TEnumType.h File Reference

#include <map>
#include <stdexcept>

Include dependency graph for TEnumType.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	mrpt::typemeta::internal::bimap< KEY, VALUE >
struct	mrpt::typemeta::TEnumTypeFiller< ENUMTYPE >
	Only specializations of this class are defined for each enum type of interest. More...
struct	mrpt::typemeta::TEnumType< ENUMTYPE >
	A helper class that can convert an enum value into its textual representation, and viceversa. More...

Namespaces
	mrpt
	This is the global namespace for all Mobile Robot Programming Toolkit (MRPT) libraries.
	mrpt::typemeta
	mrpt::typemeta::internal

Macros
#define	MRPT_ENUM_TYPE_BEGIN(_ENUM_TYPE_WITH_NS)
#define	MRPT_ENUM_TYPE_BEGIN_NAMESPACE(_NAMESPACE, _ENUM_TYPE_WITH_NS)
#define	MRPT_ENUM_TYPE_END()
#define	MRPT_FILL_ENUM(_X)   m_map.insert(_X, #_X)
	For use in specializations of TEnumTypeFiller. More...
#define	MRPT_FILL_ENUM_CUSTOM_NAME(_X, _NAME)   m_map.insert(_X, _NAME)
#define	MRPT_FILL_ENUM_MEMBER(_CLASS, _VALUE)   m_map.insert(_CLASS::_VALUE, #_VALUE)
#define	_MRPT_AUXTOSTR(__AA)   #__AA

Macro Definition Documentation

_MRPT_AUXTOSTR

#define _MRPT_AUXTOSTR

(

__AA

)

#__AA

Definition at line 96 of file TEnumType.h.

Referenced by mrpt::typemeta::TEnumType< ENUMTYPE >::name2value(), and mrpt::typemeta::TEnumType< ENUMTYPE >::value2name().

MRPT_ENUM_TYPE_BEGIN

#define MRPT_ENUM_TYPE_BEGIN

(

_ENUM_TYPE_WITH_NS

)

Value:

namespace mrpt                                                            \
    {                                                                         \
    namespace typemeta                                                        \
    {                                                                         \
    template <>                                                               \
    struct TEnumTypeFiller<_ENUM_TYPE_WITH_NS>                                \
    {                                                                         \
        static void fill(                                                     \
            mrpt::typemeta::internal::bimap<_ENUM_TYPE_WITH_NS, std::string>& \
                m_map)                                                        \
        {

Examples:

typemeta_TEnumType/test.cpp.

Definition at line 62 of file TEnumType.h.

MRPT_ENUM_TYPE_BEGIN_NAMESPACE

#define MRPT_ENUM_TYPE_BEGIN_NAMESPACE	(		_NAMESPACE,
			_ENUM_TYPE_WITH_NS
	)

Value:

MRPT_ENUM_TYPE_BEGIN(_ENUM_TYPE_WITH_NS)                           \
    using namespace _NAMESPACE;

Definition at line 74 of file TEnumType.h.

MRPT_ENUM_TYPE_END

#define MRPT_ENUM_TYPE_END

(

)

Value:

}                        \
    }                        \
    ;                        \
    }                        \
    }

Examples:

typemeta_TEnumType/test.cpp.

Definition at line 78 of file TEnumType.h.

MRPT_FILL_ENUM

#define MRPT_FILL_ENUM

(

_X

)

m_map.insert(_X, #_X)

For use in specializations of TEnumTypeFiller.

Examples:

typemeta_TEnumType/test.cpp.

Definition at line 86 of file TEnumType.h.

MRPT_FILL_ENUM_CUSTOM_NAME

#define MRPT_FILL_ENUM_CUSTOM_NAME	(		_X,
			_NAME
	)		m_map.insert(_X, _NAME)

Definition at line 87 of file TEnumType.h.

MRPT_FILL_ENUM_MEMBER

#define MRPT_FILL_ENUM_MEMBER	(		_CLASS,
			_VALUE
	)		m_map.insert(_CLASS::_VALUE, #_VALUE)

Examples:

typemeta_TEnumType/test.cpp.

Definition at line 88 of file TEnumType.h.
