mrpt::opengl::T2DTextData Struct Reference

Detailed Description

An auxiliary struct for holding a list of text messages in some mrpt::opengl & mrpt::gui classes The font can be either a bitmapped or a vectorized font.

See also
mrpt::opengl::CTextMessageCapable

Definition at line 94 of file opengl_fonts.h.

#include <mrpt/opengl/opengl_fonts.h>

Inheritance diagram for mrpt::opengl::T2DTextData:
Inheritance graph

Public Member Functions

 T2DTextData ()


Public Attributes

std::string text

double x

double y

mrpt::img::TColorf color

bool draw_shadow

mrpt::img::TColorf shadow_color

Bitmapped font params
mrpt::opengl::TOpenGLFont font

Vectorized font params - Applicable only if

font==MRPT_GLUT_BITMAP_NONE

std::string vfont_name
 Vectorized font name ("sans","mono","serif") More...

double vfont_scale
 Size of characters. More...

TOpenGLFontStyle vfont_style
 (default: NICE) See TOpenGLFontStyle. More...

double vfont_spacing
 (default: 1.5) Refer to mrpt::opengl::gl_utils::glDrawText More...

double vfont_kerning
 (default: 0.1) Refer to mrpt::opengl::gl_utils::glDrawText More...


Constructor & Destructor Documentation

◆ T2DTextData()

mrpt::opengl::T2DTextData::T2DTextData ( )
inline

Definition at line 96 of file opengl_fonts.h.

Member Data Documentation

◆ color

mrpt::img::TColorf mrpt::opengl::TFontParams::color
inherited

Definition at line 62 of file opengl_fonts.h.

Referenced by mrpt::opengl::CTextMessageCapable::addTextMessage().

◆ draw_shadow

bool mrpt::opengl::TFontParams::draw_shadow
inherited

Definition at line 64 of file opengl_fonts.h.

Referenced by mrpt::opengl::CTextMessageCapable::addTextMessage().

◆ font

mrpt::opengl::TOpenGLFont mrpt::opengl::TFontParams::font
inherited

Definition at line 69 of file opengl_fonts.h.

Referenced by mrpt::opengl::CTextMessageCapable::addTextMessage().

◆ shadow_color

mrpt::img::TColorf mrpt::opengl::TFontParams::shadow_color
inherited

Definition at line 65 of file opengl_fonts.h.

Referenced by mrpt::opengl::CTextMessageCapable::addTextMessage().

◆ text

std::string mrpt::opengl::T2DTextData::text

Definition at line 97 of file opengl_fonts.h.

Referenced by mrpt::opengl::CTextMessageCapable::addTextMessage().

◆ vfont_kerning

double mrpt::opengl::TFontParams::vfont_kerning
inherited

(default: 0.1) Refer to mrpt::opengl::gl_utils::glDrawText

Definition at line 84 of file opengl_fonts.h.

Referenced by mrpt::opengl::CTextMessageCapable::addTextMessage().

◆ vfont_name

std::string mrpt::opengl::TFontParams::vfont_name
inherited

Vectorized font name ("sans","mono","serif")

Definition at line 76 of file opengl_fonts.h.

Referenced by mrpt::opengl::CTextMessageCapable::addTextMessage().

◆ vfont_scale

double mrpt::opengl::TFontParams::vfont_scale
inherited

Size of characters.

Definition at line 78 of file opengl_fonts.h.

Referenced by mrpt::opengl::CTextMessageCapable::addTextMessage().

◆ vfont_spacing

double mrpt::opengl::TFontParams::vfont_spacing
inherited

(default: 1.5) Refer to mrpt::opengl::gl_utils::glDrawText

Definition at line 82 of file opengl_fonts.h.

Referenced by mrpt::opengl::CTextMessageCapable::addTextMessage().

◆ vfont_style

TOpenGLFontStyle mrpt::opengl::TFontParams::vfont_style
inherited

(default: NICE) See TOpenGLFontStyle.

Definition at line 80 of file opengl_fonts.h.

Referenced by mrpt::opengl::CTextMessageCapable::addTextMessage().

◆ x

double mrpt::opengl::T2DTextData::x

Definition at line 98 of file opengl_fonts.h.

Referenced by mrpt::opengl::CTextMessageCapable::addTextMessage().

◆ y

double mrpt::opengl::T2DTextData::y

Definition at line 98 of file opengl_fonts.h.

Referenced by mrpt::opengl::CTextMessageCapable::addTextMessage().
