mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS > Class Template Reference

Detailed Description

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
class mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >

A directed graph with the argument of the template specifying the type of the annotations in the edges.

This class only keeps a list of edges (in the member edges), so there is no information stored for each node but its existence referred by a node_ID.

Note that edges are stored as a std::multimap<> to allow multiple edges between the same pair of nodes.

See also
mrpt::graphs::CDijkstra, mrpt::graphs::CNetworkOfPoses, mrpt::graphs::CDirectedTree

Definition at line 70 of file CDirectedGraph.h.

#include <mrpt/graphs/CDirectedGraph.h>

Inheritance diagram for mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >:
Inheritance graph

Classes

struct  edge_t
 The type of each global pose in nodes: an extension of the TYPE_EDGES pose with any optional user-defined data. More...


Public Types

typedef mrpt::aligned_containers< TPairNodeIDs, edge_t >::multimap_t edges_map_t
 The type of the member edges. More...

typedef edges_map_t::iterator iterator

typedef edges_map_t::reverse_iterator reverse_iterator

typedef edges_map_t::const_iterator const_iterator

typedef edges_map_t::const_reverse_iterator const_reverse_iterator

typedef CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS > self_t
 Handy self type. More...


Public Member Functions

 CDirectedGraph (const edges_map_t &obj)
 Copy constructor from a multimap<pair< >, > More...

 CDirectedGraph ()
 Default constructor. More...

iterator begin ()

iterator rbegin ()

iterator end ()

iterator rend ()

const_iterator begin () const

const_iterator rbegin () const

const_iterator end () const

const_iterator rend () const

Edges/nodes utility methods
size_t edgeCount () const
 The number of edges in the graph. More...

void clearEdges ()
 Erase all edges. More...

void insertEdge (TNodeID from_nodeID, TNodeID to_nodeID, const edge_t &edge_value)
 Insert an edge (from -> to) with the given edge value. More...

void insertEdgeAtEnd (TNodeID from_nodeID, TNodeID to_nodeID, const edge_t &edge_value)
 Insert an edge (from -> to) with the given edge value (more efficient version to be called if you know that the end will go at the end of the sorted std::multimap). More...

bool edgeExists (TNodeID from_nodeID, TNodeID to_nodeID) const
 Test if the given directed edge exists. More...

edge_tgetEdge (TNodeID from_nodeID, TNodeID to_nodeID)
 Return a reference to the content of a given edge. More...

const edge_tgetEdge (TNodeID from_nodeID, TNodeID to_nodeID) const
 Return a reference to the content of a given edge. More...

std::pair< iterator, iteratorgetEdges (TNodeID from_nodeID, TNodeID to_nodeID)
 Return a pair<first,last> of iterators to the range of edges between two given nodes. More...

std::pair< const_iterator, const_iteratorgetEdges (TNodeID from_nodeID, TNodeID to_nodeID) const
 Return a pair<first,last> of const iterators to the range of edges between two given nodes. More...

void eraseEdge (TNodeID from_nodeID, TNodeID to_nodeID)
 Erase all edges between the given nodes (it has no effect if no edge existed) More...

void getAllNodes (std::set< TNodeID > &lstNode_IDs) const
 Return a list of all the node_ID's of the graph, generated from all the nodes that appear in the list of edges. More...

std::set< TNodeID > getAllNodes () const
 Less efficient way to get all nodes that returns a copy of the set object. More...

size_t countDifferentNodesInEdges () const
 Count how many different node IDs appear in the graph edges. More...

void getNeighborsOf (const TNodeID nodeID, std::set< TNodeID > &neighborIDs) const
 Return the list of all neighbors of "nodeID", by creating a list of their node IDs. More...

std::set< TNodeID > getNeighborsOf (const TNodeID nodeID) const
 Return the list of all neighbors of "nodeID", by creating a list of their node IDs. More...

template<class MAP_NODEID_SET_NODEIDS >
void getAdjacencyMatrix (MAP_NODEID_SET_NODEIDS &outAdjacency) const
 Return a map from node IDs to all its neighbors (that is, connected nodes, regardless of the edge direction) This is a much more efficient method than calling getNeighborsOf() for each node in the graph. More...

template<class MAP_NODEID_SET_NODEIDS , class SET_NODEIDS >
void getAdjacencyMatrix (MAP_NODEID_SET_NODEIDS &outAdjacency, const SET_NODEIDS &onlyForTheseNodes) const
 Just like getAdjacencyMatrix but return only the adjacency for those node_ids in the set onlyForTheseNodes (both endings nodes of an edge must be within the set for it to be returned) More...

I/O utilities
bool saveAsDot (std::ostream &o, const TGraphvizExportParams &p=TGraphvizExportParams()) const
 Save the graph in a Graphviz (.dot files) text format; useful for quickly rendering the graph with "dot". More...

bool saveAsDot (const std::string &fileName, const TGraphvizExportParams &p=TGraphvizExportParams()) const


Public Attributes

edges_map_t edges
 The public member with the directed edges in the graph. More...


Member Typedef Documentation

◆ const_iterator

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
typedef edges_map_t::const_iterator mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::const_iterator

Definition at line 94 of file CDirectedGraph.h.

◆ const_reverse_iterator

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
typedef edges_map_t::const_reverse_iterator mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::const_reverse_iterator

Definition at line 95 of file CDirectedGraph.h.

◆ edges_map_t

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
typedef mrpt::aligned_containers<TPairNodeIDs, edge_t>::multimap_t mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::edges_map_t

The type of the member edges.

Definition at line 91 of file CDirectedGraph.h.

◆ iterator

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
typedef edges_map_t::iterator mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::iterator

Definition at line 92 of file CDirectedGraph.h.

◆ reverse_iterator

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
typedef edges_map_t::reverse_iterator mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::reverse_iterator

Definition at line 93 of file CDirectedGraph.h.

◆ self_t

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
typedef CDirectedGraph<TYPE_EDGES, EDGE_ANNOTATIONS> mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::self_t

Handy self type.

Definition at line 97 of file CDirectedGraph.h.

Constructor & Destructor Documentation

◆ CDirectedGraph() [1/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::CDirectedGraph ( const edges_map_t obj)
inline

Copy constructor from a multimap<pair< >, >

Definition at line 103 of file CDirectedGraph.h.

◆ CDirectedGraph() [2/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::CDirectedGraph ( )
inline

Default constructor.

Definition at line 105 of file CDirectedGraph.h.

Member Function Documentation

◆ begin() [1/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
iterator mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::begin ( )
inline

◆ begin() [2/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
const_iterator mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::begin ( ) const
inline

Definition at line 110 of file CDirectedGraph.h.

◆ clearEdges()

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
void mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::clearEdges ( )
inline

Erase all edges.

Definition at line 120 of file CDirectedGraph.h.

Referenced by mrpt::graphs::CNetworkOfPoses< CPOSE, MAPS_IMPLEMENTATION, NODE_ANNOTATIONS, EDGE_ANNOTATIONS >::extractSubGraph().

Here is the caller graph for this function:

◆ countDifferentNodesInEdges()

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
size_t mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::countDifferentNodesInEdges ( ) const
inline

Count how many different node IDs appear in the graph edges.

Definition at line 233 of file CDirectedGraph.h.

◆ edgeCount()

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
size_t mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::edgeCount ( ) const
inline

The number of edges in the graph.

Definition at line 118 of file CDirectedGraph.h.

◆ edgeExists()

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
bool mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::edgeExists ( TNodeID  from_nodeID,
TNodeID  to_nodeID
) const
inline

Test if the given directed edge exists.

Definition at line 143 of file CDirectedGraph.h.

◆ end() [1/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
iterator mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::end ( )
inline

◆ end() [2/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
const_iterator mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::end ( ) const
inline

Definition at line 112 of file CDirectedGraph.h.

◆ eraseEdge()

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
void mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::eraseEdge ( TNodeID  from_nodeID,
TNodeID  to_nodeID
)
inline

Erase all edges between the given nodes (it has no effect if no edge existed)

Definition at line 203 of file CDirectedGraph.h.

◆ getAdjacencyMatrix() [1/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
template<class MAP_NODEID_SET_NODEIDS >
void mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::getAdjacencyMatrix ( MAP_NODEID_SET_NODEIDS &  outAdjacency) const
inline

Return a map from node IDs to all its neighbors (that is, connected nodes, regardless of the edge direction) This is a much more efficient method than calling getNeighborsOf() for each node in the graph.

Possible values for the template argument MAP_NODEID_SET_NODEIDS are:

Definition at line 279 of file CDirectedGraph.h.

◆ getAdjacencyMatrix() [2/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
template<class MAP_NODEID_SET_NODEIDS , class SET_NODEIDS >
void mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::getAdjacencyMatrix ( MAP_NODEID_SET_NODEIDS &  outAdjacency,
const SET_NODEIDS &  onlyForTheseNodes
) const
inline

Just like getAdjacencyMatrix but return only the adjacency for those node_ids in the set onlyForTheseNodes (both endings nodes of an edge must be within the set for it to be returned)

Definition at line 295 of file CDirectedGraph.h.

◆ getAllNodes() [1/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
void mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::getAllNodes ( std::set< TNodeID > &  lstNode_IDs) const
inline

Return a list of all the node_ID's of the graph, generated from all the nodes that appear in the list of edges.

Definition at line 211 of file CDirectedGraph.h.

◆ getAllNodes() [2/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
std::set<TNodeID> mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::getAllNodes ( ) const
inline

Less efficient way to get all nodes that returns a copy of the set object.

See also
getAllNodes( std::set<TNodeID> &lstNode_IDs)

Definition at line 224 of file CDirectedGraph.h.

Referenced by mrpt::graphs::CDirectedGraph< CPOSE, EDGE_ANNOTATIONS >::getAllNodes().

Here is the caller graph for this function:

◆ getEdge() [1/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
edge_t& mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::getEdge ( TNodeID  from_nodeID,
TNodeID  to_nodeID
)
inline

Return a reference to the content of a given edge.

If several edges exist between the given nodes, the first one is returned.

Exceptions
std::exceptionif the given edge does not exist
See also
getEdges

Definition at line 155 of file CDirectedGraph.h.

◆ getEdge() [2/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
const edge_t& mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::getEdge ( TNodeID  from_nodeID,
TNodeID  to_nodeID
) const
inline

Return a reference to the content of a given edge.

If several edges exist between the given nodes, the first one is returned.

Exceptions
std::exceptionif the given edge does not exist
See also
getEdges

Definition at line 173 of file CDirectedGraph.h.

◆ getEdges() [1/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
std::pair<iterator, iterator> mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::getEdges ( TNodeID  from_nodeID,
TNodeID  to_nodeID
)
inline

Return a pair<first,last> of iterators to the range of edges between two given nodes.

See also
getEdge

Definition at line 187 of file CDirectedGraph.h.

◆ getEdges() [2/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
std::pair<const_iterator, const_iterator> mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::getEdges ( TNodeID  from_nodeID,
TNodeID  to_nodeID
) const
inline

Return a pair<first,last> of const iterators to the range of edges between two given nodes.

See also
getEdge

Definition at line 194 of file CDirectedGraph.h.

◆ getNeighborsOf() [1/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
void mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::getNeighborsOf ( const TNodeID  nodeID,
std::set< TNodeID > &  neighborIDs
) const
inline

Return the list of all neighbors of "nodeID", by creating a list of their node IDs.

See also
getAdjacencyMatrix

Definition at line 247 of file CDirectedGraph.h.

Referenced by mrpt::graphs::CNetworkOfPoses< CPOSE, MAPS_IMPLEMENTATION, NODE_ANNOTATIONS, EDGE_ANNOTATIONS >::extractSubGraph(), and mrpt::graphs::CDirectedGraph< CPOSE, EDGE_ANNOTATIONS >::getNeighborsOf().

Here is the caller graph for this function:

◆ getNeighborsOf() [2/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
std::set<TNodeID> mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::getNeighborsOf ( const TNodeID  nodeID) const
inline

Return the list of all neighbors of "nodeID", by creating a list of their node IDs.

See also
getAdjacencyMatrix

Definition at line 262 of file CDirectedGraph.h.

◆ insertEdge()

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
void mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::insertEdge ( TNodeID  from_nodeID,
TNodeID  to_nodeID,
const edge_t edge_value
)
inline

◆ insertEdgeAtEnd()

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
void mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::insertEdgeAtEnd ( TNodeID  from_nodeID,
TNodeID  to_nodeID,
const edge_t edge_value
)
inline

Insert an edge (from -> to) with the given edge value (more efficient version to be called if you know that the end will go at the end of the sorted std::multimap).

See also
insertEdge

Definition at line 134 of file CDirectedGraph.h.

Referenced by mrpt::hmtslam::CHierarchicalMapMHPartition::computeGloballyConsistentNodeCoordinates().

Here is the caller graph for this function:

◆ rbegin() [1/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
iterator mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::rbegin ( )
inline

Definition at line 107 of file CDirectedGraph.h.

◆ rbegin() [2/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
const_iterator mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::rbegin ( ) const
inline

Definition at line 111 of file CDirectedGraph.h.

◆ rend() [1/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
iterator mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::rend ( )
inline

Definition at line 109 of file CDirectedGraph.h.

◆ rend() [2/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
const_iterator mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::rend ( ) const
inline

Definition at line 113 of file CDirectedGraph.h.

◆ saveAsDot() [1/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
bool mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::saveAsDot ( std::ostream &  o,
const TGraphvizExportParams p = TGraphvizExportParams()
) const
inline

Save the graph in a Graphviz (.dot files) text format; useful for quickly rendering the graph with "dot".

Returns
false on any error

Definition at line 321 of file CDirectedGraph.h.

Referenced by mrpt::graphs::CDirectedGraph< CPOSE, EDGE_ANNOTATIONS >::saveAsDot().

Here is the caller graph for this function:

◆ saveAsDot() [2/2]

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
bool mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::saveAsDot ( const std::string fileName,
const TGraphvizExportParams p = TGraphvizExportParams()
) const
inline

This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts.

Definition at line 365 of file CDirectedGraph.h.

Member Data Documentation

◆ edges

template<class TYPE_EDGES, class EDGE_ANNOTATIONS = detail::edge_annotations_empty>
edges_map_t mrpt::graphs::CDirectedGraph< TYPE_EDGES, EDGE_ANNOTATIONS >::edges



Page generated by Doxygen 1.8.14 for MRPT 1.9.9 Git: ae4571287 Thu Nov 23 00:06:53 2017 +0100 at dom oct 27 23:51:55 CET 2019
