xsxbusmessageid.h File Reference
This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Typedefs

typedef enum XsXbusMessageId XsXbusMessageId


Enumerations

enum  XsXbusMessageId {
  XMID_InvalidMessage =0x00, XMID_Wakeup =0x3E, XMID_WakeupAck =0x3F, XMID_ReqDid =0x00,
  XMID_DeviceId =0x01, XMID_Initbus =0x02, XMID_InitBusResults =0x03, XMID_ReqPeriod =0x04,
  XMID_ReqPeriodAck =0x05, XMID_SetPeriod =0x04, XMID_SetPeriodAck =0x05, XMID_SetBid =0x06,
  XMID_SetBidAck =0x07, XMID_AutoStart =0x06, XMID_AutoStartAck =0x07, XMID_BusPower =0x08,
  XMID_BusPowerAck =0x09, XMID_ReqDataLength =0x0A, XMID_DataLength =0x0B, XMID_ReqConfiguration =0x0C,
  XMID_Configuration =0x0D, XMID_RestoreFactoryDef =0x0E, XMID_RestoreFactoryDefAck =0x0F, XMID_GotoMeasurement =0x10,
  XMID_GotoMeasurementAck =0x11, XMID_ReqFirmwareRevision =0x12, XMID_FirmwareRevision =0x13, XMID_ReqBluetoothDisable =0x14,
  XMID_ReqBluetoothDisableAck =0x15, XMID_DisableBluetooth =0x14, XMID_DisableBluetoothAck =0x15, XMID_ReqXmOutputMode =0x16,
  XMID_ReqXmOutputModeAck =0x17, XMID_SetXmOutputMode =0x16, XMID_SetXmOutputModeAck =0x17, XMID_ReqBaudrate =0x18,
  XMID_ReqBaudrateAck =0x19, XMID_SetBaudrate =0x18, XMID_SetBaudrateAck =0x19, XMID_ReqSyncMode =0x1A,
  XMID_ReqSyncModeAck =0x1B, XMID_SetSyncMode =0x1A, XMID_SetSyncModeAck =0x1B, XMID_ReqProductCode =0x1C,
  XMID_ProductCode =0x1D, XMID_ReqProcessingFlags =0x20, XMID_ReqProcessingFlagsAck =0x21, XMID_SetProcessingFlags =0x20,
  XMID_SetProcessingFlagsAck =0x21, XMID_ReqInputTrigger =0x26, XMID_ReqInputTriggerAck =0x27, XMID_SetInputTrigger =0x26,
  XMID_SetInputTriggerAck =0x27, XMID_ReqOutputTrigger =0x28, XMID_ReqOutputTriggerAck =0x29, XMID_SetOutputTrigger =0x28,
  XMID_SetOutputTriggerAck =0x29, XMID_SetSyncBoxMode =0x2A, XMID_SetSyncBoxModeAck =0x2B, XMID_ReqSyncBoxMode =0x2A,
  XMID_ReqSyncBoxModeAck =0x2B, XMID_SetSyncConfiguration =0x2C, XMID_SetSyncConfigurationAck =0x2D, XMID_ReqSyncConfiguration =0x2C,
  XMID_SyncConfiguration =0x2D, XMID_DriverDisconnect =0x2E, XMID_DriverDisconnectAck =0x2F, XMID_XmPowerOff =0x44,
  XMID_ReqOutputConfiguration =0xC0, XMID_ReqOutputConfigurationAck =0xC1, XMID_SetOutputConfiguration =0xC0, XMID_SetOutputConfigurationAck =0xC1,
  XMID_ReqOutputMode =0xD0, XMID_ReqOutputModeAck =0xD1, XMID_SetOutputMode =0xD0, XMID_SetOutputModeAck =0xD1,
  XMID_ReqOutputSettings =0xD2, XMID_ReqOutputSettingsAck =0xD3, XMID_SetOutputSettings =0xD2, XMID_SetOutputSettingsAck =0xD3,
  XMID_ReqOutputSkipFactor =0xD4, XMID_ReqOutputSkipFactorAck =0xD5, XMID_SetOutputSkipFactor =0xD4, XMID_SetOutputSkipFactorAck =0xD5,
  XMID_ReqSyncInSettings =0xD6, XMID_ReqSyncInSettingsAck =0xD7, XMID_SetSyncInSettings =0xD6, XMID_SetSyncInSettingsAck =0xD7,
  XMID_ReqSyncOutSettings =0xD8, XMID_ReqSyncOutSettingsAck =0xD9, XMID_SetSyncOutSettings =0xD8, XMID_SetSyncOutSettingsAck =0xD9,
  XMID_ReqErrorMode =0xDA, XMID_ReqErrorModeAck =0xDB, XMID_SetErrorMode =0xDA, XMID_SetErrorModeAck =0xDB,
  XMID_ReqTransmitDelay =0xDC, XMID_ReqTransmitDelayAck =0xDD, XMID_SetTransmitDelay =0xDC, XMID_SetTransmitDelayAck =0xDD,
  XMID_SetMfmResults =0xDE, XMID_SetMfmResultsAck =0xDF, XMID_ReqObjectAlignment =0xE0, XMID_ReqObjectAlignmentAck =0xE1,
  XMID_SetObjectAlignment =0xE0, XMID_SetObjectAlignmentAck =0xE1, XMID_ReqAlignmentRotation =0xEC, XMID_ReqAlignmentRotationAck =0xED,
  XMID_SetAlignmentRotation =0xEC, XMID_SetAlignmentRotationAck =0xED, XMID_ReqXmErrorMode =0x82, XMID_ReqXmErrorModeAck =0x83,
  XMID_SetXmErrorMode =0x82, XMID_SetXmErrorModeAck =0x83, XMID_ReqBufferSize =0x84, XMID_ReqBufferSizeAck =0x85,
  XMID_SetBufferSize =0x84, XMID_SetBufferSizeAck =0x85, XMID_ReqHeading =0x82, XMID_ReqHeadingAck =0x83,
  XMID_SetHeading =0x82, XMID_SetHeadingAck =0x83, XMID_ReqMagneticField =0x6A, XMID_ReqMagneticFieldAck =0x6B,
  XMID_SetMagneticField =0x6A, XMID_SetMagneticFieldAck =0x6B, XMID_ReqLocationid =0x84, XMID_ReqLocationidAck =0x85,
  XMID_SetLocationId =0x84, XMID_SetLocationIdAck =0x85, XMID_ReqExtOutputMode =0x86, XMID_ReqExtOutputModeAck =0x87,
  XMID_SetExtOutputMode =0x86, XMID_SetExtOutputModeAck =0x87, XMID_ReqStringOutputType =0x8E, XMID_ReqStringOutputTypeAck =0x8F,
  XMID_SetStringOutputType =0x8E, XMID_SetStringOutputTypeAck =0x8F, XMID_ReqBatteryLevel =0x88, XMID_Batterylevel =0x89,
  XMID_ReqInitTrackMode =0x88, XMID_ReqInitTrackModeAck =0x89, XMID_SetInitTrackMode =0x88, XMID_SetInitTrackModeAck =0x89,
  XMID_ReqMasterSettings =0x8A, XMID_MasterSettings =0x8B, XMID_StoreFilterState =0x8A, XMID_StoreFilterStateAck =0x8B,
  XMID_SetUtcTime =0x60, XMID_ReqUtcTime =0x60, XMID_SetUtcTimeAck =0x61, XMID_UtcTime =0x61,
  XMID_AdjustUtcTime =0xA8, XMID_AdjustUtcTimeAck =0xA9, XMID_ReqActiveClockCorrection =0x9C, XMID_ActiveClockCorrection =0x9D,
  XMID_StoreActiveClockCorrection =0x9E, XMID_StoreActiveClockCorrectionAck = 0x9F, XMID_ReqAvailableFilterProfiles =0x62, XMID_AvailableFilterProfiles =0x63,
  XMID_ReqFilterProfile =0x64, XMID_ReqFilterProfileAck =0x65, XMID_SetFilterProfile =0x64, XMID_SetFilterProfileAck =0x65,
  XMID_ReqAvailableScenarios =XMID_ReqAvailableFilterProfiles, XMID_AvailableScenarios =XMID_AvailableFilterProfiles, XMID_ReqScenario =XMID_ReqFilterProfile, XMID_ReqScenarioAck =XMID_ReqFilterProfileAck,
  XMID_SetScenario =XMID_SetFilterProfile, XMID_SetScenarioAck =XMID_SetFilterProfileAck, XMID_ReqGravityMagnitude =0x66, XMID_ReqGravityMagnitudeAck =0x67,
  XMID_SetGravityMagnitude =0x66, XMID_SetGravityMagnitudeAck =0x67, XMID_ReqGpsLeverArm =0x68, XMID_ReqGpsLeverArmAck =0x69,
  XMID_SetGpsLeverArm =0x68, XMID_SetGpsLeverArmAck =0x69, XMID_ReqLatLonAlt =0x6E, XMID_ReqLatLonAltAck =0x6F,
  XMID_SetLatLonAlt =0x6E, XMID_SetLatLonAltAck =0x6F, XMID_GotoConfig =0x30, XMID_GotoConfigAck =0x31,
  XMID_BusData =0x32, XMID_MtData =0x32, XMID_SetNoRotation =0x22, XMID_SetNoRotationAck =0x23,
  XMID_RunSelfTest =0x24, XMID_SelfTestResults =0x25, XMID_PrepareData =0x32, XMID_ReqData =0x34,
  XMID_ReqDataAck =0x35, XMID_MtData2 =0x36, XMID_Reset =0x40, XMID_ResetAck =0x41,
  XMID_Error =0x42, XMID_MasterIndication =0x46, XMID_ReqFilterSettings =0xA0, XMID_ReqFilterSettingsAck =0xA1,
  XMID_SetFilterSettings =0xA0, XMID_SetFilterSettingsAck =0xA1, XMID_ReqAmd =0xA2, XMID_ReqAmdAck =0xA3,
  XMID_SetAmd =0xA2, XMID_SetAmdAck =0xA3, XMID_ResetOrientation =0xA4, XMID_ResetOrientationAck =0xA5,
  XMID_ReqGpsStatus =0xA6, XMID_GpsStatus =0xA7, XMID_WriteDeviceId =0xB0, XMID_WriteDeviceIdAck =0xB1,
  XMID_WriteSecurityKey =0xB2, XMID_WriteSecurityKeyAck =0xB3, XMID_ProtectFlash =0xB4, XMID_ProtectFlashAck =0xB5,
  XMID_ReqSecurityCheck =0xB6, XMID_SecurityCheck =0xB7, XMID_ScanChannels =0xB0, XMID_ScanChannelsAck =0xB1,
  XMID_EnableMaster =0xB2, XMID_EnableMasterAck =0xB3, XMID_DisableMaster =0xB4, XMID_DisableMasterAck =0xB5,
  XMID_ReqRadioChannel =0xB6, XMID_ReqRadioChannelAck =0xB7, XMID_SetClientPriority =0xB8, XMID_SetClientPriorityAck =0xB9,
  XMID_ReqClientPriority =0xB8, XMID_ReqClientPriorityAck =0xB9, XMID_SetWirelessConfig =0xBA, XMID_SetWirelessConfigAck =0xBB,
  XMID_ReqWirelessConfig =0xBA, XMID_ReqWirelessConfigAck =0xBB, XMID_UpdateBias =0xBC, XMID_UpdateBiasAck =0xBD,
  XMID_ToggleIoPins =0xBE, XMID_ToggleIoPinsAck =0xBF, XMID_SetTransportMode =0xC2, XMID_SetTransportModeAck =0xC3,
  XMID_ReqTransportMode =0xC2, XMID_ReqTransportModeAck =0xC3, XMID_AcceptMtw =0xC4, XMID_AcceptMtwAck =0xC5,
  XMID_RejectMtw =0xC6, XMID_RejectMtwAck =0xC7, XMID_InfoRequest =0xC8, XMID_InfoRequestAck =0xC9,
  XMID_ReqFrameRates =0xCA, XMID_ReqFrameRatesAck =0xCB, XMID_StartRecording =0xCC, XMID_StartRecordingAck =0xCD,
  XMID_StopRecording =0xCE, XMID_StopRecordingAck =0xCF, XMID_InfoBatteryLevel =0x49, XMID_InfoTemperature =0x4A,
  XMID_GotoOperational =0xC0, XMID_GotoOperationalAck =0xC1, XMID_ReqEmts =0x90, XMID_EmtsData =0x91,
  XMID_RestoreEmts =0x94, XMID_RestoreEmtsAck =0x95, XMID_StoreEmts =0x96, XMID_StoreEmtsAck =0x97,
  XMID_GotoTransparentMode =0x50, XMID_GotoTransparentModeAck =0x51
}
 Xsens Xbus Message Identifiers. More...


Typedef Documentation

◆ XsXbusMessageId

Definition at line 366 of file xsxbusmessageid.h.
