EXCEPTION, and vDevices.

Here is the call graph for this function:

◆ getColorSensorParam()

bool COpenNI2Generic::getColorSensorParam	(	mrpt::utils::TCamera &	param,
		unsigned	sensor_id = `0`
	)		const

Definition at line 531 of file COpenNI2Generic.cpp.

References mrpt::hwdrivers::COpenNI2Generic::CDevice::COLOR_STREAM, isOpen(), MRPT_UNUSED_PARAM, THROW_EXCEPTION, and vDevices.

Here is the call graph for this function:

◆ getConnectedDevices()

int COpenNI2Generic::getConnectedDevices ( )

Get a list of the connected OpenNI2 sensors.

This method can or cannot be implemented in the derived class, depending on the need for it.

Exceptions

This	method must throw an exception with a descriptive message if some critical error is found.

Definition at line 164 of file COpenNI2Generic.cpp.

References mrpt::mrpt::format(), getNumDevices(), m_depth_format, m_rgb_format, m_verbose, showLog(), THROW_EXCEPTION, and vDevices.

Here is the call graph for this function:

◆ getDepthSensorParam()

bool COpenNI2Generic::getDepthSensorParam	(	mrpt::utils::TCamera &	param,
		unsigned	sensor_id = `0`
	)		const

Definition at line 547 of file COpenNI2Generic.cpp.

References mrpt::hwdrivers::COpenNI2Generic::CDevice::DEPTH_STREAM, isOpen(), MRPT_UNUSED_PARAM, THROW_EXCEPTION, and vDevices.

Here is the call graph for this function:

◆ getDeviceIDFromSerialNum()

bool COpenNI2Generic::getDeviceIDFromSerialNum	(	const unsigned int	SerialRequired,
		int &	sensor_id
	)		const

Get the ID of the device corresponding to 'SerialRequired'.

Definition at line 364 of file COpenNI2Generic.cpp.

References MRPT_UNUSED_PARAM, THROW_EXCEPTION, and vDevices.

◆ getNextFrameD()

void COpenNI2Generic::getNextFrameD	(	mrpt::math::CMatrix &	depth_img,
		uint64_t &	timestamp,
		bool &	there_is_obs,
		bool &	hardware_error,
		unsigned	sensor_id = `0`
	)

The main data retrieving function, to be called after calling loadConfig() and initialize().

Parameters

depth_img	The output retrieved depth image (only if there_is_obs=true).
timestamp	The timestamp of the capture (only if there_is_obs=true).
there_is_obs	If set to false, there was no new observation.
hardware_error	True on hardware/comms error.
sensor_id	The index of the sensor accessed.

Definition at line 460 of file COpenNI2Generic.cpp.

References mrpt::mrpt::format(), getNumDevices(), MRPT_UNUSED_PARAM, showLog(), THROW_EXCEPTION, and vDevices.

Here is the call graph for this function:

◆ getNextFrameRGB()

void COpenNI2Generic::getNextFrameRGB	(	mrpt::utils::CImage &	rgb_img,
		uint64_t &	timestamp,
		bool &	there_is_obs,
		bool &	hardware_error,
		unsigned	sensor_id = `0`
	)

The main data retrieving function, to be called after calling loadConfig() and initialize().

Parameters

out_img	The output retrieved RGB image (only if there_is_obs=true).
timestamp	The timestamp of the capture (only if there_is_obs=true).
there_is_obs	If set to false, there was no new observation.
hardware_error	True on hardware/comms error.
sensor_id	The index of the sensor accessed.
out_obs	The output retrieved observation (only if there_is_obs=true).
timestamp	The timestamp of the capture (only if there_is_obs=true).
there_is_obs	If set to false, there was no new observation.
hardware_error	True on hardware/comms error.
sensor_id	The index of the sensor accessed.

Definition at line 418 of file COpenNI2Generic.cpp.

References mrpt::mrpt::format(), getNumDevices(), MRPT_UNUSED_PARAM, showLog(), THROW_EXCEPTION, and vDevices.

Here is the call graph for this function:

◆ getNextFrameRGBD()

void COpenNI2Generic::getNextFrameRGBD	(	mrpt::obs::CObservation3DRangeScan &	out_obs,
		bool &	there_is_obs,
		bool &	hardware_error,
		unsigned	sensor_id = `0`
	)

The main data retrieving function, to be called after calling loadConfig() and initialize().

Parameters

out_obs	The output retrieved observation (only if there_is_obs=true).
there_is_obs	If set to false, there was no new observation.
hardware_error	True on hardware/comms error.
sensor_id	The index of the sensor accessed.

See also: doProcess

Parameters

out_obs	The output retrieved observation (only if there_is_obs=true).
there_is_obs	If set to false, there was no new observation.
hardware_error	True on hardware/comms error.
sensor_id	The index of the sensor accessed.

Definition at line 500 of file COpenNI2Generic.cpp.

References mrpt::mrpt::format(), getNumDevices(), MRPT_UNUSED_PARAM, showLog(), THROW_EXCEPTION, and vDevices.

Here is the call graph for this function:

◆ getNumDevices()

int COpenNI2Generic::getNumDevices ( ) const

The number of available devices at initialization.

Definition at line 148 of file COpenNI2Generic.cpp.

References vDevices.

Referenced by close(), getConnectedDevices(), getNextFrameD(), getNextFrameRGB(), getNextFrameRGBD(), isOpen(), and open().

Here is the caller graph for this function:

◆ isOpen()

bool COpenNI2Generic::isOpen ( const unsigned sensor_id ) const

Whether there is a working connection to the sensor.

Definition at line 243 of file COpenNI2Generic.cpp.

References getNumDevices(), MRPT_UNUSED_PARAM, THROW_EXCEPTION, and vDevices.

Referenced by getColorSensorParam(), getDepthSensorParam(), open(), and openDevicesBySerialNum().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ isVerbose()

bool COpenNI2Generic::isVerbose ( ) const

Definition at line 150 of file COpenNI2Generic.cpp.

References m_verbose.

Referenced by showLog().

Here is the caller graph for this function:

◆ kill()

void COpenNI2Generic::kill ( )

Kill the OpenNI2 driver.

See also: start()

Definition at line 233 of file COpenNI2Generic.cpp.

References THROW_EXCEPTION, and vDevices.

Referenced by ~COpenNI2Generic().

Here is the caller graph for this function:

◆ open()

void COpenNI2Generic::open ( unsigned sensor_id = 0 )

Try to open the camera (all the parameters [resolution,fps,...] must be set before calling this) - users may also call initialize(), which in turn calls this method.

Raises an exception upon error.

Exceptions

std::exception A textual description of the error.

Definition at line 257 of file COpenNI2Generic.cpp.

References mrpt::mrpt::format(), getNumDevices(), isOpen(), m_fps, m_height, m_verbose, m_width, MRPT_UNUSED_PARAM, showLog(), THROW_EXCEPTION, and vDevices.

Referenced by openDevicesBySerialNum().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ openDeviceBySerial()

unsigned int COpenNI2Generic::openDeviceBySerial ( const unsigned int SerialRequired )

Open a RGBD device specified by its serial number.

This method is a wrapper for openDevicesBySerialNum(const std::set<unsigned>& vSerialRequired) This method requires to open the sensors which are still closed to read their serial.

Definition at line 356 of file COpenNI2Generic.cpp.

References openDevicesBySerialNum().

Here is the call graph for this function:

◆ openDevicesBySerialNum()

unsigned int COpenNI2Generic::openDevicesBySerialNum ( const std::set< unsigned > & vSerialRequired )

Open a set of RGBD devices specified by their serial number.

Raises an exception when the demanded serial numbers are not among the connected devices. This function also fills a vector with the serial numbers of the connected OpenNI2 sensors (this requires openning the sensors which are still closed to read their serial)

Definition at line 301 of file COpenNI2Generic.cpp.

References mrpt::mrpt::format(), isOpen(), m_fps, m_height, m_verbose, m_width, MRPT_UNUSED_PARAM, open(), showLog(), THROW_EXCEPTION, and vDevices.

Referenced by openDeviceBySerial().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ setVerbose()

void COpenNI2Generic::setVerbose ( bool verbose )

Definition at line 149 of file COpenNI2Generic.cpp.

References m_verbose.

◆ showLog()

void COpenNI2Generic::showLog ( const std::string & message ) const

protected

Definition at line 151 of file COpenNI2Generic.cpp.

References isVerbose().

Referenced by getConnectedDevices(), getNextFrameD(), getNextFrameRGB(), getNextFrameRGBD(), open(), and openDevicesBySerialNum().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ start()

bool COpenNI2Generic::start ( )

Open all sensor streams (normally called automatically at constructor, no need to call it manually).

Returns: false on error

See also: kill() to close

Definition at line 114 of file COpenNI2Generic.cpp.

References numInstances, and THROW_EXCEPTION.

Referenced by COpenNI2Generic().

Here is the caller graph for this function:

Member Data Documentation

◆ m_depth_format

int mrpt::hwdrivers::COpenNI2Generic::m_depth_format

protected

Definition at line 157 of file COpenNI2Generic.h.

Referenced by getConnectedDevices().

◆ m_fps

float mrpt::hwdrivers::COpenNI2Generic::m_fps

protected

Definition at line 156 of file COpenNI2Generic.h.

Referenced by open(), and openDevicesBySerialNum().

◆ m_grab_3D_points

bool mrpt::hwdrivers::COpenNI2Generic::m_grab_3D_points

protected

Definition at line 163 of file COpenNI2Generic.h.

Referenced by mrpt::hwdrivers::COpenNI2Sensor::enableGrab3DPoints(), and mrpt::hwdrivers::COpenNI2Sensor::isGrab3DPointsEnabled().

◆ m_grab_depth

bool mrpt::hwdrivers::COpenNI2Generic::m_grab_depth

protected

Definition at line 163 of file COpenNI2Generic.h.

Referenced by mrpt::hwdrivers::COpenNI2Sensor::enableGrabDepth(), and mrpt::hwdrivers::COpenNI2Sensor::isGrabDepthEnabled().

◆ m_grab_image

bool mrpt::hwdrivers::COpenNI2Generic::m_grab_image

protected

The data that the RGBD sensors can return.

Default: all true

Definition at line 163 of file COpenNI2Generic.h.

Referenced by mrpt::hwdrivers::COpenNI2Sensor::enableGrabRGB(), and mrpt::hwdrivers::COpenNI2Sensor::isGrabRGBEnabled().

◆ m_height

int mrpt::hwdrivers::COpenNI2Generic::m_height

protected

Definition at line 155 of file COpenNI2Generic.h.

Referenced by open(), and openDevicesBySerialNum().

◆ m_rgb_format

int mrpt::hwdrivers::COpenNI2Generic::m_rgb_format

protected

Definition at line 157 of file COpenNI2Generic.h.

Referenced by getConnectedDevices().

◆ m_verbose

bool mrpt::hwdrivers::COpenNI2Generic::m_verbose

protected

Definition at line 158 of file COpenNI2Generic.h.

Referenced by COpenNI2Generic(), getConnectedDevices(), isVerbose(), open(), openDevicesBySerialNum(), and setVerbose().

◆ m_width

int mrpt::hwdrivers::COpenNI2Generic::m_width

protected

The same options (width, height and fps) are set for all the sensors.

(This could be changed if necessary)

Definition at line 155 of file COpenNI2Generic.h.

Referenced by open(), and openDevicesBySerialNum().

◆ numInstances

int COpenNI2Generic::numInstances = 0

staticprotected

Definition at line 148 of file COpenNI2Generic.h.

Referenced by start(), and ~COpenNI2Generic().

◆ vDevices

std::vector< std::shared_ptr< COpenNI2Generic::CDevice > > COpenNI2Generic::vDevices

staticprotected

Initial value:

=

std::vector<std::shared_ptr<COpenNI2Generic::CDevice>>()

Definition at line 146 of file COpenNI2Generic.h.

Referenced by close(), getColorSensorParam(), getConnectedDevices(), getDepthSensorParam(), getDeviceIDFromSerialNum(), getNextFrameD(), getNextFrameRGB(), getNextFrameRGBD(), getNumDevices(), isOpen(), kill(), open(), and openDevicesBySerialNum().

◆ vSerialNums

std::vector<int> mrpt::hwdrivers::COpenNI2Generic::vSerialNums

protected

A vector with the serial numbers of the available devices.

Definition at line 151 of file COpenNI2Generic.h.

Detailed Description

Classes

Public Member Functions

Protected Member Functions

Protected Attributes

Static Protected Attributes

Constructor & Destructor Documentation

◆ COpenNI2Generic() [1/2]

◆ COpenNI2Generic() [2/2]

◆ ~COpenNI2Generic()

Member Function Documentation

◆ close()

◆ getColorSensorParam()

◆ getConnectedDevices()

◆ getDepthSensorParam()

◆ getDeviceIDFromSerialNum()

◆ getNextFrameD()

◆ getNextFrameRGB()

◆ getNextFrameRGBD()

◆ getNumDevices()

◆ isOpen()

◆ isVerbose()

◆ kill()

◆ open()

◆ openDeviceBySerial()

◆ openDevicesBySerialNum()

◆ setVerbose()

◆ showLog()

◆ start()

Member Data Documentation

◆ m_depth_format

◆ m_fps

◆ m_grab_3D_points

◆ m_grab_depth

◆ m_grab_image

◆ m_height

◆ m_rgb_format

◆ m_verbose

◆ m_width

◆ numInstances

◆ vDevices

◆ vSerialNums
