Detailed Description

Classes for creating GUI windows for 2D and 3D visualization.

mrpt_gui_grp

Namespaces
	detail
	Auxiliary structures used internally to mrpt.

Classes
class	CBaseGUIWindow
	The base class for GUI window classes. More...

class	mrptEventWindowChar
	An event sent by a window upon a char pressed by the user. More...

class	mrptEventWindowResize
	An event sent by a window upon resize. More...

class	mrptEventMouseDown
	An event sent by a window upon a mouse click, giving the (x,y) pixel coordinates. More...

class	mrptEventMouseMove
	An event sent by a window when the mouse is moved over it. More...

class	mrptEventWindowClosed
	An event sent by a window upon when it's about to be closed, either manually by the user or programmatically. More...

class	CDisplayWindow
	This class creates a window as a graphical user interface (GUI) for displaying images to the user. More...

class	CDisplayWindow3D
	A graphical user interface (GUI) for efficiently rendering 3D scenes in real-time. More...

class	mrptEvent3DWindowGrabImageFile
	An event sent by a CDisplayWindow3D window when an image is saved after enabling this feature with CDisplayWindow3D::grabImagesStart() More...

class	CDisplayWindow3DLocker
	Auxiliary class for safely claiming the 3DScene of a mrpt::gui::CDisplayWindow3D. More...

class	CDisplayWindowPlots
	Create a GUI window and display plots with MATLAB-like interfaces and commands. More...

class	CGlCanvasBase
	This base class implements a working with opengl::Camera and a OpenGL canvas, and it's used in gui::CWxGLCanvasBase and gui::CQtGlCanvasBase. More...

class	WxSubsystem
	This class implements the GUI thread required for the wxWidgets-based GUI. More...

class	CWindowDialog
	The wx dialog for gui::CDisplayWindow. More...

class	C3DWindowDialog

class	CWindowDialogPlots
	The wx dialog for gui::CDisplayWindowPlots. More...

class	wxMRPTImageControl
	A custom control to display the bitmap and avoid flicker. More...

class	CPanelCameraSelection
	A panel to select the camera input from all the formats supported by MRPT. More...

Enumerations
enum	mrptKeyCode { MRPTK_BACK = 8 , MRPTK_TAB = 9 , MRPTK_RETURN = 13 , MRPTK_ESCAPE = 27 , MRPTK_SPACE = 32 , MRPTK_DELETE = 127 , MRPTK_START = 300 , MRPTK_LBUTTON , MRPTK_RBUTTON , MRPTK_CANCEL , MRPTK_MBUTTON , MRPTK_CLEAR , MRPTK_SHIFT , MRPTK_ALT , MRPTK_CONTROL , MRPTK_MENU , MRPTK_PAUSE , MRPTK_CAPITAL , MRPTK_END , MRPTK_HOME , MRPTK_LEFT , MRPTK_UP , MRPTK_RIGHT , MRPTK_DOWN , MRPTK_SELECT , MRPTK_PRINT , MRPTK_EXECUTE , MRPTK_SNAPSHOT , MRPTK_INSERT , MRPTK_HELP , MRPTK_NUMPAD0 , MRPTK_NUMPAD1 , MRPTK_NUMPAD2 , MRPTK_NUMPAD3 , MRPTK_NUMPAD4 , MRPTK_NUMPAD5 , MRPTK_NUMPAD6 , MRPTK_NUMPAD7 , MRPTK_NUMPAD8 , MRPTK_NUMPAD9 , MRPTK_MULTIPLY , MRPTK_ADD , MRPTK_SEPARATOR , MRPTK_SUBTRACT , MRPTK_DECIMAL , MRPTK_DIVIDE , MRPTK_F1 , MRPTK_F2 , MRPTK_F3 , MRPTK_F4 , MRPTK_F5 , MRPTK_F6 , MRPTK_F7 , MRPTK_F8 , MRPTK_F9 , MRPTK_F10 , MRPTK_F11 , MRPTK_F12 , MRPTK_F13 , MRPTK_F14 , MRPTK_F15 , MRPTK_F16 , MRPTK_F17 , MRPTK_F18 , MRPTK_F19 , MRPTK_F20 , MRPTK_F21 , MRPTK_F22 , MRPTK_F23 , MRPTK_F24 , MRPTK_NUMLOCK , MRPTK_SCROLL , MRPTK_PAGEUP , MRPTK_PAGEDOWN , MRPTK_NUMPAD_SPACE , MRPTK_NUMPAD_TAB , MRPTK_NUMPAD_ENTER , MRPTK_NUMPAD_F1 , MRPTK_NUMPAD_F2 , MRPTK_NUMPAD_F3 , MRPTK_NUMPAD_F4 , MRPTK_NUMPAD_HOME , MRPTK_NUMPAD_LEFT , MRPTK_NUMPAD_UP , MRPTK_NUMPAD_RIGHT , MRPTK_NUMPAD_DOWN , MRPTK_NUMPAD_PAGEUP , MRPTK_NUMPAD_PAGEDOWN , MRPTK_NUMPAD_END , MRPTK_NUMPAD_BEGIN , MRPTK_NUMPAD_INSERT , MRPTK_NUMPAD_DELETE , MRPTK_NUMPAD_EQUAL , MRPTK_NUMPAD_MULTIPLY , MRPTK_NUMPAD_ADD , MRPTK_NUMPAD_SEPARATOR , MRPTK_NUMPAD_SUBTRACT , MRPTK_NUMPAD_DECIMAL , MRPTK_NUMPAD_DIVIDE , MRPTK_WINDOWS_LEFT , MRPTK_WINDOWS_RIGHT , MRPTK_WINDOWS_MENU , MRPTK_COMMAND , MRPTK_SPECIAL1 = 193 , MRPTK_SPECIAL2 , MRPTK_SPECIAL3 , MRPTK_SPECIAL4 , MRPTK_SPECIAL5 , MRPTK_SPECIAL6 , MRPTK_SPECIAL7 , MRPTK_SPECIAL8 , MRPTK_SPECIAL9 , MRPTK_SPECIAL10 , MRPTK_SPECIAL11 , MRPTK_SPECIAL12 , MRPTK_SPECIAL13 , MRPTK_SPECIAL14 , MRPTK_SPECIAL15 , MRPTK_SPECIAL16 , MRPTK_SPECIAL17 , MRPTK_SPECIAL18 , MRPTK_SPECIAL19 , MRPTK_SPECIAL20 }

enum	mrptKeyModifier { MRPTKMOD_NONE = 0x0000 , MRPTKMOD_ALT = 0x1000 , MRPTKMOD_CONTROL = 0x2000 , MRPTKMOD_ALTGR = MRPTKMOD_ALT \| MRPTKMOD_CONTROL , MRPTKMOD_SHIFT = 0x4000 , MRPTKMOD_META = 0x8000 , MRPTKMOD_WIN = MRPTKMOD_META , MRPTKMOD_CMD = MRPTKMOD_CONTROL }

Functions
void	show_mrpt_about_box_wxWidgets (void *parent_wx_window, const std::string &appName, const std::string &additionalInfo=std::string(), const bool showStandardInfo=true)
	Shows the standard MRPT GUI "About Box" (wxWidgets version) More...

void	show_mrpt_about_box_Qt (const std::string &appName, const std::string &additionalInfo=std::string(), const bool showStandardInfo=true)

void	tryCatch (const std::function< void()> &tryPart, const std::string &catchMessage)

void	showErrorMessage (const std::string &str)

wxImage *	MRPTImage2wxImage (const mrpt::utils::CImage &img)
	Create a wxImage from a MRPT image. More...

wxBitmap *	MRPTImage2wxBitmap (const mrpt::utils::CImage &img)
	Create a wxBitmap from a MRPT image. More...

wxImage *	IplImage2wxImage (void *img)
	Create a wxImage from a IPL image. More...

mrpt::utils::CImage *	wxImage2MRPTImage (const wxImage &img)
	Create a MRPT image from a wxImage. More...

mrpt::utils::CImage::Ptr	wxImage2MRPTImagePtr (const wxImage &img)
	Create a MRPT image from a wxImage. More...

mrptKeyModifier	keyEventToMrptKeyModifier (const wxKeyEvent &ev)
	Extracts the key modifiers from a wxKeyEvent. More...

Enumeration Type Documentation

◆ mrptKeyCode

enum mrpt::gui::mrptKeyCode

Enumerator
MRPTK_BACK
MRPTK_TAB
MRPTK_RETURN
MRPTK_ESCAPE
MRPTK_SPACE
MRPTK_DELETE
MRPTK_START
MRPTK_LBUTTON
MRPTK_RBUTTON
MRPTK_CANCEL
MRPTK_MBUTTON
MRPTK_CLEAR
MRPTK_SHIFT
MRPTK_ALT
MRPTK_CONTROL
MRPTK_MENU
MRPTK_PAUSE
MRPTK_CAPITAL
MRPTK_END
MRPTK_HOME
MRPTK_LEFT
MRPTK_UP
MRPTK_RIGHT
MRPTK_DOWN
MRPTK_SELECT
MRPTK_PRINT
MRPTK_EXECUTE
MRPTK_SNAPSHOT
MRPTK_INSERT
MRPTK_HELP
MRPTK_NUMPAD0
MRPTK_NUMPAD1
MRPTK_NUMPAD2
MRPTK_NUMPAD3
MRPTK_NUMPAD4
MRPTK_NUMPAD5
MRPTK_NUMPAD6
MRPTK_NUMPAD7
MRPTK_NUMPAD8
MRPTK_NUMPAD9
MRPTK_MULTIPLY
MRPTK_ADD
MRPTK_SEPARATOR
MRPTK_SUBTRACT
MRPTK_DECIMAL
MRPTK_DIVIDE
MRPTK_F1
MRPTK_F2
MRPTK_F3
MRPTK_F4
MRPTK_F5
MRPTK_F6
MRPTK_F7
MRPTK_F8
MRPTK_F9
MRPTK_F10
MRPTK_F11
MRPTK_F12
MRPTK_F13
MRPTK_F14
MRPTK_F15
MRPTK_F16
MRPTK_F17
MRPTK_F18
MRPTK_F19
MRPTK_F20
MRPTK_F21
MRPTK_F22
MRPTK_F23
MRPTK_F24
MRPTK_NUMLOCK
MRPTK_SCROLL
MRPTK_PAGEUP
MRPTK_PAGEDOWN
MRPTK_NUMPAD_SPACE
MRPTK_NUMPAD_TAB
MRPTK_NUMPAD_ENTER
MRPTK_NUMPAD_F1
MRPTK_NUMPAD_F2
MRPTK_NUMPAD_F3
MRPTK_NUMPAD_F4
MRPTK_NUMPAD_HOME
MRPTK_NUMPAD_LEFT
MRPTK_NUMPAD_UP
MRPTK_NUMPAD_RIGHT
MRPTK_NUMPAD_DOWN
MRPTK_NUMPAD_PAGEUP
MRPTK_NUMPAD_PAGEDOWN
MRPTK_NUMPAD_END
MRPTK_NUMPAD_BEGIN
MRPTK_NUMPAD_INSERT
MRPTK_NUMPAD_DELETE
MRPTK_NUMPAD_EQUAL
MRPTK_NUMPAD_MULTIPLY
MRPTK_NUMPAD_ADD
MRPTK_NUMPAD_SEPARATOR
MRPTK_NUMPAD_SUBTRACT
MRPTK_NUMPAD_DECIMAL
MRPTK_NUMPAD_DIVIDE
MRPTK_WINDOWS_LEFT
MRPTK_WINDOWS_RIGHT
MRPTK_WINDOWS_MENU
MRPTK_COMMAND
MRPTK_SPECIAL1
MRPTK_SPECIAL2
MRPTK_SPECIAL3
MRPTK_SPECIAL4
MRPTK_SPECIAL5
MRPTK_SPECIAL6
MRPTK_SPECIAL7
MRPTK_SPECIAL8
MRPTK_SPECIAL9
MRPTK_SPECIAL10
MRPTK_SPECIAL11
MRPTK_SPECIAL12
MRPTK_SPECIAL13
MRPTK_SPECIAL14
MRPTK_SPECIAL15
MRPTK_SPECIAL16
MRPTK_SPECIAL17
MRPTK_SPECIAL18
MRPTK_SPECIAL19
MRPTK_SPECIAL20

Definition at line 25 of file keycodes.h.

◆ mrptKeyModifier

enum mrpt::gui::mrptKeyModifier

Enumerator
MRPTKMOD_NONE
MRPTKMOD_ALT
MRPTKMOD_CONTROL
MRPTKMOD_ALTGR
MRPTKMOD_SHIFT
MRPTKMOD_META
MRPTKMOD_WIN
MRPTKMOD_CMD

Definition at line 159 of file keycodes.h.

Function Documentation

◆ IplImage2wxImage()

wxImage * mrpt::gui::IplImage2wxImage ( void * img )

Create a wxImage from a IPL image.

The new object must be freed by the user when not required anymore.

See also: IplImage2wxImage

Definition at line 237 of file WxUtils.cpp.

References ASSERT_, and mrpt::system::os::memcpy().

Here is the call graph for this function:

◆ keyEventToMrptKeyModifier()

mrptKeyModifier mrpt::gui::keyEventToMrptKeyModifier ( const wxKeyEvent & ev )

Extracts the key modifiers from a wxKeyEvent.

Definition at line 1135 of file WxUtils.cpp.

References MRPTKMOD_ALT, MRPTKMOD_CMD, MRPTKMOD_CONTROL, MRPTKMOD_META, MRPTKMOD_NONE, and MRPTKMOD_SHIFT.

Referenced by mrpt::gui::CWindowDialog::OnChar(), and mrpt::gui::CWindowDialogPlots::OnChar().

Here is the caller graph for this function:

◆ MRPTImage2wxBitmap()

wxBitmap * mrpt::gui::MRPTImage2wxBitmap ( const mrpt::utils::CImage & img )

Create a wxBitmap from a MRPT image.

The new object must be freed by the user when not required anymore.

See also: MRPTImage2wxImage

Definition at line 168 of file WxUtils.cpp.

References mrpt::system::os::memcpy(), and THROW_EXCEPTION.

Referenced by mrpt::gui::wxMRPTImageControl::AssignImage().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ MRPTImage2wxImage()

wxImage * mrpt::gui::MRPTImage2wxImage ( const mrpt::utils::CImage & img )

Create a wxImage from a MRPT image.

The new object must be freed by the user when not required anymore.

See also: MRPTImage2wxImage

Definition at line 29 of file WxUtils.cpp.

References mrpt::system::os::memcpy().

Referenced by mrpt::gui::CDisplayWindowPlots::image(), and mrpt::gui::CDisplayWindow::showImage().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ show_mrpt_about_box_Qt()

void mrpt::gui::show_mrpt_about_box_Qt	(	const std::string &	appName,
		const std::string &	additionalInfo = `std::string()`,
		const bool	showStandardInfo = `true`
	)

Definition at line 18 of file about_box_qt.cpp.

References THROW_EXCEPTION.

◆ show_mrpt_about_box_wxWidgets()

void mrpt::gui::show_mrpt_about_box_wxWidgets	(	void *	parent_wx_window,
		const std::string &	appName,
		const std::string &	additionalInfo = `std::string()`,
		const bool	showStandardInfo = `true`
	)

Shows the standard MRPT GUI "About Box" (wxWidgets version)

Definition at line 18 of file about_box_wx.cpp.

References THROW_EXCEPTION.

◆ showErrorMessage()

void mrpt::gui::showErrorMessage ( const std::string & str )

Definition at line 38 of file error_box.cpp.

References _U.

Referenced by tryCatch().

Here is the caller graph for this function:

◆ tryCatch()

void mrpt::gui::tryCatch	(	const std::function< void()> &	tryPart,
		const std::string &	catchMessage
	)

Definition at line 21 of file error_box.cpp.

References showErrorMessage().

Here is the call graph for this function:

◆ wxImage2MRPTImage()

mrpt::utils::CImage * mrpt::gui::wxImage2MRPTImage ( const wxImage & img )

Create a MRPT image from a wxImage.

The new object must be freed by the user when not required anymore. It is recommended to use wxImage2MRPTImagePtr instead since smart pointers are safer to manage.
